- Page 1 Installation Instructions ELEKTROMAT SI 45.15 FU-40,00 Model: 10004022 10011 -en- Status: 23.08.2018...
- Page 2 GfA ELEKTROMATEN GmbH & Co. KG Wiesenstraße 81 D-40549 Düsseldorf www.gfa-elektromaten.de info@gfa-elektromaten.de...
- Page 3 Table of contents General safety information ....................4 Technical Data ........................ 5 Mechanical installation ....................6 Electrical installation ..................... 10 Limit switch adjustment ....................11 Motor connection ......................12 ...
- Page 4 1 General safety information Specified normal use The drive unit is intended for doors, which have to be secured against falling down; a safety brake is included in the gearbox. The drive unit is directly mounted on the door shaft. The safe operation is only guaranteed with normal specified use.
- Page 5 2 Technical Data Type SG 85F Output torque 450 (410) Output speed OPEN 7-15 Output speed CLOSE 7-15 Output speed CLOSE > 2,5m 7-15 Output shaft / hollow shaft 40,00 Locking torque moment 1100 Safety brake (testhouse/approval number) 14-003612-PR03 Maximum holding torque Supply voltage 1N~ 230 Operating current...
- Page 6 3 Mechanical installation Prerequisites The permissible loads on walls, fastenings, mountings and transmission elements must not be exceeded, even for maximum holding torques or locking torques (▶ refer to technical data). Connection elements ▶ Self-locking connection ▶ Utilize the hole diameter ▶...
- Page 7 Mounting Two elongated holes are provided for mounting. BAGAD0 3 0 0 1 _Z0 0 3...
- Page 8 Installation The descriptions below apply to general door specifications. The specifications of the door manufacturer must also be observed during installation. Warning - Potential injury or danger to life! During installation, be sure to use a lifting device that has a sufficient load-carrying capacity.
- Page 9 ▶ Attach the drive unit. BAGAE0 3 0 0 5 _Z0 0 2 ▶ Tighten all connection elements (M12) to BAGAE0 3 0 1 0 _Z0 0 2 75 Nm. Install all other connection elements according to the specifications of the door manufacturer.
- Page 10 4 Electrical installation Warning - Danger to life from electric current! Switch the mains OFF and check that the cables are de-energised Observe the applicable regulations and standards Make a proper electrical connection Use suitable tools Performing electrical installation Remove the cover.
- Page 11 5 Limit switch adjustment The adjustment of the final limit positions OPEN and CLOSE is described in the instructions for the door control panel.
- Page 12 6 Motor connection Motor X13 Motor plug 7 Limit switch connection S10 Manual operation X12 DES connection Safety circuit Channel B (RS485) Ground Channel A (RS485) Safety circuit Supply network Connection cable...
- Page 13 8 Emergency manual operation (emergency hand crank) The emergency manual operation is designed for opening or closing the door without power supply. Its activation interrupts the control voltage. Electrical operation is no longer possible. Warning – Injuries due to incorrect operation or falling objects! ...
- Page 14 Plug in the crank and turn until it engages (①). Open or close by turning the crank (②). After use, the crank may be attached to the drive unit. ▶ Attach as illustrated.
- Page 15 9 Completion of commissioning / testing Check the following components and after that, mount all covers. Gearbox Check drive unit for oil loss (a few drops are not critical). Protect output shaft permanently against corrosion. Safety brake in the gearbox The safety brake requires no maintenance or inspection.
- Page 16 Emergency manual operation Function to be checked in a de-energised state. Carry out functional test only between final limit positions. Limit switches Check the final limit positions by opening and closing the door completely. The safety zone must not be reached. Entire drive unit Note! ...
- Page 17 EMC Directive 2014/30/EU within the meaning of RoHS Directive 2011/65/EU The following requirements from Appendix I of GfA ELEKTROMATEN GmbH & Co. KG the Machinery Directive 2006/42/EC are met: declare under our sole responsibility that the 1.1.2, 1.1.3, 1.1.5, 1.2.2, 1.2.3, 1.2.6, 1.3.2,...
