I-Tech UT1032 User Manual page 5

The MIO-SONIC device for ultrasound therapy is ideal for the treatment of
muscular and nervous pathologies and for the recovery of traumas, in case of
both chronic and acute pathologies.
In fact, ultrasound therapy is indicated for antalgic treatments and relaxation
of contracted muscles, in the treatment of neuritis and sciatalgia, joint
calcifications, tendinitis, hematomas and contractures.
For details, treatable pathologies, specific methods of application and use of
the programs, see the chapter dedicated to the use of the device.
The population of patients for ultrasound therapy treatment using the MIO-
SONIC device includes patients of both sexes, men and women, adults (unless
otherwise indicated). For more details, please refer to Contraindications
Technical features
Characteristics
Power supply
Isolation (EN 60601-1)
Applied part (EN 60601-1)
Dimensions
(length x height x depth)
Weight
Functioning
Maximum power
Effective power
Frequency range
Frequency modulation
Waveform
Modulation duty cycle
Regolation intensity
Ultrasound head
Effective radiant area
Ultrasonic beam
Head material
Conditions of use
Specifications
Medical power model GJ24WA-1500120V
Input: AC 100/240V, 50/60Hz
Output: DC 15V, 1.2A
II
BF
202x49x70mm
193g (power adapter not included)
Continuous
6.4W ± 20% (modulation duty cycle at 100%)
1.6W/cm² ± 20% (modulation duty cycle at
100%)
1MHz ± 10%
100Hz ± 10%
Pulsed
L: 5%
M: 50%
H: 100%
Adjustable on 3 steps L-M-H
5 cm²
4 cm² ± 20%
Collimated
Alluminium
Environmental
34
From +5° to +40°C
MNPG549-00
