- Page 1 ELECTRIC BICYCLE USER MANUAL www.volta.com.tr Please read this user manual carefully before using your vehicle...
- Page 2 PREFACE Thank you for choosing a Volta brand e-bike and for joining our family. This product is designed for environmentally friendly transportation. This user manual has been prepared to ensure the safe use of your e-bike. Before using your e-bike, please read the user manual carefully and follow all the warnings and procedures mentioned in the guide.
- Page 3 • After purchasing your e-bike, you are required to take it to the nearest authorized service for the first maintenance after 1 month. • Do not attach yourself or your bike to a vehicle. Do not ride with one hand. Only lift your feet off the pedals if road conditions require it. www.volta.com.tr...
- Page 4 ..................................DESCRIPTIONS ..................................SAFE DRIVING ..................................GENERAL VIEW ..................................ADJUSTING THE ELECTRIC BICYCLE ......................... OPERATION AND USAGE ..............................MAINTENANCE AND CONTROL ............................ CLEANING AND STORAGE OF ELECTRIC BICYCLE ....................REACTIVATING ..................................TECHNICIAL SPECIFICATIONS ............................MANUFACTURER INFORMATION ..........................WARRANTY ....................................www.volta.com.tr...
- Page 5 Any e-bike that complies with the European standard EN 15194-1 is considered a regular bicycle under Road Traffic Law. A driver’s license is not required for such an e-bike. NOTE We recommend the use of bicycle helmets for all e-bike users, without any discrimination. www.volta.com.tr...
- Page 6 Electric Power Assisted Bicycles (EN 15194:2017) manufactured by Volta Motor comply with the Electromagnetic Compatibility (2014/30/EU), Low Voltage (2014/35/EU), and Machinery Safety (2006/42/EC) directives.
- Page 7 As of 1 January 2016, all vehicles driven by electric motors of 250 watts or more will be licensed and fitted with a licence plate. Vehicles belonging to this motor type should go to the Traffic Registration Branch Directorate and register. NOTE We kindly ask you to act in accordance with the highway rules in your country. www.volta.com.tr...
- Page 8 This symbol refers to situations that require attention during use, adjustment, control or maintenance, and provides information about situations that may cause serious damage and accidents if ignored. This symbol indicates that you should read the user manual. Products marked with this symbol meet all applicable European Economic Community regulations. www.volta.com.tr...
- Page 9 This label provides information specific to each electric bicycle, such as the serial number, motor power, and other details, and is located on the main frame of the :VB3 Elektrikli Bisiklet :250 W :VB3...
- Page 10 “ Ampere Electrik Current Ampere hour Energy Capacity Pressure Gram Mass Hour Time Hertz Frequency Kilogram Mass km/h Kilometre/hour Speed Kilopascal Pressure Speed Newton meter Torque inçkareye pound Pressure Volt Electric Voltage Watt Electric Power Watt saat Electric Capacity www.volta.com.tr...
- Page 11 • • Avoid excessive puddles that may form in wet weather. Avoid excessive puddles that may form in wet weather. • • Never use under the influence of alcohol and drugs. Never use under the influence of alcohol and drugs. www.volta.com.tr...
- Page 12 • Check the control unit display for any warning or error messages. Clear the error before driving. • Make sure that the headlights and tail lights are switched on when activated and remain on when the bicycle is stationary. www.volta.com.tr...
- Page 13 CAUTION • The parts listed in the user manual are provided as a reference. The manufacturer may make changes without prior notice. • Your electric bicycle is shipped with approximately 20% charge and charge your bicycle before first use. www.volta.com.tr...
- Page 14 CAUTION • The parts listed in the user manual are provided as a reference. The manufacturer may make changes without prior notice. • Your electric bicycle is shipped with approximately 20% charge and charge your bicycle before first use. www.volta.com.tr...
- Page 15 CAUTION • The parts listed in the user manual are provided as a reference. The manufacturer may make changes without prior notice. • Your electric bicycle is shipped with approximately 20% charge and charge your bicycle before first use. www.volta.com.tr...
- Page 16 8. PAS Level 9. Cruise Inducator 10. Battery Charge Status 11. Power On/Off Button 12. Plus Button 13. Minus Button CAUTION The parts listed in the user manual are provided as a reference. The manufacturer may make changes without prior notice. www.volta.com.tr...
- Page 17 Initial Movement Assistance: The electric assistance is activated after you start pedaling the bike. However, if you want to start moving without pedaling, you can activate the bike’s initial movement without pedal assistance by holding down the minus button. The initial movement assistance will be deactivated in the following situations: www.volta.com.tr...
- Page 18 P04: Automatic Sleep Time: It allows the bicycle to go to sleep in the specified time if the bicycle is not used when the power is on. When P04 is active, a value of 0 means that it will never go to sleep mode. Other values indicate the time in minutes to go to sleep in case of non-use. www.volta.com.tr...
- Page 19 3-5-8 options suitable for the user. P06 Wheel Diameter: The rim size of the VB3 electric bicycle is 20 inches. This value should be set as 20 on the display. In this way, the bicycle will be able to keep the km counter correctly thanks to its own rim size.
- Page 20 P18 Gas Level Option: Since there is no throttle lever option in this model, the 0 option comes factory set as unchangeable. P19 Cruise Control: 0 and 1 options are available. 0: Throttle Lever, without 6 km/h constant speed definition. 1: Throttle Lever, with 6 km/h constant speed definition. www.volta.com.tr...
- Page 21 4.4.3. Display Error Codes Error codes that may occur on the display are as follows. If one of these codes is encountered, get support from the nearest authorised Volta Motor service. Error Code Error Code Descriptions Normal Reserved (the error code does not represent an error at the moment, but may be used as an error code in the future).
- Page 22 WARNING Make sure the lock mechanism that helps adjust the saddle height is tightened properly and does not move. Otherwise, the lock mechanism may loosen, which could cause the saddle to move unexpectedly, leading to accidents or undesirable situations. www.volta.com.tr...
- Page 23 CAUTION • Make sure that all saddle adjustment mechanisms are tightened before every journey. • If you leave your e-bike unattended, make sure that all adjustments are correct before setting off again. www.volta.com.tr...
- Page 24 The brake system of your bicycle is equipped with front wheel mechanical disc brake system and rear wheel hydraulic disc brake system. For proper braking, the brake lever free travel distance should be 5-10 mm. Braking should start from this distance. www.volta.com.tr...
- Page 25 • The brake system is vital for your safety. Have regular checks and adjustments performed by authorized service centers according to the intervals specified in the periodic maintenance schedule. DİKKAT During braking, disc brakes heat up, so avoid touching the discs immediately after use. www.volta.com.tr...
- Page 26 To switch on the lighting system, press and hold the plus button on the indicator for 3 seconds. This will switch on the lighting system. To switch off, press and hold the same button for 3 seconds again. www.volta.com.tr...
- Page 27 The permissible load level for the rear carrier bar is 5 kg. CAUTION Do not carry loads on surfaces of the bicycle that are not designed for carrying. Otherwise, both the components may be damaged, and the safety of the ride could be compromised. www.volta.com.tr...
- Page 28 With their lightweight design, lithium ion batteries provide lightness to their users both while on the e-bike and when removed from the bike for charging. NOTE Lithium-ion batteries do not have a memory effect. Therefore, you can fully charge your battery after every ride. www.volta.com.tr...
- Page 29 If you’re not using your e-bike, you should recharge the battery at least once every month. NOTE Make sure the charging socket has a 220V connection. A fluctuating voltage output or an unstable power source may damage the battery cells. www.volta.com.tr...
- Page 30 • Ensure that you see the charging indicator light on the display panel, confirming that the battery is charging. • Once charging is complete, disconnect the charger from the bike’s charging port. • Finally, unplug the charger from the power outlet. www.volta.com.tr...
- Page 31 After the battery is fully charged, all of the indicator lights on it will light up. The charge level can be monitored through the indicator lights. The remaining capacity of the battery can be monitored by pressing the on/off button on the battery. www.volta.com.tr...
- Page 32 24 hours at least once every three months. This will keep the battery in good condition. Make sure that your battery is stored in a well-ventilated and dry place. • If you have any questions about proper service and maintenance, contact your local e-bike dealer. • Do not disassemble the battery. www.volta.com.tr...
- Page 33 • Do not store the battery in cold and humid environments. If stored for more than one month, please charge the battery once a month for two hours. • If the battery becomes waste or is no longer used, please return it to the manufacturer or to the recommended waste collection facilities. www.volta.com.tr...
- Page 34 The brake pads and disc must be completely free of oil based on petroleum/grease. In case the brake pads are contaminated in this way, they must be replaced with new ones. The brake disc must be cleaned with detergent, rinsed, and dried. www.volta.com.tr...
- Page 35 If the tire does not have the correct air pressure, it will wear out more quickly and its lifespan will be shortened. Additionally, underinflated tires can reduce grip and may cause accidents. • In the case of very low air pressure, the tire may come off the rim. www.volta.com.tr...
- Page 36 When maintaining the cassette, use pure alcohol. Do not use solvent-based products, as they can damage the cassette and make gear shifting difficult. WARNING • Even the smallest crack or break in the crankset can cause serious injury. www.volta.com.tr...
- Page 37 • Using a fuse with a capacity lower than specified can cause the system to continuously trip, while using a fuse with a capacity higher than specified can damage electronic components and wires due to high currents. • Do not use high-pressure water when washing your vehicle, as it may damage the electrical systems. www.volta.com.tr...
- Page 38 The 1st and 4th month maintenance are important for your vehicle. After the first use, the motor components have adjusted to each other, and it is recommended to check all bolts during the first maintenance. The reliability of your vehicle depends on the proper completion of the initial use and the first periodic maintenance. www.volta.com.tr...
- Page 39 7.9. Periodic Maintenance Schedules Periodic maintenance should be carried out by authorized Volta Motor service centers. Vehicles that do not adhere to the maintenance intervals will be excluded from the warranty coverage. WARRANTY MAINTENANCE CARD PERIODIC MAINTENANCE TABLE 4.MONTHS 8.MONTHS 12.MONTHS...
- Page 40 www.volta.com.tr...
- Page 41 (approx. 5-10% per month) when inactive. Therefore, check the battery regularly and if you observe a reduction in capacity, charge it to the recommended level of 60-80%. CAUTION Li-ion batteries are fully recyclable. At the end of the battery’s lifetime, you can hand it in to any collection point or your retailer. www.volta.com.tr...
- Page 42 Store your electric bike in a dry and dark place, keeping it protected from dust. Cover it with a non-plastic or rubber cover. Be careful when storing in conditions where the temperature does not fluctuate too much. Large temperature variations can cause wear, damage, and cracking of many parts of your bike. www.volta.com.tr...
- Page 43 Do the first use in an area closed to traffic. After making sure that all parts of your electric vehicle are working correctly and at full performance, go out into traffic. Assembly The electric bicycle is delivered assembled. www.volta.com.tr...
- Page 44 Tyres Max Carrying Capacity Front Tire Size Engine Power 250 W 26*1.95 Rear Tire Size Engine Type BLDC 26*1.95 Rims Battery Type Lithium-Ion 26 inc Battery Capacity 36V 10Ah Charger Capacity 36V 2A Charging Time 4,5 - 5 h www.volta.com.tr...
- Page 45 11. Manufacturer Information The service life of your Volta brand vehicle is 10 years, and the maximum repair period is 45 working days. If you encounter any problems with your vehicle, you can visit our website www.volta.com.tr and access information about authorized services and spare parts.
- Page 46 www.volta.com.tr...
- Page 47 www.volta.com.tr...
- Page 48 www.volta.com.tr...
- Page 49 22. Battery swelling due to overcharging or sulphation due to non-compliance with charging rules 23. The faults during the warranty period must be repaired within the scope of the warranty by contacting the authorised services with the warranty certificate and user manual. www.volta.com.tr...
- Page 50 Hail, storm, flood, lightning, and other natural disasters. • Cosmetic conditions, scratches in the paint. 10. During the warranty period, you should apply to our authorised service stations with the warranty certificate and user manual for the repair of malfunctions within the scope of the warranty. www.volta.com.tr...
- Page 51 NOTES..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................www.volta.com.tr...
- Page 52 Yaka Mah. 401. Sok, No: 19, 0380 731 25 25 0850 222 28 65 0850 222 28 65 0850 222 28 65 www.volta.com.tr...
