Homedics VibraDent Sparkle HD-120C Manual

CHARGING INSTRUCTIONS

Follow this procedure before you use VibraDent Sparkle for the first time.

To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not change the plug in any way.

1. Plug the charger base into a 120-volt outlet. Place the handle into the base and allow it to charge for at least 16 hours before using it for the first time.
2. The charger indicator light will show red when the unit is correctly placed in the charger base. The indicator will go out when the toothbrush is removed from the base.
3. The optimum voltage for charging is 120V.
4. To maintain the unit's full performance, it should always be stored on the charging base after use.

Note: Charge for at least 16 hours before using the unit for the first time.

HOW TO USE THE PRODUCT

1. Attach the brush head to the handle by positioning the brush head at a 90 angle to the left of the handle. Turn the brush head counter clockwise one quarter turn, so the bristles are facing the same direction as the ON/OFF button. (See Fig.1)

2. Before brushing, rinse your mouth thoroughly and wet the brush head to moisten, then apply tooth paste.
3. To avoid splashing, guide the brush head to your teeth before switching the unit on. Place the brush in a slanted position, 45° towards the gum line.
4. Press the "ON" button to activate the unit.
5. Gently guide the brush head from tooth to tooth, spending a few seconds on the surface of each tooth.
6. Brush the gumlines as well as the teeth, starting with the outside teeth and gums, followed by the insides and finishing with the chewing surfaces.

7. Do not press too hard or scrub with VibraDent Sparkle. Allow the unit to do the work.
8. The auto timer feature will automatically turn the unit off after the 2-minute dentist recommended brushing time.
   NOTE: To turn the unit off before the 2 minutes have elapsed, simply press the "OFF" button.
9. Rinse mouth thoroughly with water.
10. Brush heads should be replaced every 2-3 months to ensure optimal performance. HoMedics replacement heads (RH-V) for this model are available at your local retailer or check www.homedics.com for a list of retailers that offer these replacement heads.

CLEANING AND MAINTENANCE

1. After use, rinse the brush head for several seconds under running water with the handle switched on.
2. Switch the handle off, and take off the brush head.
3. Rinse both parts separately under running water and wipe them dry. Note: Be sure to point the handle downward (upside down) when rinsing. Do not allow water to drain down into the handle.
4. After cleaning place the VibraDent Sparkle handle back on the charging base.
5. When VibraDent Sparkle is not in use for an extended period, unplug the cord and store.
6. Clean the charger base periodically with a soft cloth or paper towel. The charger base must be dry before plugging it into an electrical outlet.

Note: To maintain optimal performance, we recommend that you replace your brush head every 2-3 months.

Note: We recommend soaking the brush head in a denture cleaner (commercially available) every 2 to 4 weeks to keep it hygienically clean.

All servicing of this unit must be performed by authorized HoMedics service personnel only.

MEDICAL SAFEGUARDS

Please note the following instructions for your continued safety.

1. Similar to starting any new oral hygiene product, contact your dentist before using VibraDent Sparkle if you have had oral or periodontal surgery.
2. Contact your dentist if excessive bleeding occurs or if bleeding continues after 2 weeks.
3. This product is designed for cleaning teeth and gums only. Do not use for any other purpose.

SPECIAL INSTRUCTIONS

REMOVING AND DISPOSING OF NI-CAD BATTERIES
VibraDent Sparkle is equipped with long-lasting, rechargeable nickel-cadmium batteries. To help protect our environment, they should be removed at the end of the unit's life for safe disposal. Batteries CANNOT be replaced.

To remove the batteries before discarding product:

1. Place the handle in the charging base and turn counter clockwise to remove the cap.
2. Slide the battery out of the handle and remove.
3. Dispose of the cell-pack in compliance with national or local regulations for environmental protection and recycling of raw materials. Do not dispose of the cell-pack by burning or incineration.

Opening the handle will destroy the appliance and invalidate the warranty.

Note: During the first few days of using, your gums may bleed slightly. Any bleeding should stop within a few days. If your gums continue to bleed for a period of 2 weeks or more, discontinue use and consult your dentist.

IMPORTANT SAFEGUARDS

WHEN USING ELECTRICAL PRODUCTS, ESPECIALLY WHEN CHILDREN ARE PRESENT, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING:
READ ALL INSTRUCTIONS BEFORE USING

TO REDUCE THE RISK OF ELECTROCUTION:

• DO NOT handle the plug with wet hands.
• DO NOT place or store the charger base where it can fall or be pulled into a tub, sink or toilet.
• DO NOT reach for a charger base that has fallen into water. Unplug immediately.
• DO NOT use while bathing.
• DO NOT submerge the charger base in water or any other liquid.
• This charger base is designed for use in 120-volt, 60 Hz outlet. NEVER force the plug into an outlet.

TO REDUCE THE RISK OF BURNS, ELECTROCUTION, FIRE OR INJURY:

• DO NOT excessively bend or pull the cord. Unplug the cord by grasping the plug—not the cord.
• Keep the cord away from heated surfaces.
• Use this product only for its intended use as described in this manual. DO NOT use the product for any other purpose.
• DO NOT use attachments not recommended by HoMedics.
• DO NOT use outdoors or operate where aerosol products are being used or where oxygen is being administered.
• NEVER insert brush head into or remove it from the universal handle while the product is on.
• NEVER operate the product if it has a damaged cord or plug, if it is not working properly, if the charging base has been dropped or damaged, or if it has been immersed in water. Return the product to HoMedics service center for examination and repair.
• This product should never be used by any individual suffering from any physical ailment that would limit the user's capacity to operate the controls.
• This unit should not be used by children without adult supervision.
• Not recommended for children under 3.
• Avoid using a brush with crushed or bent bristles.
• NEVER use while sleeping or when drowsy.
• For household use only.

Note: When the rechargeable cells are running empty, the toothbrush automatically turns off. This protects the rechargeable cells from deep discharging and signals that the power unit should be charged.

Note: The handle may warm up during charging. This has no effect on the unit's operation.

VibraDent Sparkle comes with 3 color coded brush heads for multiple users.

SAVE THESE INSTRUCTIONS

ONE YEAR LIMITED WARRANTY

To obtain warranty service on your HoMedics product, either hand deliver or mail the unit and your dated sales receipt (as proof of purchase), postpaid, along with check or money order in the amount of $5.00 payable to HoMedics, Inc. to cover handling.

Mail to:
HoMedics
Service Center Dept. 168
3000 Pontiac Trail
Commerce Township, MI
48390

e-mail:
cservice@homedics.com
