PCB Piezotronics ICP S111A24 Installation And Operating Manual page 9

Model Number
111A24
Performance
Measurement Range(for ±5V output)
Useful Overrange(for ± 10V output)
Sensitivity(± 0.5 mV/psi)
Maximum Pressure
Resolution
Resonant Frequency
Rise Time(Reflected)
Low Frequency Response(- 5 %)
Non-Linearity
Environmental
Acceleration Sensitivity
Temperature Range(Operating)
Temperature Coefficient of Sensitivity
Maximum Flash Temperature
Maximum Vibration
Maximum Shock
Electrical
Output Polarity(Positive Pressure)
Discharge Time Constant(at room temp)
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Physical
Sensing Geometry
Sensing Element
Housing Material 17-4 Stainless Steel
Diaphragm
Sealing
Electrical Connector 10-32 Coaxial Jack
Weight
[4]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Piezotronics, Inc.
ICP® PRESSURE SENSOR
EN GLISH SI
1,000 psi 6,895 kPa
2,000 psi 13,790 kPa
5.0 mV/psi 0.73 mV/kPa
10,000 psi 68,950 kPa
0.02 psi 0.14 kPa
≥ 400 kHz ≥ 400 kHz
≤ 1.5 µ sec ≤ 1.5 µ sec
0.005 Hz 0.005 Hz
≤ 2.0 % FS ≤ 2.0 % FS
0.002 psi/g 0.0014 kPa/(m/s²)
-100 to +275 °F -73 to +135 °C
≤ 0.03 %/°F ≤ 0.054 %/°C
3,000 °F 1,649 °C
2,000 g pk 19,600 m/s² pk
20,000 g pk 196,000 m/s² pk
Positive Positive
≥ 100 sec ≥ 100 sec
20 to 30 VDC 20 to 30 VDC
2 to 20 mA 2 to 20 mA
≤ 100 Ohm ≤ 100 Ohm
8 to 14 VDC 8 to 14 VDC
Compression Compression
Quartz Quartz
17-4 Stainless Steel
Invar Invar
Welded Hermetic Welded Hermetic
10-32 Coaxial Jack
0.21 oz 6 gm
Optional versions have identical specifications and accessories as listed for the standard model except
where noted below. More than one option may be used.
[1]
- Ablative Coating
CA
E - Emralon coating
[2]
Coating
Electrical Isolation
Supplied Accessory: Model 065A08 Isolation ring 0.250"OD x 0.218" ID x 0.027" thk anodized
aluminum (3)
Supplied Accessory: Model 065A22 Isolation Seal, .250" OD x .218" ID x .015", Torlon or Vespel (3)
[3]
J - Ground Isolated
Electrical Isolation(50 V)
[2]
- Negative Output Polarity
N
S - Stainless Steel Diaphragm
Diaphragm
W - Water Resistant Cable
- Water Resistant Cable
WM
N OTES:
[1]For +10 volt output, minimum 24 VDC supply voltage required. Negative 10 volt output may be
limited by output bias.
[2]Typical.
[3]Zero-based, least-squares, straight line method.
[4]See PCB Declaration of Conformance PS023 for details.
[5]Used with optional mounting adaptor.
[6]For sensor mounted in thread adaptor, see adaptor installation drawing for supplied accessories
and pressure limitations.
[7]Clamp nut installed prior to cable attachment
SUPPLIED ACCESSORIES:
Model 060A03 Clamp nut, 5/16-24-2A thd, 1/4" hex, stainless steel (1)
Model 060A05 Clamp nut M7 x 0.75-6g thd (1)
Model 065A02 Seal ring, sensor flush mount, 0.248" OD x 0.219" ID x 0.015" thk, brass (3)
Model 065A05 Seal sleeve sensor recess mount 0.248" OD x 0.221" ID x 0.240" thk 17-4 (1)
Model PCS-1AZ Sensitivity calibration at 100% and 10% of sensor range
Entered: ND Engineer: AJA
Date: 06/26/2024 Date: 06/26/2024 Date: 06/26/2024 Date: 06/26/2024 111-1240-80
3425 Walden Avenue, Depew, NY 14043
Revision: N
ECN #: 54949
OPTION AL VERSION S
Emralon Emralon
8 8
10 Ohm 10 Ohm
8 8
10 Ohm 10 Ohm
316L Stainless Steel 316L Stainless Steel
Sales: RWM Approved: RPF Spec Number:
Phone: 716-684-0001
Fax: 716-684-0987
E-Mail: info@pcb.com
[5]
[6]
[6][5]
[6]
[6]
[6][7]
[6][7]
