PCB Piezotronics ICP S111A24 Installation And Operating Manual page 11

4
PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
ELECTRICAL CONNECTOR
10-32 UNF - 2A
B
MODEL 060A05
3
CLAMP NUT
.25 [6.4] HEX
M7x0.75 - 6g
4 PRESSURE SENSOR
.235  .001 5.97 [  .03 ]
[ ]
+ .000 + .00
 
.218 5.54 - .03
- .001
[ ]
+ .000 + .00
A  
.248 6.29 - .03
- .001
4 IC AMP & SENSOR ARE SEALED ASSEMBLIES & SHOULD BE
RETURNED TO THE FACTORY FOR SERVICE &/OR REPAIR
3 RECOMMENDED TORQUE ON .25 [6.3] HEX: 25-35 IN-LBS [2.8-3.9 N-m]
2 DIMENSIONS "A" & "B" TO SUIT USER REQUIREMENTS
1 THESE DIMENSIONS FOR .750 [19.05] THICK WALL. C'BORE FOR THICKER WALLS
4
3
LENGTH
CHARGE 1.32± .05 [33.5]
®
1.46± .05 [37.1]
ICP
.81 [20.6]
.34 [8.5]
3
2
MOUNTING HOLE PREPARATION
MODEL 065A02 SEAL
.015 [.38] THICK
1 FLUSH INSTALLATION
 .221± .002 [5.61± .05] THRU
.250 +.003 6.35 +.08
 -.000 [  -.00 ]  .520 [13.20]
M7x0.75 - 6H  .400 [10.16]
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES DIMENSIONS IN MILLIMETERS
[ IN BRACKETS ]
DECIMALS XX ±.01 DECIMALS X ± 0.3
XXX ±.005
XX ± 0.13
ANGLES  2 DEGREES ANGLES  2 DEGREES
CABLE TOLERANCES IN ENGLISH CABLE TOLERANCES IN METRIC
1"≤ LENGTH < 1' = +1"/ - 0
2.54cm ≤ LENGTH < 30.5cm = +2.54cm/ - 0
1'≤ LENGTH < 5' = +2"/ - 0
30.5cm ≤ LENGTH < 1.5m = +5.1cm/ - 0
5'≤ LENGTH < 100' = +6"/ - 0
1.5m ≤ LENGTH < 30.5m = +15.2cm/ - 0
30.5m ≤ LENGTH = +30.5cm/ - 0
100'≤ LENGTH = +1'/ - 0
FILLETS AND RADII FILLETS AND RADII
.003 - .005 0.07 - 0.13
2
1
REVISIONS
REV DESCRIPTION
-SEE SHEET 1-
MODEL 065A05 SEAL
.240 [.610] LONG
2
"A"

"B" 2
RECESSED INSTALLATION
.250 +.003 6.35 +.08
  
-.000 [ -.00 ] .750 [19.05]

M7x0.75 - 6H .400 [10.16]
DRAWN CHECKED ENGINEER
NJF 09/23/22 JDM 09/23/22 AJA 09/23/22
3425 WALDEN AVE. DEPEW, NY 14043
TITLE
INSTALLATION DRAWING (716) 684-0001 E-MAIL: sales@pcb.com
METRIC MOUNT
DWG. NO.
CODE
MODELS 111, 112, & 113 SERIES IDENT. NO.
52681
PRESSURE SENSOR
SCALE:
1
DIN
B
A
40623
4X SHEET 2 OF 2
