INSTALLATION OF DRAIN WATER OUTLET
As a way to drain waste water from the Countertop Water Machine:
1
2
PEX Pipe), and insert it
into the drain port.
With this approach, the drain water will empty into your sink, reducing the available water for filtration, within
the Water Tank. Simply refill the Water Tank when it gets low.
Remove the Quick Connect Port Plug in the Drain
Water Port, located on the back on the Machine
next to the power cord attachment, by depressing
the collar in all of the way using the Quick Connect
Release Tool and gently remove the Plug.
3
Place the end of the
small drain hose into
your sink drain, allowing
the flushed out water to
go directly into your sink.
There are two optional
elbows to help install the
drain line if needed.
x
x
Avoid bending or twisting the drain pipe.The pipe
needs to go into the Machine straight on. If it
comes into the Machine at an angle, it will most
likely cause leaking.
