- Page 2 catalog foreword ............ 1 1. Equipment overview ........3 2. Equipment introduction ........4 2.1. working principle ........4 2.2. technical parameter ........ 5 2.3. Safety Precautions ......... 6 3. Introduction of equipment packaging, transportation and lifting ............. 8 4. Equipment introduction ........9 4.1.
- Page 3 6.1. Add X, Y to the guide rail lubricating oil ..22 6.2. Slider assembly grease application ....23 7. Troubleshooting judgment ....错误!未定义书签。 7.1. The vibrating knife does not vibrate ....24 7.2. The sharpening knife is not sharp ....24 7.3.
- Page 4 In order to facilitate your better use of this device, please read the user manual carefully, follow the steps, and keep it properly after reading. From beginning to end, IECHO's "star service" will accompany you, no matter what problem you have when using it, please contact us according to the phone number and address on the user manual, we are always waiting to serve you.
- Page 5 Internal or external modifications to the equipment should only be made after prior consultation with Hangzhou IECHO Technology Co., Ltd. Caution The company is not responsible for the safety injury caused by the use of accessories not authorized by Hangzhou IECHO Technology Co., Ltd.
- Page 6 Equipment overview ⚫ GLSC automatic multi-layer cutting system consists of multi-layer cutting machine, cutting machine control software CutterServer and data processing software IMlyCut. ⚫ The multi-layer cutting machine is composed of cutting machine plane XY motion mechanism, electrical control system, vacuum pump control system, head tool vibration and tool drop control system, tool automatic sharpening system, tool intelligent correction system, drilling device, automatic receiving platform , and auxiliary paving system and other components.
- Page 7 methods), deceleration, boundary cutting condition definition (deceleration, boundary deceleration cutting definition), specific sharpening point definition, specific graphic cutting method definition, etc. Cut data adapted to multi-layer cropping. Equipment introduction 2.1. working principle...
- Page 8 ⚫ The GLSC multi-layer cutting machine uses the IMulCut software to edit the user data (general dxf, cut, nc, plt format), such as sample analysis, automatic nesting, cutting attributes, etc. After generating the cutting task, the Cutterserver sends it to the cutting machine, According to the cutting data, the control system calculates at high speed and generates motion control instructions, and the servo motor and pneumatic actuators complete the motion control actions such as cutting trajectory, rotary knife, lifting...
- Page 9 Maximum crop 90 mm(after compression） height maximum cutting 90 m/min speed ≤1 mm Crop accuracy Drilling device 1、2.、3Punching (optional) drilling heating Optional Knife cooling Optional device Lateral rail Optional movement cleaning device Optional Self-diagnosis Optional (maintenance) Working status Optional monitoring display Communication 485 communication Interface...
- Page 10 ensured that there is no debris on the work surface. 2.3.5. If there is an abnormal situation when the cutting machine is running, immediately press the emergency stop switch or directly turn off the main power switch. 2.3.6. Before starting the machine, check the tool and cutter head to see if the cutting tool is lifted, and then start the equipment after confirming that it is normal.
- Page 11 Introduction of equipment packaging, transportation and lifting ⚫ The center of gravity of the equipment on the two beams of the equipment cavity (where the red arrow points in Figure 1) ⚫ Forklift fork feet fork two beams, and the feet extend out of the entire beam.
- Page 12 ⚫ When the crane is hoisting, thread the wire rope into the square pipe groove pointed by the red arrow. Equipment introduction 4.1. Overall appearance...
- Page 13 4.2. head assembly 4.3. Vacuum adsorption parts...
- Page 14 ⚫ The working principle of the vacuum system is shown in the figure. The GLSC automatic multi-layer cutting system fixes the fabric to be cut on the cutting table through a vacuum adsorption system. The efficient vacuum adsorption design is not only closely related to the cutting effect of the equipment, but also can save a lot of energy for the enterprise.
- Page 15 4.4. Ground rail moving parts ⚫ The GLSC fully automatic multi-layer cutting system can install the ground rail according to the user's production mode to move one for two, one for three, and realize uninterrupted cutting of the cutting equipment, which greatly meets the needs of users.
- Page 16 4.5. Knife Smart Parts ⚫ When cutting thicker and harder fabrics, when the tool runs to an arc or a corner, due to the extrusion of the fabric to the blade, the blade and the theoretical contour line are offset, causing the offset between the upper and lower layers.
- Page 17 fabric through this button. 2.Manual sharpening key: Press this key to start sharpening the blade. 3.Vibrating knife switch button, press this button to start the vibrating knife motor; press it again to turn off the vibrating motor. 4.Cutting line function: When the cutting knife is facing the cutting position, just press and hold this button, the equipment can automatically realize vibration, knife drop, movement and other work, complete the cutting work along the Y axis direction, and realize the manual cutting...
- Page 18 9.Red light point on/off button: Press this button to light up the red light point, and control the movement of the machine head and the beam by moving the crank handle. The position of the red light point is the position of the knife during cutting.
- Page 19 installation 5.1. Site requirements ⚫ The ground of the installation site should be basically flat. ⚫ If it is installed on the upper floor of the building, it must first be confirmed that the floor load-bearing can ensure the safety of equipment installation, and it is recommended that on the basis of satisfying the floor load-bearing, the main engine should be installed above the main beam to ensure a higher safety factor.
- Page 20 5.2. The installation steps are as follows 5.2.1. The host equipment is in place: Check the equipment layout diagram to make sure that the moving direction of the equipment is consistent with the installation position. After being in place, determine whether the front, back, left, and right positions of the equipment meet the customer's normal use and future maintenance requirements.
- Page 21 5.2.4. External gas source access: connect the 12-point gas pipe to the oil-water separator as shown in the figure 5.2.5. Tool piston installation: Extend the piston from bottom to top (Figure 1), and fix the main connecting rod of the card with M3 screws (Figure 2)
- Page 22 5.2.6. Blade installation: Insert the blade into the cutter head obliquely (Figure 1), and fix the blade on the piston connector with M3 screws after entering (Figure 2). 5.2.7. Abrasive belt installation: Press your fingers in the direction of the arrow (Fig.
- Page 23 5.2.8. Drilling installation: Put the drilling tool into the drilling part (Figure 1), and fix the tool on the drilling part with screws (Figure 2)
- Page 24 routine maintenance operations...
- Page 25 ⚫ Use an air gun or a brush to clean the X- and Y-direction racks frequently to ensure that the racks are free of debris. ⚫ When the software prompts that the parameter of the front blade is too small, it means that the blade edge has been used up and a new blade needs to be replaced.
- Page 26 amount of the supplied lubricating oil must be added. 6.2. Slider assembly grease application ⚫ Every time the tool is changed, an even layer of grease must be applied to the outer surface of the slider assembly.
- Page 27 Troubleshooting judgment 7.1. The vibrating knife does not vibrate ⚫ If the machine suddenly does not vibrate (or breaks the knife) during work, press the emergency stop button at the first time, and manually move the machine head to the origin position. Open the cover of the machine head, turn the eccentric shaft of the machine head to see if there is any abnormality, and observe whether the transmission belt is slipping or the transmission belt is broken.
- Page 28 bent, the bristles fall off, and the bristle bricks should be replaced. 7.4. Vacuum pump not working properly ⚫ The vacuum pump works for a long time and the temperature is too high. ⚫ The inverter that controls the vacuum pump reports an error. ⚫...
- Page 29 equipment is running. ⚫ When checking and maintaining the equipment, please disconnect the power supply, and it is strictly forbidden to plug or unplug the cable plug or perform wiring operations while the power is on. ⚫ If you need to check, debug the cutting head or replace the tool in the power-on state, it must be confirmed that the cutting machine has been stopped.
- Page 30 Protective measures 9.1. mechanical protection ⚫ Emergency stop button: Usually during the cutting process, the operator finds that the cutting cannot be carried out. If the robot has not left the safe distance of the cutting machine, he can press the emergency stop button at the four corners of the equipment, and the equipment will stop working.
- Page 31 equipment are shown in the following table: 9.3. nameplate ⚫ The machine warning nameplate is shown in the figure below Introduction of packaging and handling process 10.1. Handling Precautions ⚫ The packaged cutting equipment should be able to adapt to a variety of...
- Page 32 transportation methods. During transportation, the product should be fixed with a tie-down tool to avoid dumping, collision, sun and rain, and keep the product clean. ⚫ When loading and unloading, it should be handled with care to avoid collision. ⚫ During transportation, it should not be shipped together with flammable, explosive and corrosive items.
- Page 33 ◼ The copyright of this manual belongs to Hangzhou IECHO Technology Co., Ltd. (hereinafter referred to as IECHO). ◼ IECHO makes no guarantees about this manual, and IECHO will not be held responsible for any misunderstandings that may be caused by users of this manual.
