- Page 1 Oven JC43060.0 User manual and installation instructions...
- Page 2 en Safety Futher information and explanations are available online: Table of contents 1.2 Intended use This appliance is designed only to be built INFORMATION FOR USE into kitchen units. Read the special installation instructions. Safety .............. 2 Only a licensed professional may connect ap- Preventing material damage ...... 4 pliances without plugs.
- Page 3 Safety en Loose food remnants, fat and meat juices WARNING ‒ Risk of injury! may catch fire. Scratched glass in the appliance door may ▶ Before using the appliance, remove the develop into a crack. worst of the food residues and remnants ▶ Do not use any harsh or abrasive cleaners from the cooking compartment, heating ele- or sharp metal scrapers to clean the glass ments and accessories.
- Page 4 en Preventing material damage 1.5 Halogen bulb WARNING ‒ Risk of suffocation! Children may put packaging material over WARNING ‒ Risk of burns! their heads or wrap themselves up in it and The bulbs in the cooking compartment get suffocate. very hot. There is still a risk of burning for ▶...
- Page 5 Environmental protection and saving energy en 3 Environmental protection and saving energy 3.1 Disposing of packaging When baking multiple dishes, do so in succession or in parallel. The packaging materials are environmentally compat- ¡ The cooking compartment is heated after baking ible and can be recycled. the first dish.
- Page 6 en Familiarising yourself with your appliance 4.2 Buttons and display You can use the buttons to set various functions for your appliance. The display shows the settings. If a function is active, the corresponding symbol lights up in the display. The clock symbol only lights up when you change the time.
- Page 7 Accessories en 4.4 Temperature and setting levels There are different settings for the types of heating and functions. Note: For temperature settings above 250 °C, the appliance reduces the temperature to approx. 240 °C after ap- prox. 10 minutes. If your appliance has the top/bottom heating or bottom heating types, this temperature reduction does not take place there.
- Page 8 You will find a comprehensive range of products for your appliance in our brochures and online: www.junker-home.info Accessories vary from one appliance to another. When Baking tray Slide the tray, e.g. the universal pan, purchasing accessories, always quote the exact E.g.
- Page 9 Before using for the first time en 6 Before using for the first time Configure the settings for initial start-up. Clean the ap- Before heating the appliance, wipe the smooth sur- pliance and accessories. faces in the cooking compartment with a soft, damp cloth.
- Page 10 en Time-setting options Use the function selector to set a suitable type of a When the rapid heating process ends, an audible heating. signal sounds and the heating indicator goes out. Place the food in the cooking compartment. 9 Time-setting options Your appliance has different time-setting options, with Use the button to change the timer duration.
- Page 11 Childproof lock en is highlighted on the display. 9.4 Setting the end time Requirement: Use the or button to delay the end time. ▶ You can set the time at which the cooking time ends, a The appliance applies the change after a few delayed by up to 23 hours and 59 minutes.
- Page 12 en Cleaning and servicing 11 Cleaning and servicing Do not use cleaning products with a high alcohol To keep your appliance working efficiently for a long ▶ content. time, it is important to clean and maintain it carefully. Do not use hard scouring pads or cleaning ▶...
- Page 13 Wet-cleaning aid en Cooking compartment Area Suitable cleaning agents Information Enamel surfaces ¡ Hot soapy water Soak any heavily soiled areas and use a brush or steel wool. Leave the appliance door open to dry the cooking compartment ¡ Vinegar water after cleaning it.
- Page 14 en Shelf supports Clean the smooth surfaces in the cooking compart- 12.2 Post-cleaning the cooking ment with a dish cloth or a soft brush. Remove stub- compartment born food remnants using a stainless steel scouring pad. ATTENTION! Remove limescale with a cloth soaked in vinegar. The prolonged presence of moisture in the cooking Then wipe with clean water and rub dry with a soft compartment leads to corrosion.
- Page 15 Appliance door en Slide the appliance door straight onto the two WARNING ‒ Risk of injury! hinges . Slide the appliance door on as far as it When the hinges are not secured, they can snap will go. shut with great force. Open the appliance door fully. Make sure that the locking levers are always ▶...
- Page 16 en Appliance door Remove the door cover . If necessary, you can remove the condensate trough for cleaning. Open the appliance door. ‒ Tilt the condensate trough upwards and remove ‒ Lift out the inner pane and set it down carefully on a flat surface.
- Page 17 Appliance door en Slide the intermediate pane into the left- and right- Slide the inner pane into the left- and right-hand re- hand retainers . tainers . Push the intermediate pane upwards until it is in the Push the inner pane upwards until it is in the left- left- and right-hand retainers ...
- Page 18 en Troubleshooting 15 Troubleshooting You can rectify minor faults on your appliance yourself. WARNING ‒ Risk of electric shock! Read the troubleshooting information before contacting Incorrect repairs are dangerous. after-sales service. This will avoid unnecessary costs. Repairs to the appliance should only be carried out ▶...
- Page 19 Disposal en Pull out the halogen bulb without turning it . WARNING ‒ Risk of injury! The glass cover may already have broken due to ex- ternal influences or it may break due to excessive pres- sure when being installed or removed. Exercise caution when installing or removing the ▶...
- Page 20 en How it works 18 How it works Here, you can find the ideal settings for various types ¡ The larger the poultry, meat or fish, the lower the of food as well as the best accessories and cookware. cooking temperature and the longer the cooking We have perfectly tailored these recommendations to time.
- Page 21 How it works en 18.4 Food selection Food Accessories/cookware Shelf pos- Type of Temperature Cooking ition heating in °C/grill time in mins setting Sponge cake, delicate Loaf tin 150-170 60-80 Sponge cake, on 2 levels Loaf tin 140-150 70-85 Fruit tart or cheesecake with shortcrust Springform cake tin, 170-190 55-80...
- Page 22 en How it works Recommended settings for yoghurt Food Accessories/cookware Shelf position Type of Temperature in Cooking heating °C time in mins Yoghurt Individual moulds Cooking compartment 1. 100 1. - floor 2. - 2. 8–9 hrs Preheat the appliance. 18.6 Test dishes Shelf positions Shelf positions for baking on two levels: These overviews have been produced for test institutes...
- Page 23 Installation instructions en 19 Installation instructions Observe this information when installing the appliance. 19.1 General installation instructions Follow these instructions before you start with the installation of the appliance. ¡ The safe operation of this appliance can only be guaranteed if it has been installed ¡...
- Page 24 en Installation instructions ¡ To ventilate the appliance, the intermediate floor 19.3 Installation below a worktop must have a ventilation cut-out. Observe the installation dimensions and the installation ¡ In combination with induction hobs, the gap instructions when installing below a worktop. between the worktop and appliance must not be sealed using additional strips.
- Page 25 Installation instructions en ¡ To ensure that the appliance door can be opened, 19.6 Installing two appliances on top of you must take the minimum dimensions into consid- each other eration when installing in a corner. The dimension Your appliance can also be installed above or below is dependent on the thickness of the unit front and another appliance.
- Page 26 en Installation instructions 19.9 Installing the appliance Slide the appliance in fully and centre it. Screw the appliance into place. For handleless kitchens with vertical bar handle strips: Attach a suitable filling piece in order to cover ‒ any sharp edges and to guarantee a safe install- ation.
- Page 28 Valid within Great Britain: Imported to Great Britain by Nobilia GB Ltd. Kingsway Business Park OL16 4UG Rochdale Great Britain *9001658779* BSH Hausgeräte GmbH 9001658779 Carl-Wery-Straße 34 030316 81739 München, GERMANY...
