Summary of Contents for SafeHome CM100-B
- Page 2 Note: Many times throughout this User's Guide, we will refer to Carbon Monoxide as "CO". CM100-B carbon monoxide (CO) alarm is an important part of your family's home safety plan. This alarm has been designed and tested to detect CO level in a residential environment.
- Page 3 warn you of trouble. The way you respond to a CO alarm is quite different than a smoke alarm. That's because a house fire and a CO problem are two distinctly different situations. If your smoke alarm were triggered, you would quickly be able to judge the level of danger you were in with your senses.
- Page 4 WARNING: If the apparatus is tampered with, then there is possible hazards of electric shock or malfunction. 1. INTRODUCTION CM100-B carbon monoxide detector which adopting high quality electrochemical gas sensor and advanced technology, has the advantages of good stability and long life span. The installation method can be ceiling hung and wall mounted.
- Page 5 Model CM100-B is equipped with a digital display that shows levels of CO (displayed in PPM - parts per million). Learn the difference between dangerous, high, mid and low levels. Dangerous Levels: When someone is experiencing symptoms of CO poisoning and CO readings are generally above 100 PPM.
- Page 6 ● Simultaneous operation of several fuel-burning appliances competing for limited internal air. ● Vent pipe connections vibrating loose from clothes dryers, furnaces, or water heaters. ● Obstructions in, or unconventional, vent pipe designs which can amplify the above situations. ● Extended operation of unvented fuel-burning devices (range, oven, fireplace, etc.).
- Page 7 CO alarms should not be used to detect the presence of natural gas (methane), propane, butane, or other combustible fuels. Tell children never to touch, unplug or otherwise interfere with the alarm. Warn children of CO poisoning dangers. 2. SPECIFICATIONS Model CM100-B Working voltage DC9V Working current ≤17uA Alarming current <55mA...
- Page 8 3. FUNCTION AND INDICATION 4. INSTALLATION WARNING: The apparatus should be installed by a competent person. 4.1 Installation position The detector and the fuel using device should be installed inside the same room. If the detector is wall mounted, its height should be higher than any door or window, and at least 150mm to the ceiling.
- Page 9 4.3 Installation rooms Ideally, install one detector in each room where there is fuel using device. If there are more fuel using devices while the detector quantity is limited, please consider the followings to decide the installation position: Please install one detector inside the bedroom which has fuel using device. Please install one detector inside the room where there is a non-chimney or normal chimney fuel using device.
- Page 10 Please choose the suitable wall firstly. Fix M5 screw on the wall with distance of 60mm. The screws should be 3.5mm higher than the wall. Then hang the detector on the wall as the above drawing. 4.5.2 Battery installation First, please tum off the battery cover according to the orient on the above drawing.
- Page 11 with the detecting range of 25~ 500ppm. On the screen, there are gas type "CO" and also unit "PPM". The LCD screen can also be used to display special characters. When the battery voltage is too low, the "L" character is displayed to indicate the current under power state.
- Page 12 5.2.4 Button function When the detector is in monitoring status, press this button, the user can test the equipment functions. All LED flash at the same time and the buzzer gives sound simultaneously. If no light flash or the buzzer does not work, please repair it so as to avoid abnormal alarming.
- Page 13 Note: When the gas concentration detected is lower than 25, the equipment still displays "0" on the screen. When the concentration is higher than 500, the screen still displays "500" on the screen. In above 2 situations, yellow LED flashes once every 16 seconds with the flashing time of 0.3 seconds, and buzzer gives sound for 0.3 seconds at the same time.
- Page 14 CO and protect your life and belongings safety, we strongly suggest you change a new detector when its lifetime over. 9. PACKING LIST CM100-B CO alarm 1 pcs DC 9V Alkaline Battery 1 pcs M5 bolt...
- Page 15 TWO YEARS LIMITED WARRANTY Warranty Coverage: The manufacturer warranties to the original consumer purchaser, that this product (except battery) will be free of defects in material and workmanship for a period of seven (2) years from date of purchase. The manufacturer's liability hereunder is limited to replacement of the product, repair of the product or replacement of the product with repaired product at the discretion of the manufacturer.
- Page 16 IMPORTANT: Do not remove unit back cover. Back cover removal will void warranty. Your Hanwei Carbon Monoxide Alarm is not a substitute for property, disability, life or other insurance of any kind. Appropriate insurance coverage is your responsibility. Consult your insurance agent. Also, Hanwei makes no warranty, express or implied, written or oral, including that of merchantability or fitness for any particular purpose, with respect to the battery.
- Page 17 HANWEI ELECTRONICS GROUP CORPORATION No. 169, Xuesong Road, National Hi-Tech Zone, Zhengzhou 450001, Henan, China Phone: +86 371 67169070/67169080 Fax: +86 371 67169090 E-mail: sales@hwsensor.com Website: www.hwsensor.com...
