Pilz PNOZ 1 24 VAC 3S1O

Emergency Stop Relay and Safety Gate Monitor

w/Screw Terminals

A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .

• C r i t i c a l a n d e x p e d i t e d s e r v i c e s

• I n s t o c k / R e a d y - t o - s h i p

Artisan Scientific Corporation dba Artisan Technology Group is not an affiliate, representative, or authorized distributor for any manufacturer listed herein.

.00

In Stock

Qty Available: 1

Used and in Excellent Condition

Open Web Page

https://www.artisantg.com/85378-1

• We b u y y o u r e x c e s s , u n d e r u t i l i z e d , a n d i d l e e q u i p me n t

• F u l l - s e r v i c e , i n d e p e n d e n t r e p a i r c e n t e r

Need help?

Do you have a question about the PNOZ 1 24 VAC 3S1O and is the answer not in the manual?

Questions and answers

Summary of Contents for Pilz PNOZ 1 24 VAC 3S1O

Page 1 Pilz PNOZ 1 24 VAC 3S1O Emergency Stop Relay and Safety Gate Monitor w/Screw Terminals In Stock Qty Available: 1 Used and in Excellent Condition Open Web Page https://www.artisantg.com/85378-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
Page 2 PNOZ 1 Safety relays Operating Manual-21114-EN-04...
Page 3 Preface This document is the original document. All rights to this documentation are reserved by Pilz GmbH & Co. KG. Copies may be made for the user's internal purposes. Suggestions and comments for improving this documenta- tion will be gratefully received.
Page 4 Contents Introduction ..........................Validity of documentation......................Using the documentation ......................Definition of symbols......................... Safety ............................Intended use ..........................Safety regulations ........................Safety assessment ........................Use of qualified personnel ......................Warranty and liability ........................ Disposal ............................ For your safety .......................... Unit features ...........................
Page 5 PNOZ 1 Introduction Validity of documentation This documentation is valid for the product PNOZ 1. It is valid until new documentation is published. This operating manual explains the function and operation, describes the installation and provides guidelines on how to connect the product. Using the documentation This document is intended for instruction.
Page 6 PNOZ 1 INFORMATION This gives advice on applications and provides information on special fea- tures. Safety Intended use The safety relay PNOZ 1 provides a safety-related interruption of a safety circuit. The safety relay meets the requirements of EN 60947-5-1 and EN 60204-1 and may be used in applications with: E-STOP pushbuttons Safety gates...
Page 7 PNOZ 1 Use of qualified personnel The products may only be assembled, installed, programmed, commissioned, operated, maintained and decommissioned by persons who are competent to do so. A competent person is a qualified and knowledgeable person who, because of their train- ing, experience and current professional activity, has the specialist knowledge required.
Page 8 PNOZ 1 Unit features Positive-guided relay outputs: – 3 safety contacts (N/O), instantaneous – 1 auxiliary contact (N/C), instantaneous Connection options for: – E-STOP pushbutton – Safety gate limit switch – Start button LED display for: – Supply voltage – Switch status of the safety contacts See order reference for unit types Safety features The safety relay meets the following safety requirements:...
Page 9 PNOZ 1 Type: DC : 24 VDC; Order no. 775695 23 33 41 A1 A2 T12 T22 T33 T34 14 24 34 42 *Insulation between the non-marked area and the relay contacts: Basic insulation (over- voltage category III), Protective separation (overvoltage category II) Function Description The safety relay PNOZ 1 provides a safety-oriented interruption of a safety circuit.
Page 10 PNOZ 1 Manual start: Unit is active once the input circuit and the start circuit are closed. Increase in the number of available contacts by connecting contact expandsion modules or external contactors/relays. Timing diagram Legend Power: Supply voltage Start: Start circuit Input: Input circuit Output safe: Safety contacts Output aux: Auxiliary contact...
Page 11 PNOZ 1 Do not connect undesignated terminals. To prevent contact welding, a fuse should be connected before the output contacts (see Technical details [ 14]). Calculation of the max. cable length l in the input circuit: lmax / km = max. overall cable resistance (see Technical details [ 14]) lmax...
Page 12 PNOZ 1 NOTICE With single-channel wiring the safety level of your machine/plant may be lower than the safety level of the unit (see Safety characteristic data [ 23]). Start circuit E-STOP wiring (single-channel, Safety gate (dual-channel) dual-channel) Safety gate (single-channel) Automatic start Automatic start with start-up test Manual start...
Page 13 PNOZ 1 Legend S1/S2: E-STOP/safety gate switch S3: Reset button : Switch operated : Gate open : Gate closed Operation When the relay outputs are switched on, the mechanical contact on the relay cannot be tested automatically. Depending on the operational environment, measures to detect the non-opening of switching elements may be required under some circumstances.
Page 14 PNOZ 1 Dimensions in mm 75 (2.95") 90 (3.54") 87 (3.42") Operating Manual PNOZ 1 | 13 21114-EN-04...
Page 15 PNOZ 1 Technical details Order no. 775600 – 775620 See below for more order numbers General 775600 775620 CCC, CE, EAC (Eurasian), TÜV, CCC, CE, EAC (Eurasian), TÜV, Certifications cULus Listed cULus Listed Electrical data 775600 775620 Supply voltage Voltage 24 V 48 V Kind...
Page 16 PNOZ 1 Relay outputs 775600 775620 Utilisation category of safety con- tacts AC1 at 400 V 400 V Min. current 0,01 A 0,01 A Max. current Max. power 2000 VA 2000 VA AC1 at 240 V 240 V Min. current 0,01 A 0,01 A Max.
Page 17 PNOZ 1 Relay outputs 775600 775620 External contact fuse protection, safety contacts In accordance with the standard EN 60947-5-1 EN 60947-5-1 Max. melting integral 240 A²s 240 A²s Blow-out fuse, quick 10 A 10 A Blow-out fuse, slow Blow-out fuse, gG 10 A 10 A Circuit breaker 24V AC/DC,...
Page 18 PNOZ 1 Environmental data 775600 775620 Ambient temperature Temperature range -10 - 55 °C -10 - 55 °C Storage temperature Temperature range -40 - 85 °C -40 - 85 °C Climatic suitability Humidity 93 % r. h. at 40 °C 93 % r.
Page 19 PNOZ 1 Mechanical data 775600 775620 Dimensions Height 87 mm 87 mm Width 90 mm 90 mm Depth 121 mm 121 mm Weight 500 g 500 g Where standards are undated, the 2020-07 latest editions shall apply. Order no. 775630 -775695 General 775630 775650...
Page 20 PNOZ 1 Inputs 775630 775650 775695 Max. overall cable resist- ance Rlmax Single-channel at UB – – 150 Ohm Single-channel at UB 200 Ohm 200 Ohm – Dual-channel without detection of shorts across contacts at UB – – 250 Ohm Dual-channel without detection of shorts across contacts at UB...
Page 21 PNOZ 1 Relay outputs 775630 775650 775695 Utilisation category of auxiliary contacts AC1 at 240 V 240 V 240 V Min. current 0,01 A 0,01 A 0,01 A Max. current Max. power 2000 VA 2000 VA 2000 VA DC1 at 24 V 24 V 24 V...
Page 22 PNOZ 1 Relay outputs 775630 775650 775695 External contact fuse pro- tection, auxiliary contacts Max. melting integral 240 A²s 240 A²s 240 A²s Blow-out fuse, quick 10 A 10 A 10 A Blow-out fuse, slow Blow-out fuse, gG 10 A 10 A 10 A Circuit breaker 24 V...
Page 23 PNOZ 1 Environmental data 775630 775650 775695 Climatic suitability Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C 93 % r. h. at 40 °C Condensation during op- eration Not permitted Not permitted Not permitted EN 60947-5-1, EN EN 60947-5-1, EN EN 60947-5-1, EN...
Page 24 PNOZ 1 Mechanical data 775630 775650 775695 Stripping length with screw terminals 8 mm 8 mm 8 mm Dimensions Height 87 mm 87 mm 87 mm Width 90 mm 90 mm 90 mm Depth 121 mm 121 mm 121 mm Weight 500 g 500 g...
Page 25 PNOZ 1 Supplementary data CAUTION! It is essential to consider the relay's service life graphs. The relay outputs' safety-related characteristic data is only valid if the values in the service life graphs are met. The PFH value depends on the switch frequency and the load of the relay output. If the service life graphs are not accessible, the stated PFH value can be used irrespective of the switch frequency and the load, as the PFH value already considers the relay's B10d value as well as the failure rates of the other components.
Page 26 European Parliament and of the Council. The complete EC Declaration of Conformity is available on the Internet at www.pilz.com/support/downloads. Representative: Norbert Fröhlich, Pilz GmbH & Co. KG, Felix-Wankel-Str. 2, 73760 Ost- fildern, Germany Operating Manual PNOZ 1...
Page 27 We are represented internationally. Please refer to our homepage www.pilz.com for further details or contact our headquarters. Headquarters: Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: info@pilz.com, Internet: www.pilz.com...
