DTDAUTO AFO4 SCAN Quick Manual

Fault diagnostic scanner & advanced accessory for pgm-fi motorcycle users
Hide thumbs

Advertisement

Quick Links

Download this manual
QUICK GUIDE
AFO4 SCAN
FAULT DIAGNOSTIC SCANNER & ADVANCED ACCESSORY
FOR PGM-FI MOTORCYCLE USERS

Advertisement

loading
Need help?

Need help?

Do you have a question about the AFO4 SCAN and is the answer not in the manual?

Questions and answers

Related Manuals for DTDAUTO AFO4 SCAN

Summary of Contents for DTDAUTO AFO4 SCAN

  • Page 1 QUICK GUIDE AFO4 SCAN FAULT DIAGNOSTIC SCANNER & ADVANCED ACCESSORY FOR PGM-FI MOTORCYCLE USERS...
  • Page 2 Version 2.0 A. INTRODUCTION AFO4 SCAN 2.0 - MOTORCYCLE FAULT DIAGNOSIS SCANNER WITH A CHEAP PRICE, QUALITY, AND DIVERSE PURPOSE OF USE - 2-in-1 product with many functions, special utilities, and diverse business purposes for repairmen - Super-cheap, compact fault diagnosis scanner suitable for individual users, small repair...
  • Page 3 - Actively and optimally calibrate the air-to-air ratio to overcome errors related to Rich/Lean fuel caused by errors inside the ECU such as fuel consumption, engine weakness, needle wear, heavy fuel, inactivity Idling Stop... no need to replace new ECU DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 4 - Identify OBD fault codes, show live engine data, look up and support fast and convenient repairs (you also this accessories can be used as a basic fault reader for HONDA, YAMAHA motorbikes) DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 5 - Weight: 500g - Current consumption: 30mA to 70mA - Operating voltage: 12V - Water resist, light impact and temperature < 100C - Firmware version: 2.0 - Warranty 01 year E. PACKAGE LIST DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 6 Application software installed on phones using Android/iOS operating system The hardware of the accessory installed on the vehicle Update cable used to update hardware (optional extra, not included in standard package) Quick guide DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 7 - Follow the given assembly instructions strictly. The manufacturer is not responsible for improper assembly that causes fire or explosion in the vehicle's wiring. - Use a tin soldering iron to solder the signal wire (TPS – black wire) of the AFO4 SCAN to the TP signal wire on the vehicle.
  • Page 8 Version 2.0 2. ELECTRICAL WIRING DIAGRAM FOR PGM-FI HONDA - Step 1: Turn OFF the ignition key - Step 2: Remove out of the seat, storage box then connect exactly circuit as below diagram. DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 9 Version 2.0 DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 10 Version 2.0 DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 11 Version 2.0 3. ELECTRICAL WIRING DIAGRAM FOR FI YAMAHA DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 12 Version 2.0 DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 13 Version 2.0 DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 14 Version 2.0 DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 15 Version 2.0 DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 16 Version 2.0 4. SPECIAL ATTENTION WHEN INSTALLING THE AFO4 SCAN ON HONDA PGM-FI MOTORCYCLES Connector of HONDA injectors have 02 types are common and special connector (reverse connector), about 90% are common type, only 10% are reverse type. To determine type for connector, you must plug-in AFO connector to vehicle connector same as the image below.
  • Page 17 Special/ reverse connector type of injector  This case, you must invert wires of injector connector on motorbike firstly STEPS REVERT WIRES OF INJECTOR CONNECTOR ON MOTORBIKE Orange/Black wire DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 18 Black/White wire, then replug them into connector - Plug metal latch (4) Black/White wire Black/White wire Injector connector on motorbike after inverted wires Orange/Black wire LIST OF SOME INJECTOR CONNECTOR TYPES FOR HONDA MOTORCYCLES DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 19 Version 2.0 SPECIAL/REVERSE COMMON CONNECTOR VEHICLE MODEL CONNECTOR TYPE OF TYPE OF INJECTOR INJECTOR AIRBLADE CB150R CB300R CB500F CB500X CB650R CBR250 CBR650R CB650F DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 20 Version 2.0 CBR650F CB500X CBR500R CB500F CBR50RR CBR150R CLICK CLICK-i CLICK 125/150 CRF (Thailand) CZi (Thailand) DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 21 Version 2.0 DREAM 110i FORZA FUTURE NEO FI FUTURE X FI FUTURE 125 FI GENIO (2019-2021) LEAD 110/ 125 MONKEY 125i PCX 150/ 160 DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 22 Version 2.0 PCX HYBRID SH 125/150i (Italia) SH 125/150 ESP (Before 2015) SH 125/150 ESP (2016) SH 125/150 ESP (2017-2021) SH 300i SH 300i ABS SH MODE SCR 110 SCOOPY DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 23 Version 2.0 SCOOPY-i SONIC SUPER CUB C125 SUPRA VARIO VISION VISION ESP WAVE RSX FI WAVE RSX FI AT WINNER 150 WINNER X DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 24 G. INSTRUCTIONS FOR INSTALLATION, USING AFO4 SCAN APPLICATION ON PHONE 1. INSTRUCTIONS FOR INSTALLATION, ACTIVATION OF COPYRIGHT OF AFO4 SCAN Step 1: Download and install AFO4 SCAN App# from CH Play or App Store. DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 25 Version 2.0 Step 2: Open AFO4 SCANApp# from icon on the mobile phone's screen: Step 3: Press “Allow” if there is a report asking to turn ON the Bluetooth DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 26 Version 2.0 Step 4: Select language “English” Step 5: Press “ACCEPT” to turn ON allow to my location (obligatory) DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 27 Version 2.0 Step 6: Press “Allow” to AFO4 SCAN access location of device Step 7: Fill in all the information in the fields marked "*", then click the "Update information" button. DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 28 Version 2.0 Step 8: Select the 3 dots icon from main Step 9: Press “Scan” to connect AFO4 screen SCAN hardware DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 29 Version 2.0 Step 10: Turn ON the ignition key on the vehicle DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 30 “AFO210122O10-6” (device code is product code is printed on the product code stamp code) and packaged with the device) - If entering the code fails, please try again or contact DTDAuto for support DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 31 From the next use the application will automatically connect. Step 13: Instructions for initial vehicle installation or changing vehicle type if installing the device to another vehicle. - Select the 3 dots icon from main screen then select "Setting" DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 32 Version 2.0 - Select vehicle market, for example “Vietnam” or other markets - Select the vehicle model (example: Vision 2013-2015) DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 33 (you also this accessories can be used as a basic fault reader for HONDA, YAMAHA motorbikes) Method 1: From the main screen, swipe from right to left at the "DTDAuto" logo position to switch to vehicle monitoring and fault diagnosis mode.
  • Page 34 Version 2.0 DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 35 Version 2.0 DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 36 3. AUTOMATICALLY INTELLIGENTLY OPTIMIZE THE A/F RATIO FROM TIME TO TIME This function is automatic so you don't need to set up any operation on the AFO4 SCAN app# 4. CHANGE FUEL CONSUMPTION AND ENGINE POWER OF PGM-FI VEHICLE IN...
  • Page 37 5. CRUISE CONTROL (Only supported with vehicles that have VSS signal) Step 1: Stop engine, turn ON the ignition key Step 2: Press on “LIMIT” list box then select the desired safe limit speed DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 38 10 meters away from the vehicle). You can turn OFF the "AUTO" button to off this feature in some necessary situations such as lending a vehicle... DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 39 If you are sure you want to turn it off, select "YES". The purpose is to prevent the engine from accidentally shutting down while the vehicle is on the road. DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 40 7. SUPPORT TO TRACKING THE JOURNEY WITH GOOGLE MAP Integrated Google Map to track the journey and navigate on the same smartphone screen Method 1: From the main screen, swipe from right to left at the "DTDAuto" logo position to switch to vehicle monitoring and fault diagnosis mode.
  • Page 41 Version 2.0 8. CHECK PERSONAL INFORMATION, SOFTWARE AND HARDWARE VERSION OF DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 42 Version 2.0 AFO4 SCAN Select the 3 dots icon from main screen then select “Information” You can modify, update more personal information from this section or the "Profile" section. DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 43 Version 2.0 Thanks for your reading, wish you good use of AFO4 SCAN! DTDAUTO Co., Ltd – Edited 24/06/2024 www.dtdauto.com...
  • Page 44 C. FUNCTION ........................3 D. SPECIFICATIONS ....................... 5 E. PACKAGE LIST ......................5 F. INSTRUCTIONS FOR INSTALLING AFO4 SCAN ON VEHICLES ........7 G. INSTRUCTIONS FOR INSTALLATION, USING AFO4 SCAN APPLICATION ON PHONE .......................... 24 H. USE GUIDE FOR FUNCTIONS ................... 33 ___________________________________ DTDAUTO Co., Ltd...
