No.
ACRONYMS
1
MOTOBOX
2
MT006-LINK
3
INPUT
4
OUTPUT
5
VSS Signal
6
CKP (1) Signal
7
CKP (9) Signal
8
CKP (11) Signal
9
MAP Signal
10
TP Signal
11
TA Signal
12
TW Signal
13
O2 Signal
14
IGPLS Signal
15
INJ Signal
16
ON/OFF Signal
17
FLR ON/OFF
18
ODO
19
ODO BOARD
DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020
DEFINITION OF ACRONYMS
DESCRIPTION
Technical data box for motorcycle repair
Signal cable used to transfer data
Input signal of ECM
Ouput signal of ECM
ECM input signal from vehicle speed sensor
ECM input signal from CKP sensor (1 teeth)
ECM input signal from CKP sensor (9 teeths)
ECM input signal from CKP sensor (11 teeths)
ECM input signal from manifold air pressure sensor
ECM input signal from throttle position sensor
ECM input signal from intake air temperature sensor
ECM input signal from engine temperature sensor
ECM input signal from O2 sensor
ECM output signal control ignition coil
ECM output signal control injector
ECM output signal (ON/OFF signal)
ECM output signal control fuel pump (ON/OFF signal)
Odometer
Auxiliary circuit board used for odometer programming
www.dtdauto.com
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MOTOBOX and is the answer not in the manual?

Questions and answers

Summary of Contents for DTDAUTO MOTOBOX

  • Page 1 ECM output signal control injector ON/OFF Signal ECM output signal (ON/OFF signal) FLR ON/OFF ECM output signal control fuel pump (ON/OFF signal) Odometer ODO BOARD Auxiliary circuit board used for odometer programming DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020 www.dtdauto.com...
  • Page 2: Introduction

    ECU, solenoid valve continuous strip, electronic injectors, step motors ... - To solve the problems mentioned above. We are pleased to introduce a new product: MOTOBOX - Model: MT0006 MOTOBOX is the name of an electronically accessory is research, manufacture success in 2015. This is one of application product line advanced science and technology to life by Group Technology DTDAuto, Institute of Physics developed over the years are posted on the website: www.dtdauto.com.
  • Page 3: Equipment Image

    MOTOBOX used for motorcycle repair workshop and professional training vocation to repair, programmable electrical systems in Vietnam and other countries around the world. The product designed beautiful, strong, compact integrated, low cost, suitable for all repair workshops. II. EQUIPMENT IMAGE DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM –...
  • Page 4: Connection Port

    Used to connect to DLC diagnostic connector SIM ADJ. Used to adjust voltage for signal simulation function SIM OUT Output port of simulation signals Used to connect to EEPROM programming board and Odometer DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020 www.dtdauto.com...
  • Page 5: Connection Diagram To Motoscan, Easykey

    Note: Instruction below for MOTOSCAN, you do the same steps for EASYKEY NOTES: You supply power for MOTOBOX after connection with motorcycle is complete Step 1: Select “SPECIAL TEST MODE” menu from main interface of MOTOSCAN then press “Select/ OK” button DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM –...
  • Page 6 Step 2: Select “SIGNAL SIMULATION” menu then press “Select/ OK”, the screen display as below You use “MT0006 – LINK” cable to connect between MOTOBOX and MOTOSCAN as below: DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020 www.dtdauto.com...
  • Page 7 If MOTOSCAN don’t communicate with MOTOBOX or “MT0006-LINK” cable is faulty or communicating between MOTOSCAN and MOTOBOX has been lost synchronization then the screen displays as below: DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020...
  • Page 8 “Select/ OK” button. Example: CKP signal: Step 4: Use “4” or “6” button to increase or decrease value of electric pulse signal. Use knob on MOTOBOX to adjust voltage value of signal. DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020...
  • Page 9 Example: Decrease or increase engine speed Step 5: Use the simulation signals to generate at output of MOTOBOX for diagnosis and ECU repair. You view below image: MAP, TP, TW, TA (0.2÷5VDC/0,5A) IGPLS, INJ CKP, VSS (20VDC/20A) (12VDC/0,1A) DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020...
  • Page 10: Adjust Odometer

    IMPORTANT NOTE: Signals able to operate independently even when still supply power for MOTOBOX and then disconnect “ET0006 - LINK” cable with MOTOSCAN, this time technicians can use MOTOSCAN for other purposes. VI. ADJUST ODOMETER Note: Instruction below for MOTOSCAN, you do the same steps for EASYKEY a.
  • Page 11 You could ignore this report then press “Select/ OK” button to continue because at ODO adjusting function you need not connect MOTOBOX to motorbike that connect to EEPROM. DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020...
  • Page 12 You must choose right motorcycle model. If you select wrong model when you load data, data inside EEPROM will be wrong and is the cause of failed software inside odometer. DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020 www.dtdauto.com...
  • Page 13 Step 6: The screen displays function table. Press “Shift Down” button to select “ODO CORRECTION” function then press “Select/ OK” button. Step 7: The screen display as below: DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020 www.dtdauto.com...
  • Page 14 Use “ET0006 – LINK” cable to connect between MOTOBOX and MOTOSCAN then press “Select/ OK” to continue. DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020 www.dtdauto.com...
  • Page 15 If MOTOSCAN do not communicate with MOTOBOX or “MT0006-LINK” cable is faulty or communicating between MOTOSCAN and MOTOBOX has been lost synchronization then the screen displays as below: If the memory card is faulty or do not have memory card in MOTOBOX then the screen displays as below: You need check memory card then contact to DTDAuto to be supported.
  • Page 16 In case of the screen displays as below, you need contact to DTDAuto to be supported and updated data. Step 8: The screen display IC type of odometer. Example: IC type is 93C66. You must remove dashboard, determine position of weld points on circuit board as guide image at MOTODATA software : DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM –...
  • Page 17 You use solder machine to solder connectors of ODO cable with solder points on circuit board of odometer then press “Select/ OK”. DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020 www.dtdauto.com...
  • Page 18 DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020 www.dtdauto.com...
  • Page 19 Step 9: The screen displays function table. Press “^/v” button to select “CORRECT ODO VALUE” menu then press “Select/ OK” button DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020 www.dtdauto.com...
  • Page 20 You need check the solder connection between auxiliary circuit board (ODO BOARD) and IC, IC plugs and solder pin position of IC. Step 11: If odometer adjustment is successful, the screen will display as below: DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020 www.dtdauto.com...
  • Page 21: Write Odo Origin Data

    “Write original data” function to repair data in odometer - Repeat from step 1 to step 8 of “3.16.2.1 Adjust Odometer” item then select “Write origin data” function and press “Select/ OK” button. DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020 www.dtdauto.com...
  • Page 22: Upgrade Mcu For Ecm Of Honda, Piaggio, Yamaha

    Note: Instruction below for MOTOSCAN, you do the same steps for EASYKEY Step 1: - Use “ET0006 – LINK” cable to connect MOTOBOX and MOTOSCAN - Use DLC cable to connect MOTOBOX and DLC connector on motorcycle DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020 www.dtdauto.com...
  • Page 23 Step 2: Select “Connect to vehicle” menu from the main interface of screen and then press “Select OK”. DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020 www.dtdauto.com...
  • Page 24 Step 5: The screen displays connection guide to motorcycle. You check the connection between DLC cable and DLC diagnostic connector on motorcycle. If your connection is exactly then press “Select/ OK” to continue: DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020 www.dtdauto.com...
  • Page 25 Step 6: The screen displays list of motorcycle models (Example: LEAD 125). Press “Select/ OK” button: Press “Shift Down” button to select “UPGRADE ECM” menu, then press “Select/ OK”. DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020 www.dtdauto.com...
  • Page 26 You ignore this report and press “Select/ OK” to continue because MOTOBOX connected to MOTOSCAN. Step 8: When MOTOBOX connected to ECM of motorcycle, the screen displays software version inside ECM and software version inside MOTOBOX. DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020...
  • Page 27 If software version in MOTOBOX is newer version in ECM of motorcycle then you should update a new version for ECM. If software version in MOTOBOX like as version in ECM of motorcycle that ECM software is faulty then you need update software for ECM.
  • Page 28 ECM so you must check power before program ECM, then press “Select/ OK” to continue. Step 11: The screen displays data loading progress into ECM by percentage: DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020 www.dtdauto.com...
  • Page 29 You check connection and repeat the checking steps. - Disconnect DLC cable between DLC diagnostic connector on motorcycle and MOTOBOX - Reset the supply power for MOTOBOX (unplug power cable for 30 seconds then reconnect) - Turn OFF and turn ON ignition key then reconnect DLC cable NOTES: You turn off and turn on ignition key to have finished upgrading ECM (this is obligatory).
  • Page 30: Table Of Contents

    Address 2: Floor 3, BuildingA25, Institute of Physics / Institute of Science and Technology of Vietnam, No. 18 Hoang Quoc Viet, Hanoi, Vietnam Email: dtdauto@gmail.com Website: http://www.dtdauto.com; http://www.cartools.com.vn; http://www.cartraining.com.vn DTDAUTO TECHNOLOGY TEAM, INSTITUTE OF PHYSICS, VIETNAM – EDITED 23/03/2020 www.dtdauto.com...
