DTDAUTO AFO4 TRIP Quick Manual

Multi-function accessories to customize engine power, fault diagnosis and anti-theft for motorbikes user with mobile phones
Hide thumbs

Advertisement

Quick Links

Download this manual
QUICK GUIDE
AFO4 TRIP
MULTI-FUNCTION ACCESSORIES TO CUSTOMIZE ENGINE POWER,
FAULT DIAGNOSIS AND ANTI-THEFT FOR MOTORBIKES
USER WITH MOBILE PHONES

Advertisement

loading
Need help?

Need help?

Do you have a question about the AFO4 TRIP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DTDAUTO AFO4 TRIP

Summary of Contents for DTDAUTO AFO4 TRIP

  • Page 1 QUICK GUIDE AFO4 TRIP MULTI-FUNCTION ACCESSORIES TO CUSTOMIZE ENGINE POWER, FAULT DIAGNOSIS AND ANTI-THEFT FOR MOTORBIKES USER WITH MOBILE PHONES...
  • Page 2 Version 1.0 A. INTRODUCTION AFO4 TRIP - MULTI-FUNCTION ACCESSORIES TO CUSTOMIZE ENGINE POWER, FAULT DIAGNOSIS, AND ANTI-THEFT FOR MOTORBIKE USERS WITH MOBILE PHONES - Active control online instant engine power right when the vehicle is running on the road by the user on the smartphone.
  • Page 3 - Active control online instant engine power right when the vehicle is running on the road by the user on the smartphone - Optimizing fuel in the most economical mode is still not be out of the weak engine, DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...

  • Page 4: Cruise Control

    (you also this accessories can be used as a basic fault reader for HONDA, YAMAHA motorbikes) 7. SUPPORT TO TRACKING THE JOURNEY WITH GOOGLE MAP Integrated Google Map to track the journey and navigate on the same smartphone screen D. SPECIFICATIONS DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...

  • Page 5: Package List

    - Water resist, light impact and temperature < 100°C - Firmware version: 1.0 - Free update new Firmware version (if released) - Warranty 01 year E. PACKAGE LIST IMAGE DESCRIPTION Application software installed on phones using Android operating system DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 6 The hardware of the accessory installed on the vehicle Update cable used to update hardware (optional extra, not included in standard package) Quick guide F. INSTRUCTIONS FOR INSTALLING AFO4 TRIP ON VEHICLES 1. IMPORTANT NOTES FOR INSTALLATION DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 7 - Follow the given assembly instructions strictly. The manufacturer is not responsible for improper assembly that causes fire or explosion in the vehicle's wiring. - Use a tin soldering iron to solder the signal wire (TPS – black wire) of the AFO4 TRIP to the TP signal wire on the vehicle.
  • Page 8 Version 1.0 diagram. 3. ELECTRICAL WIRING DIAGRAM FOR FI YAMAHA DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 9 Version 1.0 DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 10 Version 1.0 DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 11 Version 1.0 DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 12 Version 1.0 4. SPECIAL ATTENTION WHEN INSTALLING THE AFO4 TRIP ON HONDA PGM-FI MOTORCYCLES Connector of HONDA injectors have 02 types are common and special connector (reverse connector), about 90% are common type, only 10% are reverse type. To determine type for connector, you must plug-in AFO connector to vehicle connector same as the image below.
  • Page 13 STEPS REVERT WIRES OF INJECTOR CONNECTOR ON MOTORBIKE Orange/Black wire Injector connector on motorbike before revert Black/White wire Orange/Black wire Use clamp to remove metal latch wires injector connector motorcycle Black/White wire DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 14 Injector connector on motorbike after inverted wires Orange/Black wire LIST OF SOME INJECTOR CONNECTOR TYPES FOR HONDA MOTORCYCLES SPECIAL/REVERSE COMMON CONNECTOR VEHICLE MODEL CONNECTOR TYPE OF TYPE OF INJECTOR INJECTOR AIRBLADE CB150R CB300R DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 15 Version 1.0 CB500F CB500X CB650R CBR250 CBR650R CB650F CBR650F CB500X CBR500R CB500F CBR50RR DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 16 Version 1.0 CBR150R CLICK CLICK-i CLICK 125/150 CRF (Thailand) CZi (Thailand) DREAM 110i FORZA FUTURE NEO FI FUTURE X FI FUTURE 125 FI DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 17 Version 1.0 GENIO (2019-2021) LEAD 110/ 125 MONKEY 125i PCX 150/ 160 PCX HYBRID SH 125/150i (Italia) SH 125/150 ESP (Before 2015) SH 125/150 ESP (2016) DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 18 Version 1.0 SH 125/150 ESP (2017-2021) SH 300i SH 300i ABS SH MODE SCR 110 SCOOPY SCOOPY-i SONIC SUPER CUB C125 SUPRA VARIO DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 19 Version 1.0 VISION VISION ESP WAVE RSX FI WAVE RSX FI AT WINNER 150 WINNER X WAVE 110i WAVE 125 (Thailand) WAVE 125i X-ADV ZOOMER DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...

  • Page 20: Complete The Installation

    APPLICATION ON PHONE 1. INSTRUCTIONS FOR INSTALLATION, ACTIVATION OF COPYRIGHT OF AFO4 TRIP Step 1: Download and install AFO4 TRIP App# from CH Play or App Store. Step 2: Open AFO4 TRIP App# from icon on the mobile phone's screen: Step 3: Press “Allow”...
  • Page 21 Version 1.0 Step 4: Select language “Việt Nam” or Step 5: Press “ACCEPT” to turn ON “English” allow to my location (obligatory) DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 22 Version 1.0 Step 6: Press “Allow” to AFO4 TRIP access location of device Step 7: Fill in all the information in the fields marked "*", then click the "Update information" button. DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 23 Version 1.0 Step 8: Select the 3 dots icon from Step 9: Press “Scan” to connect AFO4 main screen TRIP hardware DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 24 Version 1.0 Step 10: Turn ON the ignition key on the vehicle DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 25 Step 11: Select device to connect, Step 12: Enter the verification code example: “AFO210122O10-6” (device (The code is printed on the product code code is product code) stamp and packaged with the device) DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 26 Version 1.0 - If entering the code fails, please try again or contact DTDAuto for support - If the activation and connection is successful then the Bluetooth icon will be blue as below: Note: Entering the verification code is only done the first time the application is connected to the vehicle.
  • Page 27 Version 1.0 - Select the 3 dots icon from main screen then select "Setting" - Select vehicle market, for example “Vietnam” or other markets - Select the vehicle model (example: Vision 2013-2015) DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 28 2. AUTOMATICALLY INTELLIGENTLY OPTIMIZE THE A/F RATIO FROM TIME TO TIME This function is automatic so you don't need to set up any operation on the AFO4 TRIP app# 3. CHANGE FUEL CONSUMPTION AND ENGINE POWER OF PGM-FI VEHICLE IN...
  • Page 29 4. CRUISE CONTROL (Only supported with vehicles that have VSS signal) Step 1: Stop engine, turn ON the ignition key Step 2: Press on “LIMIT” list box then select the desired safe limit speed 5. SUPPORT ANTI-THEFT FUNCTION DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 30 If you are sure you want to turn it off, select "YES". The purpose is to prevent the engine from accidentally shutting down while the vehicle is on the road. DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 31 (you also this accessories can be used as a basic fault reader for HONDA, YAMAHA motorbikes) Method 1: From the main screen, swipe from right to left at the "DTDAuto" logo position to switch to vehicle monitoring and fault diagnosis mode.
  • Page 32 Version 1.0 DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 33 Version 1.0 DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 34 7. SUPPORT TO TRACKING THE JOURNEY WITH GOOGLE MAP Integrated Google Map to track the journey and navigate on the same smartphone screen Method 1: From the main screen, swipe from right to left at the "DTDAuto" logo position to switch to vehicle monitoring and fault diagnosis mode.
  • Page 35 Version 1.0 8. CHECK PERSONAL INFORMATION, SOFTWARE AND HARDWARE VERSION OF DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 36 Version 1.0 AFO4 TRIP Select the 3 dots icon from main screen then select “Information” You can modify, update more personal information from this section or the "Profile" section. DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
  • Page 37 Version 1.0 Thanks for your reading, wish you good use of AFO4 TRIP! INDEX A. INTRODUCTION ....................2 B. APPLICATION ....................... 3 C. FUNCTION ......................3 D. SPECIFICATIONS ....................4 E. PACKAGE LIST ...................... 5 F. INSTRUCTIONS FOR INSTALLING AFO4 TRIP ON VEHICLES ......... 6 G.
  • Page 38 Version 1.0 Email: dtdauto@gmail.com Website: http://www.dtdauto.com DTDAUTO VIETNAM Co., Ltd – Edited 22/06/2022 www.dtdauto.com...
