Oryx sca3600 Repair Manual

Hide thumbs Also See for sca3600:

Advertisement

Quick Links

Download this manual
sca
3600
Repair Manual
Oryx Additive Inc.
7755 S. Research Drive Tempe Ste. 120
Tempe, AZ 85284
1.833.817.3533
www.OryxAdditive.com
info@OryxAdditive.com
support@OryxAdditive.com
Rev 2.0
December 30, 2024
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the sca3600 and is the answer not in the manual?

Questions and answers

Related Manuals for Oryx sca3600

Summary of Contents for Oryx sca3600

  • Page 1 3600 Repair Manual Oryx Additive Inc. 7755 S. Research Drive Tempe Ste. 120 Tempe, AZ 85284 1.833.817.3533 www.OryxAdditive.com info@OryxAdditive.com support@OryxAdditive.com Rev 2.0 December 30, 2024...
  • Page 2 This page intentionally left blank...
  • Page 3 Table of Contents I. PRELIMINARY STEPS ..................- 5 - II. QUICK TROUBLESHOOTING................- 6 - III. REMOVING TOP COVER AND BACK PANEL ............- 10 - A. H ..................... - 10 - OW TO EMOVE THE ANEL B. H ......................
  • Page 4 C. T ................... - 35 - EMPERATURE ENSOR ROUBLESHOOTING D. W ................... - 38 - ATER EVEL ENSOR ROUBLESHOOTING E. N SCA T ....................- 40 - OWER TO ROUBLESHOOTING XIII. DOCUMENTATION ..................- 46 - A. E ..........................- 46 - RROR ODES B.
  • Page 5 I.PRELIMINARY STEPS Follow these steps before attempting to service the SCA Power off and disconnect the SCA from the main power. Allow the SCA to cool completely. Attach a hose to the front valve and drain the tank completely. Always disconnect the SCA from the main power and drain the tank completely before servicing.
  • Page 6 The 3600 Repair Manual can be found on our website at https://www.oryxadditive.com/products/sca3600. Please check if a newer version is available. If a resolution is not found, please contact Technical Support at support@oryxadditive.com or call 1.833.817.3533.
  • Page 7 Problem Possible Causes What to Do Pump will not start Control Panel has a Reseat the J6 ribbon cable connector on the PCB (See Pump Troubleshooting Section loose connection XII A). Defective Run Check the capacitance of the Run Capacitor (See Pump Troubleshooting Section XII Capacitor Defective Pump Check the resistance of the Pump and the mechanical rotation of the Pump Shaft (See...
  • Page 8 Problem Possible Causes What to Do Bath heats up but Heater Element is Check the resistance of the Heater Elements (See Heater Troubleshooting Section XII does not reach the defective Set Temperature or Temperature Sensor The Control Panel detects the current temperature of the bath through the takes a long time to defective Temperature Sensor and displays it on the Control Panel.
  • Page 9 Problem Possible Causes What to Do Alarm is sounding Loose Control Panel Reseat the J6 Control Panel connector on the PCB (See No Power to SCA Error Code ribbon cable Troubleshooting Section XII E). Displayed: Defective DC Power Check the DC voltage between TP10 and TP12 (See No Power to SCA 12V DC Out of Range Supply on the PCB Troubleshooting Section XII E).
  • Page 10 III. REMOVING TOP COVER AND BACK PANEL A. How to Remove the Back Panel 1. Remove the Back Panel With the SCA unplugged from power, remove the two screws from the top center and bottom center of the Back Panel (See Figure 1). b.
  • Page 11 B. How to Remove the Top Cover 1. Remove the Top Cover With the SCA unplugged from power, remove the J6 Control Panel ribbon cable from the PCB (See Figure 2). b. Remove the three M5 screws. Remove the cover by pushing lightly on the back of the cover and pull off, carefully pulling the J6 ribbon cable through the Bridge Slot.
  • Page 12 IV. PUMP ASSEMBLY REPLACEMENT A. How to remove the Pump Assembly 1. Remove the Pump Assembly Unplug the SCA from power and remove the Back Panel (See How to Remove the Back Panel Section III A). b. Remove the Top Cover (See How to Remove the Top Cover Section III B). Disconnect the Pump Motor connector from the PCB Assembly (See Figure 3).
  • Page 13 Remove the four M5 screws holding the Pump Assembly and ground wire (See Figure 4). h. Grip the Pump Assembly by the motor and carefully guide the Pump Assembly through the hole in the Bridge. NOTE Motor Gasket The tray gasket may cause the pump assembly to stick to the bridge.
  • Page 14 V. SENSOR ASSEMBLY REPLACEMENT A. How to Remove the Sensor Assembly 1. Remove the Sensor Assembly Remove the Back Panel (See How to Remove the Back Panel Section III A). b. Remove the Top Cover (See How to Remove the Top Cover Section III B). Unplug the three sensor connectors from the PCB (See Figure 5).
  • Page 15 d. Remove the four M5 screws holding the Sensor Assembly (See Figure 6). Carefully pull the sensor wires through the Bridge Slot. Remove the Sensor Assembly from SCA. A Flat Head screwdriver may be used to pry up the Sensor Assembly from the tray if it sticks.
  • Page 16 B. How to install the Sensor Assembly 1. Install the Sensor Assembly Insert the Sensor Assembly into the Motor Tray. b. Mount the Sensor Assembly using the four M5 screws. Carefully thread sensor wires through the Bridge. d. Plug in the 3 sensor connectors into the appropriate slots on the PCB. Plug in the J6 ribbon cable back into the PCB.
  • Page 17 VI. SPRAY NOZZLE REPLACEMENT A. How to Replace the Nozzle 1. Replace the Nozzle The 3600 has a Bayonet Style Nozzle that latches on to the outlet of the Pump. Twist the Nozzle counterclockwise to unlatch (See Figure 8). b. Ensure the Nozzle is orientated correctly (See Figure 9). Twist the Nozzle clockwise to latch. Ensure the O-Ring is in place, or the Nozzle will not latch correctly.
  • Page 18 VII. HEATER ASSEMBLY REPLACEMENT A. How to Remove the Heater Assembly 1. Remove the Heater Assembly Unplug the SCA from power and remove the Back Panel (See How to Remove the Back Panel Section III A). b. Remove the Top Cover (See How to Remove the Top Cover Section III B). SHOCK HAZARD! PLEASE ENSURE POWER PLUG IS REMOVED FROM THE SCA.
  • Page 19 ALLOW THE HEATING ELEMENT FOR COMPLETELY COOL BEFORE REMOVING. Carefully remove the Heater Assembly from SCA. M5 Screws (4 places) Figure 11 – Top View of the SCA with the Top Cover Removed Figure 12 – Remove the Heater Assembly...
  • Page 20 B. How to Install the Heater Assembly 1. Install the Heater Assembly Carefully guide the Heater Assembly through the hole in the Bridge until the plate is seated on the gasket on top of the Bridge. b. Mount the Heater Assembly to the Bridge using the four M5 mounting screws and attach the ground wire to the tray.
  • Page 21 VIII. DISPLAY CONTROL PANEL REPLACEMENT A. How to Remove the Display Control Panel 1. Remove the Display Control Panel Unplug the SCA from power and remove the Back Panel (See How to Remove the Back Panel Section III A). b. Remove the Top Cover (See How to Remove the Top Cover Section III B). Disconnect the J6 Control Panel ribbon cable from the PCB.
  • Page 22 VIIII. PCB ASSEMBLY REPLACEMENT A. How to Remove the PCB Assembly 1. Remove the PCB Assembly Remove Back Panel (See How to Remove the Back Panel Section III A). b. Check the wires to make sure the labels are on the wires connected to the PCB. Remove all the wire connectors from the PCB, be careful not to rip off a wire label.
  • Page 23 X. POWER SWITCH REPLACEMENT A. How to Remove the Power Entry Module (PEM) Switch 1. Remove the PEM Remove the Back panel (See How to Remove the Back Panel Section III A). b. Disconnect the PEM wire connectors from the fuse terminals. PEM connections Figure 16 –...
  • Page 24 XI. FUSE REPLACEMENT A. How to Replace the Fuses 1. Replace the F1/F2 Fuse Remove the Back Panel (See How to Remove the Back Panel Section III A). b. Pry the fuse out of the clips. A small flathead screwdriver can help. Pry closer to the metal ends. Replace the damaged fuse with a new fuse of the same rating.
  • Page 25 XII. TROUBLESHOOTING STEPS NOTE: The symbol “ ” prefixing the measured value denotes “approximate”. Most measurements will not be completely accurate with the values represented in this manual, but the SCA will function normally. Usually, measurements that are extremely different from the indicated measurements will represent a possible failure in the component.
  • Page 26 A. Pump Troubleshooting Symptom Pump Not Starting, Pump Starting but has Low Circulation Theory: The Water Pump uses a 230 VAC motor that circulates the water from the intake at the bottom of the Pump out through the Nozzle using an impeller attached to the Motor Shaft. The Run Capacitor gives the Pump an initial punch to rotate the Pump Motor Shaft in the proper direction as well as supply half the voltage to the Pump.
  • Page 27 Unplug the SCA from power and reseat (unplug and plug back in) the J6 “CONTROLLER” ribbon cable (See Figure 20). The latch must be released to remove the ribbon cable. Press the latch with a thumbnail and wiggle the connector out of the slot. Plug the ribbon connector back into the PCB slot and ensure it snaps securely.
  • Page 28 2. Check the Pump Motor Resistance Unplug the SCA from power and remove the “PUMP” connector from the PCB. Choose the Resistance Selection Ω on the multimeter. Check the resistance of the Pump between pins 1 and 3 (See Figure 22). If the multimeter reads ~ Ω, continue to the next step (Step b).
  • Page 29 3. Test the Input Voltage to the Pump a. With the SCA still unplugged from power and the “PUMP” disconnected from the PCB, place one lead of the multimeter Test Hooks to pin 1 and the other Test Hook to pin 3 on the PCB connector. Set the multimeter to the AC Voltage Selection .
  • Page 30 If there is no voltage between pins 1 and 3 and pins 2 and 4 and the “PUMP ON” LED is lit, replace the PCB. d. If there is voltage between pins 1 and 3, and no voltage between pins 2 and 4, the Run Capacitor may be defective.
  • Page 31 Rotate the Pump Shaft (See Figure 28). The shaft should rotate extremely easily and smoothly by rolling a finger across it. There should be no stiffness, rough spots or binds. If there is stiffness or it feels bound, inspect around the Impeller for any obvious buildup that can bind up the Impeller. To thoroughly inspect for any build up around the Impeller, the Manifold Plate can be removed (seven screws).
  • Page 32 B. Heater Troubleshooting Symptom Not Heating, Not Reaching the Set Temperature, EO Over Temperature Error Theory: The Heating Elements have an internal resistance that create heat when current flows through. When submerged in water, the heat is transferred to the water. It should take approximately 3 minutes per degree to heat up the bath.
  • Page 33 d. Unplug the SCA from power and reseat (unplug and plug back in) the J6 “CONTROLLER” ribbon cable (See Figure 30). The latch must be released to remove the ribbon cable. Press the latch with a thumbnail and wiggle the connector out of the slot. Plug the ribbon connector back into the PCB slot and ensure it snaps securely. Power on the SCA and press the Start Button If the “HEATER ON”...
  • Page 34 2. Heater Element Resistance Test If the “HEATER ON” LED is lit, and the SCA is not heating up properly or not at all, unplug power from the SCA. b. Remove the “Heater Element 1” Connector. Set the multimeter to the Resistance Selection Ω. Measure the resistance across the outside wires of the Heater 1 Connector (See Figure 32).
  • Page 35 C. Temperature Sensor Troubleshooting Symptom Not Heating, Inconsistent Heating, Not Reaching the Set Temperature, Over Heating r1 Error Theory: The Temperature Sensor changes resistance according to the temperature of the water. As the temperature increases, the resistance of the sensor decreases. The Control Panel uses this resistance to determine the temperature of the bath.
  • Page 36 Steps: 1. Reseat the Connectors Unplug the SCA from power and remove the Back Panel (See How to Remove the Back Panel Section III A). b. Reseat (unplug and plug back in) the NTC Connector on the PCB. The NTC Connector has a latch that must be depressed to unlock the connector from the slot.
  • Page 37 3. Check the resistance at 50°C A thermometer with a Celsius selection can be used to determine whether the temperature of the bath is displayed correctly on the Control Panel. Set the SCA to 50°C and press the Start Button .
  • Page 38 D. Water Level Sensor Troubleshooting Symptom High or Low Water LED Flashing on the Control Panel, r2, r3 Error Theory: The Water Level Sensor uses two internal switches within a hollow rod straddled by a watertight stainless-steel float that slides along the rod as the water level changes. If the water level is at the minimum or maximum level, the magnetic property of the float closes an internal switch, which generates an error.
  • Page 39 2. Check the resistance of the Water Level Sensor Remove the sensor from the Motor Tray (See Sensor Assembly Replacement Section V). b. Visually inspect the Water Level Sensor Assembly. If there is a buildup on the shaft that inhibits the free up and down motion of the float, clean off the buildup.
  • Page 40 E. No Power to SCA Troubleshooting Symptom SCA Appears to have no Power Theory: The SCA 3600 requires 230VAC +/- 10% single phase power. The acceptable voltages for this SCA are 207 VAC → 253 VAC. The U.S. generally uses 208 VAC, but a voltage of 220 VAC is not uncommon. The EU generally uses a voltage of 230 VAC.
  • Page 41 b. Set the multimeter to the AC Voltage Selection and check the voltage at the building’s outlet between the Y and X sockets (North America) or the N and L socket (Europe) (See Figure 44). If the multimeter reads ~ VAC (NA) or ~ VAC (EU), ensure the power cord is securely inserted into the outlet and check for voltage at the female end of the power cord (between the two top slots).
  • Page 42 d. Unplug the SCA from power and reseat the J6 Control Panel ribbon cable. Press the latch with a thumbnail (See Figure 46) and wiggle the connector out of the slot. Press the connector firmly back into the slot and ensure it snaps in securely.
  • Page 43 d. Unplug the SCA from power. Set the multimeter to Diode Test Mode Check the continuity of fuses FB1 and FB2 (See Figure 48). If the multimeter reads ~ , the fuses are good, replace the PCB. If the multimeter reads , replace the fuse.
  • Page 44 b. The TCO can trip (open) if the temperature of the bath exceeds 90°C. This removes all incoming power to the PCB. Press the red square button in the middle of the TCO (ensure the SCA is unplugged from power and the temperature of the bath is less than 80°C).
  • Page 45 d. Insert one multimeter lead into the wire terminal connected to the input of fuse F1 and touch the other lead to the left prong of the PEM. Toggle the power switch to the “On” position (left). • If the multimeter reads (continuous), continue to the next step.
  • Page 46 XIII. DOCUMENTATION A. Error Codes 12VDC out of range, (See No Power to Display Troubleshooting Section XII E). power supply error for the display Over temperature The temperature of water exceeds set temperature by more than 5 degrees Celsius. This can be caused by an exothermic reaction to soluble cleaning solutions.
  • Page 47 B. Schematics Physical Layout of PCB...
  • Page 48 Electronic Schematics...
  • Page 49 C. PCB Layout Heater Heater WLS-L Element 1 Element 2 Control Temperature Low Water Panel Sensor Sensor Heater Relay WLS-H Pin 1 High Water Sensor Input Speaker Power HEATER ON LED 2A Fuse 2A Fuse DC OK Pump Motor TP10 (Ground) TP12 (12VDC)
  • Page 50 D. J6 Control Panel Pinout • Low → ~0V DC • High → ~12V DC J6 Control Panel Connector Description High Water Level High Sensing Water Level Low Sensing Temperature Sensing Display VCC ~12V DC Power Off Power On Unused Unused Unused Heater Control...
  • Page 51 DRAIN VALVE 100508 DRAIN STRAINER ASSEMBLY, W/HANDLE 100127 NOZZLE, SINGLE SLOT, W/GASKET, 100130 PUMP STRAINER COVER 100126 HEATER ASSEMBLY, SCA3600, 220VAC 100007 PUMP SUBASSEMBLY REPAIR KIT 100006 RH TUB LID, SCA3600 100022 LH TUB LID, SCA3600 100021 SMALL PART BASKET, 4"X4"X4"...
  • Page 52 F. Specifications Model Number SCA 3600 Grounded Electrical Outlet Within 6ft (2m) of the SCA Power Requirements 230VAC +/- 10%, 50/60 Hz, 20A, 3400W CE, cTUVus, RCM, RoHS, WEEE Regulatory Compliance 27 gal (102 L) Tank Capacity 36.5 22.8 42.8 92.7 57.8 108.6...
  • Page 53 G. Technical Support Technical support for this product is provided by Oryx Additive, Inc. Before contacting Technical Support, please do the following: 1. Try the Quick Troubleshooting table at the beginning of this manual. 2. View the Troubleshooting Steps in this manual. This manual can also be found at www.oryxadditive.com/support.
  • Page 54 SCA 3600 Support Cleaning Apparatus Limited Warranty Product Limited Warranty Period SCA 3600 Support Cleaning Apparatus 1 year All new Support Cleaning Apparatus (SCA) systems are warranted exclusively by Oryx Additive, Inc.’s (“Manufacturer”) limited warranty as follows: Each Support Cleaning Apparatus system (“System”)
