- Page 1 Solidcom SE Quick Guide V1.0...
- Page 3 Foreword Solidcom SE Thank you for choosing the for on-site communication. If you have never used a wireless intercom system before, then you are about to experience one of the most exciting products in the industry. This Quick Guide will show you how to get started with the product.
- Page 4 Configuration Master Headset (Brown) Remote Headset (Black) 6-Slot Charging Base Li-ion Battery Pack 770 USB-A to USB-C Cable Number Stickers 01 Quick Guide & Packing Warranty Card & Carrying Case List Card Compliance Information Note: The quantity of the items depends on the product configuration detailed on the packing list card.
- Page 5 Overview Speaker Volume + Button Battery (Long press for 5s to Compartment enter pairing mode) Battery Compartment Button Microphone Hole (only for environmental TALK/MUTE Button sound) (Single press to switch status; long press to enable PTT function) Volume - Button USB-C Port (for firmware upgrade and audio output)
- Page 6 Overview Indicator Introduction Indicator Disconnected*: slowly flashing green light Pairing: rapidly flashing green light TALK Status: solid green light MUTE Status: solid red light Low Battery: slowly flashing red light USB-C Charging： A. Charging While Powered On: slowly flashing yellow light for 3s before returning to the former light B.
- Page 7 Operations Installing and removing the battery Place the battery into the battery Press the battery compartment button to compartment for installation. pop out the battery for removal. Turning on the device and confirming connection Headband Connection Indicator Power Switch 1. Toggle the power switch to turn on the headsets. 2.
- Page 8 Operations Turning on the microphone MUTE MUTE TALK TALK TALK TALK 85° 85° 85° 85° 110° 110° TALK TALK Clockwise Counterclockwise Beginning your work Headset Pairing All remote headsets are prepaired with the master headset at the factory, so they are ready to use upon poweron.
- Page 9 Specifications Product Name Solidcom SE Single-Ear Headset LOS Range 1,100ft (350m) Operating Frequency 2.4 GHz Modulation Mode GFSK Transmit Power ≤ 20dBm Receiver Sensitivity -92 dBm Battery Capacity 770 mAH (2.926Wh) Charging Time < 3 hours Frequency Response 150 Hz - 7 kHz (±10dB) >70dB @94dBSPL, 1kHz...
- Page 10 Specifications Product Name 6-Slot Charging Base Port USB-C Port; Charging Contacts Dimensions 119.3 × 57.6 × 34.6mm (4.7 × 2.3 × 1.4in.) Weight 91.1g Charging Power ≤ 10W Power Supply 4.75 - 5.25V Charging Current ≤ 380mA/Slot Charging Time < 3 hours (6 batteries) 0 - 45℃...
- Page 11 Statement: All copyrights belong to Shenzhen Hollyland Technology Co., Ltd. Without the written approval of Shenzhen Hollyland Technology Co., Ltd., no organization or individual may copy or reproduce part or all of any written or illustrative content and disseminate it in any form.
- Page 12 Manufacturer: Shenzhen Hollyland Technology Co., Ltd. Address: 8F, 5D Building, Skyworth Innovation Valley, Tangtou Road, Shiyan Street, Baoan District, Shenzhen, 518108, China P/N:3003080632 MADE IN CHINA...
