Summary of Contents for Hollyland Solidcom C1 HUB8S
- Page 1 Hollyland Solidcom C1 HUB8S Quick Guide V2.0.0...
-
Page 2: Product Interfaces
Product Interfaces HUB Base Interfaces ①➀ HUB Headset Volume Knob ⑪➀ USB Interface ②➀ Display ⑫➀ ANNOUNCE Button - Press and hold the ③➀ UP Arrow Key button while making an ANNOUNCE, release the button when finished ④➀ LEFT Arrow Key ⑬➀... - Page 3 Quick Start Guide Set Up HUB Base Install the HUB antennas. Power Up HUB Base Connect the 12V/2A DC Adapter to the Press the Power Switch to turn on. HUB base. Note: The HUB Base can be powered using NP-F battery, V-Mount/G-Mount battery, or DC power supply.
- Page 4 Quick Start Guide Headset Status Indicator ①➀ FLASH GREEN: Headset disconnected ②➀ STATIC GREEN: Headset connection successful ③➀ FLASH RED: Low battery, please change the battery Pairing Operation The HUB Base and Remote Headsets that come in one system package will auto pair up right out of box.
- Page 5 Quick Start Guide Headset(s) Number Setting via HUB Base When re-pairing and numbering the headset, be sure to turn on all the headsets to avoid selecting duplicate numbers, which may lead to connection failure with other headsets. In case of wrong numbering of a headset, simply connect it to the HUB with the USB cable and operate the pairing and numbering process again.
- Page 6 Quick Start Guide 4 Wire Settings After connecting the two systems with the network cable, configure each HUB Base’s line sequence by entering "4 Wire Settings" and selecting "Line sequence switching". Set the first HUB Base to “Standard mode” and the second HUB Base to “Cross mode”. HUB Display Interfaces Enter "4 Wire"...
- Page 7 Quick Start Guide HUB Settings After connecting the two systems with the network cable, configure each HUB Base’s basic settings as Master or Slave device. Generally, the first system is set as Master Device, and the second one as Slave Device. In this case, you need to turn OFF the “Obtain IP address automatically”...
- Page 8 Quick Start Guide Group Settings The HUB Base supports A and B grouping settings. You can view the system’s current group setting by entering the Group menu on the HUB. To operate group settings, connect the computer and the HUB via the RJ45 interface using the network cable, and enter the Group settings menu. Or download the Solidcom APP on the mobile phone and connect to the HUB through WiFi to access the Group settings menu.
- Page 9 Quick Start Guide Open the browser on the computer and visit http://192.168.218.10 to enter the configuration page of the HUB. A & B Group Buttons on Headset(s) After entering Group setting on the HUB, the A and B Buttons on the connected headset will light up.
- Page 10 Parameters 350m (1000ft) Line-of-Sight Range Frequency band: 1.9GHz DECT (varies by country and region) Modulation mode: GFSK Frequency Information Transmit power: <21dBm (125.9mW) (varies by country and region) Receiving sensitivity: <-90dBm Transmission Latency <35ms Battery Capacity 700mAh (2.66Wh) Li-Ion battery Headset Runtime Remote headset: ≈10h Charging Time...
- Page 11 The use of non-original spare parts may cause electric shock, fire, explosion or other dangers. Support If you encounter any problems in using the product or need any help, please contact Hollyland Support Team via the following ways: If encounter any problems in using the product or need any help, please follow these ways to get...
- Page 12 All copyrights belong to Shenzhen Hollyland Technology Co., LTD. Trademark Statement: Without the written approval of Shenzhen Hollyland Technology Co., LTD, no organization or individual may copy or reproduce part or all of the content of the text without authorization, and may not disseminate it in any form.
