Flipo SPIN GEAR Instruction Manual

SPIN GEAR™
STUNT RC CAR | Instruction Manual
Please read this instruction manual carefully before using.
• For Ages 3+
• Adult guidance is strongly recommended.
CONTENTS
1 x Spin Gear Stunt Car
1 x Remote Control
1 x USB Charging Cable
1 x Rechargeable Battery
FIGURE A
Forward
Front Axel
Drive
Spins Left
Front Axel
Backward
Spins Right
Drive
BATTERY INSTALLATION & CHARGING
Remote Control
1. Loosen the lock screw located on the rear of your remote control until it stops. Lock screw is not fully
removable for safety. Remove the battery compartment cover by lifting the integrated screw tab.
2. Insert two AA batteries according to the polarity graphic located in the compartment; make sure the (+)
and (-) poles of each battery are positioned correctly.
3. Replace the battery compartment cover and tighten screw completely to lock in place.
Spin Gear Car
1. Loosen the lock screw located on the underside of your Spin Gear until it stops. Lock screw is not fully
removable for safety. Remove the battery compartment lid by pushing the integrated safety tab in the
direction of the "Open" arrow.
2. Remove rechargeable battery from the battery compartment, depress battery connector safety lock,
and separate wire connectors.
3. Plug the USB charging cable into a USB port, or a USB AC adapter and insert the adapter into an
electrical outlet.
4. Connect the battery connector to the connector on the USB cable. The red light on the charging cable
will light when charging. When batteries are fully charged, the light will turn OFF.
5. When battery is fully charged, disconnect the battery connector from the USB charging cable, and
unplug the cable from the power source.
6. Reconnect battery to the battery cable in the battery compartment, reinsert battery, replace battery
compartment cover, and tighten the screw.
OPERATION
1. The Spin Gear is activated by moving the black toggle switch located on the bottom rear of the vehicle
to the ON position. To deactivate, move the switch to the OFF position. When first turned ON the blue lights
in the car will illuminate. Note: The remote control will automatically be linked to the Spin Gear when the
car is turned ON.
2. Drive the car by operating the joysticks on your remote control (Figure A).
SPINNING STUNT MOVES – Your Spin Gear is capable of any number of spins, turns, wheelies and other
stunts. To do so, simply move your car backward or forwards with the left joystick, while also using the right
joystick of the remote to make the front axle twist. Different combinations of pushing these buttons will
create different stunts.(Figure B)
FIGURE B
Wheelie Stunt
Wheelie Stunt
