Toro 127-6650 Installation Instructions

Anti-Scalp and Wear Bar Kit
Zero-Turn-Radius Rear-Discharge Riding Mower
Model No. 127-6650
This product contains a chemical or chemicals known to the State of California to
Note: Determine the left and right sides of the machine
from the normal operating position.
Installation
Loose Parts
Use the chart below to verify that all parts have been shipped.
Description
Left-hand roller bracket
Right-hand roller bracket
Left-hand bumper
Right-hand bumper
Anti-scalp roller
Spacer
Bolt (3/8 x 5 inches)
Bolt (3/8 x 1-1/8 inches)
Carriage bolt (3/8 x 1-1/8 inches)
Carriage bolt (3/8 x 1-1/4 inches)
Flange nut (3/8 inch)
Installing the Anti-Scalp
Rollers
1. Disengage the blade control switch (PTO), move the
motion-control levers to the neutral-locked position,
and set the parking brake.
2. Stop the engine, remove the key, and wait for all moving
parts to stop before leaving the operating position.
3. Raise the mower deck to the transport position.
4. Remove the existing plastic bumpers from the left and
right sides of the mower deck. Retain all components
for future installation.
Original Instructions (EN)
WARNING
CALIFORNIA
Proposition 65 Warning
cause cancer, birth defects, or reproductive harm.
Qty.
1
1
1
1
2
2
2
4
4
6
16
Install the wheels.
5. Loosely, install the left-hand and right-hand roller
brackets to the front of the deck with 4 bolts (3/8 x
1-1/8 inches), 4 carriage bolts (3/8 x 1-1/8 inches),
and 8 flange nuts (3/8 inch). See Figure 1 for the
correct location for the bolts.
6. Install the left-hand and right-hand bumpers to the side
of the deck with 6 carriage bolts (3/8 x 1-1/4 inches)
and 6 flange nuts (3/8 inch) (Figure 1).
Printed in the USA.
All Rights Reserved
Form No. 3383-950 Rev A
Installation Instructions
Use
*3383-950* A
