imoo Watch Phone Z7 Manual

1. Package and Product Parameters
Package Contents:
Watch Phone Z7
Manual
Product Parameters:
Product: Watch Phone
Model: W2302AO
Battery: Lithium Polymer Battery Pack 3.85V 740mAh
Cameras: Front Camera 2MP, Rear Camera 5MP
Charge Input: DC 5V 1200mA
Working Temperature: 0℃~35℃
Working Humidity: Noncondensable 15%~93%
Network Frequency Bands: 2G GSM
2. Device Layout
Watch Face:
Front
Camera
Mic
3. Choose and Install the SIM Card
Step 1: Choose the Right SIM Card
· The Size of SIM Card: supports Standard Nano-SIM card only [as picture (1)].
· Supported operators: Vodafone, O2, Three and Giffgaff. If you are using a SIM card from
a Mobile Virtual Network Operator (MVNO) and the watch does not access the Internet
after inserting the SIM card, you can go to the imoo app > More > Watch Settings > APN
to set the APN parameters of the SIM card. If the watch still does not access the
Internet after the settings, please contact our customer service to insist.
Step 2: Activate "Caller ID" function & data plan
· Please activate Caller ID and enable GPRS data network. The watch can access to
either 2G/3G/4G network data. It's recommended that you choose at least a 500MB
watch plan per month.
Step 3: Install the SIM Card
· Press the lock button to flip the watch open and open the SIM card deck on the back
of the watch using a SIM card picker.
· Place the Nano SIM card on the card deck with the gold chip facing up and insert the
SIM card deck into the back of the watch.
* Note: Please insert the SIM card into your mobile phone to delete the PIN code before inserting it into the
watch.
4. Power On
· If the new watch does not turn on, it is probably without power. Please connect the
charging cable until the watch turns on automatically.
· In case of general abnormal conditions (e.g. blank screen), press and hold the On/Off
button for 12 seconds to restart the watch.
5. Download the App & Bind the Watch
Step 1: Download & Install the App
Scan the QR code on the right to download and install the App or go to
Google Play or Apple App Store and search for "imoo Watch Phone",
"imoo" or "Watch Phone" to download and install the app.
Step 2: Bind the Watch
· Open the imoo app, register or log in.
· Turn on your watch and follow the on-screen instructions to complete the binding, or
slide the watch interface to find the Bind Code, scan the QR code, or enter the bind
code manually to bind.
How to find the Bind Code?
Bind Code Chat
6. Watch Language Settings
· If you want to change the watch language to another language, you can go to Watch >
More > Settings > Language or go to imoo app > More > Watch settings > Watch
language to select the language you want to switch to.
· After setting, the language is switched and the watch automatically restarts as shown
below:
Switching language...
About to restart...
7. Charge
The watch is equipped with magnetic charging contacts. Please align the charging
contacts on the watch with the contacts on the charging cable until "Charging" is
displayed on the watch screen.
*Please use a CE certified power adapter when connecting the charging cable to charge the watch.
8. OTA Upgrade
System Updating...
9. Basic Operation
· Turn on the screen: Tap the screen or press the On/Off button.
· Turn the screen off: Press the On/Off button to turn off the screen when the Home
screen is on; or cover the screen with your hand;
· You can set the screen on time in "Display & Brightness" under the "Settings" in More
screen. When the time is up, the screen will turn off.
SAT
SAT
Bind Code
Move right from the
Bind Code screen.
10. Basic Features
Recents Sister
Recents Sister
Dad Mum
Brother Mum
Sister Sister
Let's Chat!
Let's Chat
Family Chat
Family Chat
Body temperature
Heart rate
Add Friends
Blood oxygen
saturation
are likely to have a fever. Since results may be affected if you perform detection after
exercise, you must wait until your heart rate returns to resting level after exercise to
ensure detection accuracy. This feature is suitable for children aged 6-14, not for those
suffering from bradycardia (heart rate below 60 bpm).
Heart rate: The watch is equipped with a wrist-mounted optical heart rate sensor that
supports 24-hour continuous monitoring and recording of your heart rate. To prevent
children from accidentally activating or playing with the optical heart rate sensor, it will
normally take more than 15 seconds for the watch to display the first detection result,
while subsequent heart rate data will be updated approximately every 2-5 seconds
based on heart rate fluctuations. If the detection result is displayed with a horizontal
line ("--"), it means that you're measuring your heart rate when you're not at rest. Please
make sure you measure your heart rate when you're relatively calm, inactive and not
sleeping.
And the best time to measure your heart rate is right after you wake up in the morning
(before you've got out of bed) and before you start to move around.
* This product is not a medical device and the measurement results are for reference only and are not intended
to be used as a basis for medical diagnosis.
Take Photos
Wi-Fi Settings
Go to "Settings">"WLAN" on the watch to make the relevant settings.
Once you have bound your watch, go to imoo app > "More" > "Watch's networks" to
add a network.
11. Specifications
57.9×41.5×15.2 (mm)
Dimension
Blue/Pink
Color
Display
1.3 inches TFT (240×240)
2G GSM
3G WCDMA
Network
4G FDD-LTE
4G TD-LTE
Supported
VoLTE
CPU UWS6131E
Motion Sensor, Hall Sensor, Heart Rate Sensor, Temperature Sensor,
Sensors
Geomagnetic Sensor
Memory RAM: 128MB
WiFi: 2.4G 802.11b/g/n, Bluetooth 4.2
Connectivity
GSM900: (33dBm±2dB)
GSM1800: (30dBm±2dB)
Rated Output WCDMA B1/B8: 24dBm(+1.7/-3.7dB)
Power
FDD-LTE B1/B3/B8/B20: 23dBm(±2.7dB)
TD-LTE B34/B38/B39/B40/B41: 23dBm(±2.7dB)
WiFi＜20dBm
Locating
Barometer, GPS, GLONASS, BDS, Galileo, QZSS, WiFi, LBS
Technology
Cloud Service Supported
Operation
CaremeOS
System
Battery 740mAh
In the Box Watch Phone Z7, Charging Cable, Manual, SIM Card Picker
12. Statements
· Please read this manual carefully to ensure correct and safe use of this product.
· Please use the watch strap that is well matched to this product to avoid interfering
with the watch's antenna signal. Use of other straps may result in poor call quality or
positioning failure.
· This product is equipped with GPS tracking, which is turned off until the watch is
bound. You can view the location of the watch after you have bound the watch and
enabled the Locate feature to comply with applicable privacy laws.
· Please use only the accessories supplied. If the user does not use this product
correctly and connects it to incompatible accessories, this will automatically invalidate
the warranty and may cause irreparable damage to the product or even endanger the
safety of you and your children. We are not responsible for the above cases.
· If you need to replace any accessories, please purchase them only from our official
service centre.
· The colour of the watch and its strap may fade over time, which does not affect the
use of the product and is harmless to the human body.
· Unauthorised disassembly of this product's case will void the product's warranty.
· This product operates normally only with a good network connection. We will not be
liable for any loss caused by interruption of service due to network failure or other
force majeure.
· In the interests of continuous improvement and sustainable development, we reserve
the right to modify and improve the product details described in this document
without prior notice. The contents of this manual are based on the conditions in which
the products were manufactured. Unless otherwise stated, we make no warranties,
express or implied, as to the accuracy, reliability or content of the documents.
· To the fullest extent permitted by applicable law, in no event shall our suppliers or we
be liable for any special, incidental, consequential or indirect damages, howsoever
caused.
· Some features of this product (including but not limited to maps) are provided by third
parties.
· This manual contains important information that should be kept properly.
· This product is not equipped with the monitoring feature.
1 Charging Cable
1 SIM Card Picker
3G WCDMA
4G FDD-LTE
4G TD-LTE
Heart Rate & Body
Temperature Sensors
On/Off
Speaker
Touch Screen
(1)
①
Powering on: Press and hold down the On/Off button for 6 seconds
to power on the watch.
Bind Code
Check the watch's firmware version on the imoo app and turn on
"Auto Update". The watch will then automatically download the
software updates and complete the upgrade when it is charged
and connected to the network.
* Note: There may be security risks with informal root or system upgrades. The
watch's operating system supports only official software updates. If the user
performs an unofficial root or system upgrade, any security risks or losses
resulting therefrom should be borne by the user (possible risks include, but
are not limited to theft of the user's personal data).
Wallpaper:
From the Home screen, long press to enter Wallpaper.
Slide left or right to view more and select one as your wallpaper.
Slide left from the Home screen to enter the "Chat", "Virtual Me"
and "More" screens. Slide down from the Home screen to access
the Control Center. Slide up from the Home screen to change the
shortcut settings.
Bind Code Chat
Return to the More
screen.
Call
Contacts sorting: "Recents" is at the top; contacts are sorted by
the time they were added, with the most recently added contacts
listed first. You can change the sorting by long-pressing and
dragging the contact's avatar.
Select a contact to make a voice or video call. Video calls can
use a lot of network data. We recommend that you make video
calls when the watch is connected to a Wi-Fi network. If the app
cannot receive the video call, check that notifications are enabled
or that the call has not been blocked by the system.
Chat
Tap "Hold to Talk" to start recording a voice message, then release
your finger to send it.
The watch also supports sending photos, videos and emoticons
via "Chat".
Unread voice messages are displayed on the screen. You can tap
them to play them.
Health
Please wear the watch appropriately, do not leave too much space
between your wrist and the watch to keep the heart rate and body
temperature sensors close to the skin.
Body temperature: Using a proprietary body temperature detection
algorithm developed by imoo, it detects changes in your body
temperature trend through 24-hour continuous monitoring of
physiological data. If your body temperature exceeds 37.5℃ for
an extended period of time, your parents will be notified that you
Camera
Tap the watch face to take a photo. You can switch to using the
rear camera by flipping the watch face up. Then slide the screen
up or down to switch between using the front or rear camera.
When using the rear camera, you can manually control the
distance between the rear camera and the subject.
You can slide left or right on the screen to switch between to
"Videos" or "Photos".
Specifications
900/1800MHz
B1/B8
B1/B3/B8/B20
B34/B38/B39/B40/B41
ROM: 128MB+4GB
1
1
900/1800MHz
B1/B8
B1/B3/B8/B20
B34/B38/B39/B40/B41
Watch Back:
Lock Button
Rear Camera
SIM Card Deck
②
Tap Bind Code in the More screen and
you will see a QR code and the Bind
Code digital numbers.
After entering each feature, you can slide
right to exit the feature, as shown on the
left. You can also press the On/Off button
to return to the Home screen.
Charging
Contact
Base
