imoo Watch Phone Z6 Manual

1. Package and Product Parameters
Package Contents:
Watch Phone Z6
Manual
Product Parameters:
Product: Watch Phone
Model: W1818AO
Battery: Lithium Polymer Battery 3.85V 680mAh
Cameras: Front Camera 5MP, Rear Camera 8MP
Charge Input: DC 5V 1200mA
Working Temperature: 0℃~35℃
Working Humidity: Noncondensable 15%~93%
Network Frequency Bands: 2G GSM
2. Device Layout
Watch Face:
Front Camera
Speaker
Touch
Screen
3. Choose and Install the SIM Card
Step 1: Choose the Right SIM Card
The Size of SIM Card: supports Standard Nano-SIM card only [as picture (1)].
Step 2: Activate "Caller ID" function & data plan
Please activate "Caller ID" function and enable GPRS data network. Watch phone can
access to either 2G/3G/4G network data.
Step 3: Install the SIM Card
1. Open up the SIM
card deck with a
SIM card picker.
*Remark: Before installing the SIM card, please insert it into your mobile phone to delete its PIN.
4. Power On
1. If the new watch cannot be turned on, it is probably out of power. Please plug in the
charging cable until the watch is turned on automatically.
2. For general abnormal conditions (e.g., blank screen), press On/Off button for 10
seconds to restart the watch phone.
5. Download the App & Bind the Watch
Step 1: Download & Install the App
Scan the QR code on the right to download and install the App or go to
Google Play or Apple App Store and search for "imoo" or "Watch Phone"
to download and install the App.
Step 2: Bind the Watch
1. Open the App, register or log in.
2. Turn on the watch and complete the binding process according to the instructions
displayed on the watch, or slide the watch interface to find the Bind Code, scan the QR
code, or manually enter the Bind Code for binding.
Get the Bind Code:
Bind Code
Chat
Add Friends Steps
6. Watch Language Settings
1. Go to "More"-"Watch Settings" on imoo App to switch the language, as shown below:
2. After setting, language switching will be conducted and the watch will be restarted
automactically, as shown below:
Switching language...
About to restart...
7. Charge
1. As shown below, please flip up the watch through the lock button to find the charging
contactors of the watch.
2. Then align the charging contactors on the watch with the charging contactors on the
charging cable until "Charging" is shown on the screen. Please use the CE certified
power adapter.
8. OTA Upgrade
System Updating...
9. Basic Operation
Turn on the screen: Tap the screen or press On/Off button to turn it on.
Turn off the screen: 1. Press On/Off button to turn off the screen when the home screen
HD
CMHK
Chat
Sister
Family Chat
Create A New
Group
Slide right from
Chat interface.
10. Basic Features
Mum
Sister
Emergency Call
Chat
Sister
Family Chat
Create A New
Group
Tap to shoot
Start
Bluetooth
Bluetooth headsets can be connected to the watch. You can use Bluetooth headsets to
make a call. On More interface, tap "Watch Settings" and choose "Bluetooth" to enable
or disable Bluetooth.
Wi-Fi
After binding your watch, enter "More-Watch's Wi-Fi" on App to add a network.
11. Appendix: Specifications
Dimension 57.8×44.7×15.9 (mm)
Color Flash Green/Fantasy Purple
Display 1.41inches AMOLED (320×360)
GSM900: TX/RX: 880-915MHz/925-960MHz
GSM1800: TX/RX: 1710-1785MHz/1805-1880MHz
CDMA BC0: TX/RX: 824-849MHz/869-894MHz
CDMA 2000 BC0: TX/RX: 824-849MHz/869-894MHz
WCDMA B1: TX/RX: 1920-1980MHz/2110-2170MHz
WCDMA B2: TX/RX: 1850-1910MHz/1930-1990MHz
WCDMA B5: TX/RX: 824-849MHz/869-894MHz
WCDMA B8: TX/RX: 880-915MHz/925-960MHz
Network
FDD-LTE B1: TX/RX: 1920-1980MHz/2110-2170MHz
FDD-LTE B2: TX/RX: 1850-1910MHz/1930-1990MHz
FDD-LTE B3: TX/RX: 1710-1785MHz/1805-1880MHz
FDD-LTE B5: TX/RX: 824-849MHz/869-894MHz
FDD-LTE B8: TX/RX: 880-915MHz/925-960MHz
TDD-LTE B38: TX/RX: 2570-2620MHz
TDD-LTE B39: TX/RX: 1880-1920MHz
TDD-LTE B40: TX/RX: 2300-2400MHz
TDD-LTE B41: TX/RX: 2555-2655MHz
VoLTE Supported
CPU Qualcomm Snapdragon Wear 2100
Sensors Accelerometer, Gyroscope, Hall Sensor
Memory RAM: 512MB
Connectivity WiFi: TX/RX: 2412-2472MHz, Bluetooth 4.2
GSM900: (33dBm±2dB)
GSM1800: (30dBm±2dB)
CDMA BC0: 24dBm(+6dB/-1dB)
Rated Output
CDMA 2000 BC0: 24dBm(+6dB/-1dB)
Power
WCDMA B1/B2/B5/B8: 24dBm(+1.7/-3.7dB)
FDD-LTE B1/B2/B3/B5/B8: 23dBm(±2.7dB)
TDD-LTE B38/B39/B40/B41: 23dBm(±2.7dB)
WiFi＜20dBm
Locating
GPS, GLONASS, BDS, WiFi, LBS
Technology
Cloud Service Supported
Operation
Android 7.1.1
System
Battery 680mAh
In the Box Watch Phone Z6, Charging Cable, Manual, SIM Card Picker
1 Charging Cable
1 SIM Card Picker
2G CDMA
3G CDMA2000
3G WCDMA
4G FDD-LTE
4G TDD-LTE
On/Off
Mic
(1)
2. Put the Nano-SIM card
on the card deck with
the gold chip facing
upward.
Power On: Press On/Off button for 2 seconds to power on
the watch phone.
Bind Code
When binding a watch, the App will detect the watch's version to
check if it needs to be upgraded. If needed, the watch will be
upgraded automatically when charging.
*Remark: There may be risks for informal root or system upgrade.
is on;
2. Cover the screen with your hand to turn it off;
3. You can set the "Screen Timeout" in "Display & Brightness" of the
"Watch Settings" on More interface. When the time is up, the
Charging
screen will be turned off.
Wallpaper:
Long press the home screen to enter Wallpaper. Slide left or right
to view more and select one as your wallpaper.
Slide left from the home screen to enter More interface, slide up or
down to choose corresponding features.
Slide right from the home screen to enter "Call".
Slide from top to bottom to check the status bar and some
important push notifications.
Add Friends
Chat
Steps Level
Go back to More
interface.
Call
Select a contact to make a voice call or video call. Video calls may
consume a lot of network data. We suggest you make video calls
when connected to Wi-Fi. If the App cannot receive the video call,
please check whether Notifications has been enabled or whether
the call was intercepted by the system.
Chat
Send voice messages: Tap "Hold to Talk" to record, and release
your finger to send your voice message. Play voice messages:
Unread voice messages will be shown on the screen. Tap to play
voice messages. Add friends: Tap "Face-to-face Making Friends"
on Add Friends interface. Then you can add a friend by bumping
your watches together after you find a friend.
Take Photos
Tap the watch screen to take a photo. If you want to switch to
using the rear camera, please flip up your watch. Besides, you can
switch cameras by sliding up or down on the interface.
Video
Tap "Start" to record a video. Tap the corresponding icon to
switch cameras or view the saved videos or photos.
Specifications
ROM: 8GB
1
1
900/1800MHz
BC0 800MHz
BC0 800MHz
B1/B2/B5/B8
B1/B2/B3/B5/B8
B38/B39/B40/B41(100M)
Watch Back:
Lock Button
Rear Camera
SIM Card Deck
Charging
Contactor
1. Tap Bind Code on More
interface to get the bind
code.
2. Scan the QR code or
enter the Bind Code
manually.
Charging... (90%)
After entering each feature, you can slide
right to exit the feature, as shown on the
left. You can also press the On/Off button
to go back to the home screen.
Base
3. Insert the SIM card
deck into the watch's
back.
