- Page 1 Oshkosh Corporation Classification ‐ Restricted AN-Series Operation and Safety Manual Lighting Tower AN-Series Models 6308AN 6308AN-6 8308AN 9308AN 1001309959 October 24, 2023 1001309959 JLG Industries (Australia) 24/10/23 Oshkosh Corporation...
- Page 2 Regents Park Green Fields NSW 2143 SA 5107 Phone: (02) 8718 6300 Phone: (08) 8259 8777 JLG Industries (New Zealand) 2b Fisher Crescent Mt Wellington, Auckland New Zealand Phone: + 64 9276 1728 1001309959 JLG Industries (Australia) 24/10/23 Oshkosh Corporation...
- Page 3 Take time to read and become familiar with each AN-Series manual. If you are uncertain about any of the information presented, contact your JLG Service Office before operating this AN-Series lighting tower.
- Page 4 Oshkosh Corporation Classification ‐ Restricted AN-Series OPERATION AND SAFETY MANUAL CONTENTS PAGE GENERAL SAFETY ALERT SYMBOLS SAFETY PRECAUTIONS INSPECTION & PERPARATION MACHINE CONTROLS MACHINE OPERATION LIFTING & TRANSPORTATION TOWING INSTRUCTIONS MACHINE STORAGE 10.0 MACHINE SPECIFICATION 1001309959 JLG Industries (Australia) 24/10/23 Oshkosh Corporation...
- Page 5 If there is a question on application and/or operation, JLG Industries Customer Support Department should be consulted on 131JLG (Australia) or +61 2 6581 1111.
- Page 6 MAY ALSO ALERT AGAINST UNSAFE PRACTICES. INDICATES INFORMATION OR A COMPANY POLICY THAT RELATES DIRECTLY OR INDIRECTLY TO THE SAFETY TO THE SAFETY AND PROTECTION OF PERSONNEL AND PROPERTY. INDICATES PROCEDURES ESSENTIAL FOR SAFE OPERATION. 1001309959 JLG Industries (Australia) Page 2 Oshkosh Corporation 24/10/23...
- Page 7 8. This shall be determined by a qualified Refer diagrams shown person accordance with elsewhere in this manual for correct employer, local, government handling procedures using a crane and requirements for work practices near forklift. energised equipment. 1001309959 JLG Industries (Australia Page 3 Oshkosh Corporation 24/10/23...
- Page 8 Alternative lights should engine bay area, ensure the lighting not be fitted unless authorised by JLG. tower mast is fully retracted and stowed, the genset shutdown and electrically 2. Do not operate the lights within easy isolated and the trailer safely parked.
- Page 9 MAST PLINTH AT THE FRONT OF THE MACHINE. DO NOT SET-UP OR OPERATE THE LIGHTING TOWER IN CONDITIONS WHERE WIND SPEED IS LIKELY TO EXCEED km/hr. TIPPING OVERTURNING LIGHTING TOWER IS POSSIBLE. 1001309959 JLG Industries (Australia Page 5 Oshkosh Corporation 24/10/23...
- Page 10 6. Reference should be made to the AN tight. Series Service & Maintenance Manual [1001309960] for procedures relating to 6. Check and drain bunding if necessary. regular and periodic machine inspection. 1001309959 JLG Industries (Australia Page 6 Oshkosh Corporation 24/10/23...
- Page 11 Oshkosh Corporation Classification ‐ Restricted AN-Series MACHINE CONTROLS AN-Series Lighting Tower Controls Engine Control Panel Lights Control Panel Hydraulic System Controls 1001309959 JLG Industries (Australia Page 7 Oshkosh Corporation 24/10/23...
- Page 12 Prior to S/N 6308AN081 shutdown system. For AN machines with an engine shutdown system, this is an engine distress light that indicates, low oil pressure, low coolant level or high engine temperature condition. 1001309959 JLG Industries (Australia Page 8 Oshkosh Corporation 24/10/23...
- Page 13 Must be pressed during the operation 9308AN). Protects against overload on of any of the hydraulic control levers. these lights. Circuit breaker-General Purpose Outlet (GPO) or RCD test point. Also provides overload protection. 1001309959 JLG Industries (Australia Page 9 Oshkosh Corporation 24/10/23...
- Page 14 In windy weather the mast may rotate towards the coupling ball and engage the to the nearest mast collar slot. The ratchet bar as shown. spring-loaded pin will then engage this slot and prevent further movement. 1001309959 JLG Industries (Australia Page 10 Oshkosh Corporation 24/10/23...
- Page 15 DO NOT USE THE JOCKEY WHEEL SUPPORT MACHINE (Approximately one turn after contact). WHEN THE MAST IS RAISED. Do not attempt to jack up the machine by overextending the leg length. 1001309959 JLG Industries (Australia Page 11 Oshkosh Corporation 24/10/23...
- Page 16 To rotate the Floodlight fixture in its trunnion loosen both M12 hex head screws using an 18 mm spanner. 3. hold the light trunnion(s)in position when retightening the M16 nyloc nut. 1001309959 JLG Industries (Australia Page 12 Oshkosh Corporation 24/10/23...
- Page 17 5. Finally, adjust the light bar tilt to the 6308AN081, engine distress desired angle by operating the tilt system if installed waits for the correct control enable push button engine oil pressure before the engine switches. will start. 1001309959 JLG Industries (Australia Page 13 Oshkosh Corporation 24/10/23...
- Page 18 This is normal behaviour for this lamp type. 5. With the machine attached to the towing vehicle, ensure the jockey wheel is fully raised and locked in the stowed position. 1001309959 JLG Industries (Australia Page 14 Oshkosh Corporation 24/10/23...
- Page 19 Outrigger arms shown fully retracted and jack legs retracted and in stowed position. 1001309959 JLG Industries (Australia Page 15 Oshkosh Corporation 24/10/23...
- Page 20 A tyne should penetrate at least 800 mm from trailer’s rear panel. 1001309959 JLG Industries (Australia Page 16 Oshkosh Corporation 24/10/23...
- Page 21 Secure/bind the jack-leg handle to prevent possible unwinding of the outrigger. If required, the lighting tower can be positioned and secured lengthways across trailer deck unpinning then retracting drawbar as shown. Tie-Down Lugs – (4) Front 1001309959 JLG Industries (Australia Page 17 Oshkosh Corporation 24/10/23...
- Page 22 TRAILER OVERRIDE BRAKES COULD road surface to hold coupler above road CAUSE VEHICLE LOSE should the trailer uncouple. Inspect safety CONTROL CAUSING DEATH chain and shackle for wear and damage. SERIOUS INJURY. 1001309959 JLG Industries (Australia Page 18 Oshkosh Corporation 24/10/23...
- Page 23 14. licence plate is secure/readable. 15. all outriggers and jacks are stowed 1. Ensure that machine is shut down, the and secured. mast correctly stowed and access- doors closed. Retract and stow front 1001309959 JLG Industries (Australia Page 19 Oshkosh Corporation 24/10/23...
- Page 24 Drive tow vehicle slowly forward and apply brakes to test the override. Unhitching the AN-Series Step 1 Hitching the AN-Series Step 9 Unhitching the AN-Series Step 8 1001309959 JLG Industries (Australia Page 20 Oshkosh Corporation 24/10/23...
- Page 25 8. Empty the fuel tank. Plug all vent holes to prevent ingress of moisture, insects and to the reduce likelihood of condensation and corrosion. Clean exterior surfaces remove any collected or accumulated plant or leaf matter 1001309959 JLG Industries (Australia Page 21 Oshkosh Corporation 24/10/23...
- Page 26 Sound Pressure Level @ 7 m 70 dB Hydraulic System Oil 5.6 L Wind Speed Rating 100 km/hr Fuel Tank (diesel) 165 L Radiator Coolant 5.5 L Engine Oil Sump 5.6 L 1001309959 JLG Industries (Australia Page 22 Oshkosh Corporation 24/10/23...
- Page 27 Tyre Dimensions: 205/80 x 16” Sincro - Model SK160MB Wheel Dimensions : 16” x 6J Rated Power. 20 kVA Tyre Pressure (Gauge): 450 kPa Configuration 3-Phase Wheel Nut Tightening Torque 125 Nm 1001309959 JLG Industries (Australia Page 23 Oshkosh Corporation 24/10/23...
- Page 28 Mast at maximum height (rotated) Transport leg retracted and stowed. Manual outriggers fully extended. Outrigger arms fully retracted Jack legs extended, AN-Series level. Levelling jacks inverted and stowed. Jockey wheel retracted/swung up. 1001309959 JLG Industries (Australia Page 24 Oshkosh Corporation 24/10/23...
