- Page 1 Oshkosh Corporation Classification ‐ Restricted LED-6R Operation and Safety Manual Lighting Tower Models LED-6R 1001261282 Revision B February 14, 2024 Refurbished 6308AN (LED-6R) 1001261282_B JLG Australia Pty Ltd Page 1-1 Oshkosh Corporation 14FEB24...
- Page 2 Sydney NSW 2143 Adelaide SA 5107 Phone: (02) 8718 6300 Phone: (08) 8259 8777 JLG Industries (New Zealand) 2b Fisher Crescent Mt Wellington, Auckland New Zealand Phone: + 64 9276 1728 1001261282_B JLG Australia Pty Ltd Page 1-2 Oshkosh Corporation 14FEB24...
- Page 3 Take time to read and become familiar with all four sections of this manual. If you are uncertain about any of the information presented, contact your JLG Service Office before operating this JLG LED-6R lighting tower.
- Page 4 CONTENTS Page INTRODUCTION……………………………1-3 GENERAL……………………………………1-5 SAFETY ALERT SYMBOLS……………….1-6 SAFETY PRECAUTIONS………………….1-7 INSPECTION & PERPARATION..…….….1-9 MACHINE CONTROLS…………………….1-10 MACHINE OPERATION…….……………..1-12 LIFTING & TRANSPORTATION…...……..1-19 TOWING INSTRUCTIONS…………….…..1-21 MACHINE STORAGE.……………………..1-24 1.10 MACHINE SPECIFICATION……………..1-25 1.11 LIGHTHEAD ISOLUX PLOTS……………..1-28 1001261282_B JLG Australia Pty Ltd Page 1-4 Oshkosh Corporation 14FEB24...
- Page 5 GENERAL LED-6R This section prescribes the proper and safe practices for LED-6R operation. To promote its proper use, it is mandatory that a daily routine be established based on the regular maintenance schedule and procedures in Section 02 of this manual. A maintenance and operator training program shall also be established by a competent person and should be followed to ensure that the LED-6R is safe to operate.
- Page 6 MAY ALSO ALERT AGAINST UNSAFE PRACTICES. INDICATES INFORMATION OR A COMPANY POLICY THAT RELATES DIRECTLY OR INDIRECTLY TO THE SAFETY TO THE SAFETY AND PROTECTION OF PERSONNEL AND PROPERTY. INDICATES PROCEDURES ESSENTIAL FOR SAFE OPERATION. 1001261282_B JLG Australia Pty Ltd Page 1-6 Oshkosh Corporation 14FEB24...
- Page 7 8. This shall be determined by a qualified elsewhere in this manual for correct person accordance with handling procedures using a crane and employer, local, government forklift. requirements for work practices near energised equipment. 1001261282_B JLG Australia Pty Ltd Page 1-7 Oshkosh Corporation 14FEB24...
- Page 8 Oshkosh Corporation Classification ‐ Restricted SAFETY PRECAUTIONS LED-6R The LED-6R is a refurbished 6308AN lighting tower. The LED-6Rs feature new gensets and low-voltage D.C. LED lights. ARTICULATING TELESCOPIC MAST HAS HAZARDOUS CRUSHING AND PINCH POINTS. DO NOT PLACE DO NOT OPERATE THIS LIGHTING ARMS, HANDS ETC. ANYWHERE NEAR...
- Page 9 Ensure that all warning lighting tower functions as designed. decals have been read and understood prior to operating machine. 4. Prior to starting the LED-6R engine check whether there is sufficient, a) trailer brake fluid………… b) engine radiator coolant….
- Page 10 In windy weather the mast may rotate Operates the engine bay light. to the nearest mast collar slot. The spring-loaded pin will then engage this slot and prevent further movement. 1001261282_B JLG Australia Pty Ltd Page 1-10 Oshkosh Corporation 14FEB24...
- Page 11 1.5.5 EMERGENCY STOP THE EMERGENCY STOP (BROKEN CIRCLE) OVERRIDES LED-6R CONTROL MODULE TO SHUT DOWN Sight Bubble Level Location THE ENGINE / GENERATOR. 1001261282_B JLG Australia Pty Ltd Page 1-11 Oshkosh Corporation 14FEB24...
- Page 12 Do not use the transport leg or jockey wheel to support the machine when raising the mast. 1.6.1 LED-6R TRAILER SET-UP MANUAL OUTRIGGERS & JACKS Select a flat level area to park the lighting tower. Apply the hand brake prior to unhitching unit and disconnect the safety chains and electrical cable.
- Page 13 2. rotate the trunnion to the required angle release the spring indexing pin. tighten both M12 hex head screws. 3. hold both light trunnions in position when retightening the M16 nyloc nut. 1001261282_B JLG Australia Pty Ltd Page 1-13 Oshkosh Corporation 14FEB24...
- Page 14 4. PRESS the enable button and at the 2) Auto Start/Stop same time PULL the mast telescope control lever to extend the mast to A summary of each lighting mode follows. desired height. 1001261282_B JLG Australia Pty Ltd Page 1-14 Oshkosh Corporation 14FEB24...
- Page 15 If alarm retriggers in mute status, the controller will remove the mute status. 1001261282_B JLG Australia Pty Ltd Page 1-15 Oshkosh Corporation 14FEB24...
- Page 16 When all lights are off, the engine runs through a cool-down cycle before A) press stopping. for each screen shown in Fig 1 to Fig 3 press to select. press to confirm. 1001261282_B JLG Australia Pty Ltd Page 1-16 Oshkosh Corporation 14FEB24...
- Page 17 Parameter Setting 01 Timer Start Start Time Duration 18:50 08:30 Press key to confirm setting and the set value will be saved into internal FLASH. 1001261282_B JLG Australia Pty Ltd Page 1-17 Oshkosh Corporation 14FEB24...
- Page 18 Once the mast is lowered the drawbar jockey wheel may be lowered and locked into position. The machine can then be manually positioned stowage prepared for towing. 1001261282_B JLG Australia Pty Ltd Page 1-18 Oshkosh Corporation 14FEB24...
- Page 19 A tyne should penetrate at least 800 mm from trailer’s rear panel. 1001261282_B JLG Australia Pty Ltd Page 1-19 Oshkosh Corporation 14FEB24...
- Page 20 If required, the lighting tower can be positioned and secured lengthways across trailer deck unpinning then retracting drawbar as shown. Tie-Down Lugs – (2) Front 1001261282_B JLG Australia Pty Ltd Page 1-20 Oshkosh Corporation 14FEB24...
- Page 21 CAUSE VEHICLE LOSE road surface to hold coupler above road CONTROL CAUSING DEATH should the trailer uncouple. Inspect safety SERIOUS INJURY. chain and shackle for wear and damage. 1001261282_B JLG Australia Pty Ltd Page 1-21 Oshkosh Corporation 14FEB24...
- Page 22 14. licence plate is secure/readable. 15. all outriggers and jacks are stowed 1. Ensure that machine is shut down, the and secured. mast correctly stowed and access- doors closed. Retract and stow front 1001261282_B JLG Australia Pty Ltd Page 1-22 Oshkosh Corporation 14FEB24...
- Page 23 TOWING INSTRUCTIONS Oshkosh Corporation Classification ‐ Restricted LED-6R 1.8.2 HITCHING THE LED-6R 1.8.3 UNHITCHING THE LED-6R 1) Raise the bottom surface of the coupler Apply the trailer hand brake and lock to be above the top of the hitch ball by its position using the ratchet lever.
- Page 24 TOWING INSTRUCTIONS MACHINE STORAGE LED-6R 1.8.4 TOWING GUIDELINES 1.9.1 STORING THE LED-6R. Check the trailer wheel nuts for If the lighting tower is to be stored and tightness. Check tow-ball coupling not operated for more than three tightness after towing the trailer 50 km months.
- Page 25 2.0 L Lighthead Lift/Lower Times Engine Oil Sump 5.1 L From stowed position Fluid Bund Capacity 120% to maximum height 65 s From maximum height to stowed position 50 s 1001261282_B JLG Australia Pty Ltd Page 1-25 Oshkosh Corporation 14FEB24...
- Page 26 Oshkosh Corporation Classification ‐ Restricted 1.10 MACHINE SPECIFICATION LED-6R 1.10.5 COMPONENT SPECIFICATIONS LED-6R Floodlight IWE 400 W Light Emitting Diode (LED) 48-52 V DC Genset D905-BG + FB4-48/100 Fixed Beam Width Angle 90°/110° Colour White 5000±200 K Engine: Kubota D905 BG Electrical Input (rating)
- Page 27 8.125 m 1.75 m 70° LED-6R Truck/Lorry Transport Drawbar fully retracted and locked. Transport leg extended and locked. Outrigger arms fully retracted. Levelling jacks extended, LED-6R level. 2.5 m 3.40 m 3.15 m (3.75) m 3.13 m 1.75 m LED-6R Trailer Towed LED-6R Lighting Tower Drawbar fully extended and locked.
- Page 28 Oshkosh Corporation Classification ‐ Restricted 1.11 ISOLUX PLOTS LED-6R Chart 1.0 Lighthead tilt angle 0° Chart 2.0 Lighthead tilt angle 45° 1001261282_B JLG Australia Pty Ltd Page 1-28 Oshkosh Corporation 14FEB24...
