Technical Service Instructions
FD-4400
General Safety Information
WARNING
• Obtain and read the service instructions carefully prior to installing the parts. Loose,
worn, or damaged parts may cause injury to the rider.
We strongly recommend only using genuine Shimano replacement parts.
• Be careful not to let the cuffs of your clothes get caught in the chain while riding,
otherwise you may fall off the bicycle.
• Read these Technical Service Instructions carefully, and keep them in a safe place for
later reference.
Note
• If gear shifting operations cannot be carried out smoothly, clean the derailleur and
lubricate all moving parts.
• If the amount of looseness in the links is so great that adjustment is not possible, you
should replace the derailleur.
• When the chain is in the position shown in the illustration,
the chain may contact the front chainrings or front derailleur
and generate noise. If the noise is a problem, shift the chain
onto the next-larger rear sprocket or the one after.
• For smooth operation, use the specified outer casing and
the bottom bracket cable guide.
• Grease the inner cable and the inside of the outer casing
before use to ensure that they slide properly.
• Parts are not guaranteed against natural wear or deterioration resulting from normal
use.
• For maximum performance we highly recommend Shimano lubricants and
maintenance products.
• For any questions regarding methods of installation, adjustment, maintenance or
operation, please contact a professional bicycle dealer.
In order to realize the best performance, we recommend that the following
combination be used.
Series
Shifting lever
Outer casing
Gears
Front derailleur
Front chainwheel
Bottom bracket
Rear derailleur
Freehub
Cassette sprocket
Chain
Bottom bracket cable guide
Specifications
Type
Front derailleur installation band diameter
C
Chainstay angle (
)
Chain line
SI-5EV0B
Front derailleur
Front
chainrings
Rear
sprockets
TIAGRA
ST-4400 / ST-R600 / SL-7700 / SL-R440
SP40
18
FD-4400
FC-4401
BB-ES51 / BB-ES30
RD-4400-SS
FH-4400
CS-HG50-9
CN-HG53
SM-SP17
Band type / Brazed on type
S (28.6mm), M (31.8mm)
61° - 66°
43.5mm
t
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Shimano TIAGRA FD-4400 - TECHNICAL
Summary of Contents for Shimano TIAGRA FD-4400 - TECHNICAL
- Page 1 Technical Service Instructions SI-5EV0B FD-4400 Front derailleur General Safety Information WARNING • Obtain and read the service instructions carefully prior to installing the parts. Loose, worn, or damaged parts may cause injury to the rider. We strongly recommend only using genuine Shimano replacement parts. •...
- Page 2 Installation of the front derailleur 1. Adjust so that the clearance between the chain guide Clearance: 1 - 3 mm outer plate and the large gear is 1 - 3 mm before installing. Chain guide outer plate 2. The level section of the chain guide outer plate should be directly above and parallel to the largest chainring.
- Page 3 4. Adjustment of the cable tension (1) Set the chain to the largest rear sprocket, and shift the front to top gear. Largest Outer ring sprocket Front shifting (ST-4400) Lever Lever From large chainring to small chainring Lever Lever From small chainring to large chainring (2) Perform the trimming.
