ITEM
SHIMANO
DESCRIPTION
NO.
CODE NO.
1
Y5A407020
Clamp Bolt (M5 x 15)
* 2
Stroke Adjust Screws (M4 x 13) & Plate
Y5LW98030
* 3
Y5LW98040
Cable Fixing Plate & Bolt (M5 x 8)
4
Clamp Band Adapter (2 pcs.) for S-size /
Y5JD98020
5
Y58032000
SM-FD74 Brazed-on Bracket
6
Y58032100
SM-FD74-LW Brazed-on Bracket (Investment Cast)
7
Y5JD98030
Clamp Bolt (M5 x 13.5) & Radius Washer for Brazed-on Type
8
Y5JD98040
SM-AD11 Clamp Band Unit
9
Y5JD98050
SM-AD15 Clamp Band Unit
10
Y59L19100
Clamp Bolt (M5 x 17.5) for SM-AD11 / AD15
11
Y5C252000
Clamp Bolt (M5 x 13.5) for SM-AD11 / AD15
A: Same parts.
B: Parts are usable, but differ in materirals, appearance, finish, size, etc.
Absence of mark indicates non-interchangeability.
Specifications are subject to change without notice.
ULTEGRA Front Derailleur
FD-6703
FD-6703
-G
31.8 mm (1-1/4”") for Brazed-on Type
34.9 mm (1-3/8”") for Brazed-on Type
for Triple Gear
Silver Version
Glossy Grey Version
28.6 mm (1-1/8”")
INTERCHANGEABILITY
B
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
Mar.-2011-2951A
©
Shimano Inc. A
