- Page 1 SS 240/4 SUN RAKES (FPM 627 652) SS 300/5 (FPM 627 139) o 056172 01. 2021. ASSEMBLY / HANDLING / MAINTENANCE LIST OF SPARE PARTS SERBIA Web: www.fpm.rs e-mail: info@fpm.rs...
- Page 2 IMPROVEMENT: FPM Agromehanika DOO constantly strives to improve its products and therefore reserves the right to make changes or improvements when necessary, without any obligation to change or supplement previously manufactured or sold equipment.
- Page 3 INSTRUCTIONS FOR HANDLING AND MAINTENANCE OF HAY TURNER- COLLECTOR -SS 240/4 (FPM 627 652)- WITH FOUR COLLECTING POINTS -SS 300/5 (FPM 627 139)-WITH FIVE COLLECTING WHEELS ASSEMBLY TIME: FPM AGROMEHANIKA DOO BOLJEVAC...
- Page 4 Machine Safety (Official Gazette of the Republic of Serbia, No. 21/2020, valid from 06.03.2020) for each original piece of new hay tumbling machine delivered to the user by the sales of the network of FPM Agromehanika DOO Boljevac which guarantees that at the time of delivery each such part is new,...
- Page 5 ⎯ Every time before using the tumbler - hay collector, check whether all parts (nuts, screws, etc.) are sufficiently tightened. ⎯ . Collecting elements or their parts used for fixing (nuts, screws, etc.) if they are worn or damaged, immediately replace them with original parts of FPM AGROMEHANIKA DOO BOLJEVAC. PAGE 5...
- Page 6 ― While working, always stay away from all parts of the tumbler - hay collector, protect your hands, feet and clothes. Spinning wheel - assembly with spring forks can cause serious injury. ― Never wear loose clothing that can be caught by the rotating parts of the hay rake. Clothing should be close to the body.
- Page 7 S A F E T Y ATTACHING THE TURNER - HAY COLLECTOR ⎯ Before each attachment and detachment of the tumbler - hay collector to the tractor, lock the hydraulic controls to prevent any unintentional raising or lowering. ⎯ When attaching, pay attention to the category of the tractor and the connection levers of the hay tweezers, they must adapt or match.
- Page 8 WARNING LABELS The following warning labels have been placed on your hay rake for your safety and the safety of the people working with you. With this manual in hand, walk around the machine and check those warning labels and manual instructions. Labels must be legible, if not replace them. CAUTION CAUTION BEFORE YOU START ADJUSTING,...
- Page 9 SS 240/4 FPM 627.652 627 12 157 SS 300/5 FPM 627.139 627 16628 The identification of the tumbler - hay collector is done through the name plate (sticker number 7) which contains the following numbers: ─ In the field with the letter "Z" - the number of the certificate (document) on occupational safety is entered.
- Page 10 PACKING OF THE TURNER - HAY COLLECTOR The tipper - hay collector SS 240/4 (FPM 627.652) and 300/5 (FPM 627.139) is shipped disassembled into four subassemblies, namely the connection assembly, the intermediate carrier, the main frame and the collection wheels.
- Page 11 Due to good soil copying, they are very suitable for use on all terrains. Collectors SS 240/4 (FPM 627 652) and SS 300/5 (FPM 627 139) are tools of the carried type. The connection assembly is used to connect the collector to the tractor, adjust the working position and carry the working elements.
- Page 12 INSTALLATION INSTRUCTIONS In order to facilitate the transport of the SS 240/4 (FPM 627 652) or SS 300/5 (FPM 627 139) hay tumblers, several parts and assemblies have been removed to reduce dimensions. To properly assemble the tumbler - hay collector, proceed as follows: 1.
- Page 13 3. ASSEMBLY OF COLLECTING WHEEL BRACKET ON THE MAIN FRAME Assembly of the collecting wheel carrier (picture 3, item 1) on the main frame (picture 3, item 2) is achieved by removing the washer and split from the sleeve of the collecting wheel carrier (picture 3, item 3 and 4) and inserting the sleeve into the opening on the main frame and secure the connection by placing a flat washer and...
- Page 14 THE PROCEDURE OF AGGREGATING THE TURNER - HAY COLLECTOR ON THE TRACTOR Aggregation is performed as follows: 1. 1. First remove the paint from the connecting sleeves of the collector (picture 6, item 1). 2. 2. Move the tractor backwards, using the hydraulics, lower the lower tractor levers (fig.
- Page 15 TRANSPORT OF TURNER - HAY COLLECTOR To transport the tumbler - hay picker, remember and do the following: ― while the tumbler is in the lowered position, shorten the active length of the chain on the connection bracket (pos. 1, picture 8) so that when lifting the tumbler to the transport position, the tension spring (pos.
- Page 16 WORKING WITH A HAY ROLLER - COLLECTION OF HAY - For the operation of collecting hay, it is necessary to bring the hay collector into the position as shown in figure 12. Depending on the condition of the grass to be collected and the desired work engagement, place the main support of the collector (pos.
- Page 17 REPLACE ― add two or three links to the chain and hang it DAMAGED COLLECTIVE ELEMENTS on the hook on the frame NEVER CORRECT DISTORTED COLLECTIVE ELEMENTS. DANGER: USE ONLY ORIGINAL PARTS MANUFACTURED BY FPM AGROMEHANIKA DOO BOLJEVAC PAGE 17...
- Page 18 SOME REVOLVING PARTS. DO NOT DRIVE OTHER PERSONS ON THE TRACTOR OR TURNER. WE RECOMMEND THAT AFTER EACH WORKING SEASON, YOUR SERVICE SERVANT OF FPM AGROMEHANIKA DOO BOLJEVAC FACTORY CHECKS THE CONDITION OF THE HAY COLLECTOR, ESPECIALLY COLLECTING ELEMENTS AND OTHER PARTS.
- Page 19 SS 240/4 FPM 627 139 - 5 točka SS 300/5 DSS 520/9H FPM 627 154 - 9 točka DSS 800/13H FPM 627 156 - 13 točka The year of production: 2021 as well as in compliance with the requirements established by the European Directive 2006/42/EC (for machines).
- Page 20 For vineyard tractors For tractors cat. 1 It is replaced by one or more parts For tractors cat. 2 Pad thickness For tractors cat. 3 The thickness of the washer to reduce the gap. FPM AGROMEHANIKA DOO BOLJEVAC PAGE 20...
- Page 21 CONNECTION ASSEMBLY ORDER IDENTIFICATION NUMBER SS 240/4 (FPM 627 652) 000 00 056 M12x35 000 00 062 000 00 072 000 02 918 10x80 000 02 926 4x50 000 04 088 6,3x45 627 10 056 627 10 286 627 10 408...
- Page 22 627 11 100 627 11 110 627 11 120 627 11 140 627 11 180 IDENTIFIKACIONA NUMERA ZA PORUDŽBINU ZA : SS 300/5 (FPM 627 139) 1 000 02 926 4x50 000 04 030 4x20 000 04 086 000 02 515...
- Page 23 MAIN FRAME FOR COLLECTOR-TURNER SS 240/4 (FPM 627 652) ORDER IDENTIFICATION NUMBER 000 00 055 M10X28 000 00 061 000 00 071 000 00 737 6205 - Z 000 02 551 000 02 918 10x80 000 02 926 4x50 000 02 947...
- Page 24 COLLECTOR MAIN FRAME SS 300/5 (FPM 627 139) ORDER IDENTIFICATION NUMBER 000 00 055 M10X28 000 00 061 000 00 071 000 00 737 6205 - Z 000 02 551 000 02 918 10x80 000 02 926 4x50 000 02 947...
- Page 25 COLLECTING WHEEL ORDER IDENTIFICATION NUMBER 000 00 061 000 00 071 000 04 058 M10x30 627 10 327 627 10 328 627 10 341 627 13 265 100 27 064 1 > 7...
- Page 26 № 3812 C O N T E N T TABLE REVIEW PAGE GROUP OF PARTS Limited Warranty 5 - 6 Security Safety of attachment of the tumbler - hay collector 8 - 9 Warning labels Information for correct reading of the instructions Packaging of hay rakes Specification of technical characteristics General information...
- Page 27 THE OPERATOR SHOULD COMPLY WITH ALL SAFETY AND HEALTH REGULATIONS, AS WELL AS ROAD TRAFFIC REGULATIONS. FOR YOUR OWN SAFETY, USE ONLY ORIGINAL PARTS MANUFACTURED BY FPM AGROMEHANIKA DOO - BOLJEVAC. THE MANUFACTURER IS NOT RESPONSIBLE FOR THE CONSEQUENCES OF IMPROPER USE OR FAILURE TO FOLLOW THE RECOMMENDATIONS GIVEN IN THIS MANUAL.
- Page 28 FOR YOUR PERSONAL SAFETY AND TO GET THE BEST OUT OF YOUR HAY ROLLER-COLLECTOR, USE ONLY ORIGINAL PARTS MANUFACTURED BY FPM AGROMEHANIKA DOO BOLJEVAC FPM AGROMEHANIKA DOO 19370 Boljevac, ul. Đorđa Simeonovića br.25 PHONES: Sales department: Tel: +381 30 461 171...
