ASSEMBLY / HANDLING / MAINTENANCE

LIST OF SPARE PARTS

MULCHERS FOR

VINEYARDS AND

ORCHARDS

VM 155 HC (FPM 618 187) 1,55 m

VM 155 GHC (FPM 618.187 G) 1,55 m

VM 155 HC+ (FPM 618.234) 1,55 m

VM 155 GHC+ (FPM 618.234G) 1,55 m

VM 180 HC (FPM 618.159) 1,80 m

VM 180 GHC (FPM 618.159G) 1,80 m

VM 180 HC+ (FPM 618.159) 1,80 m

VM 180 GHC+ (FPM 618.159G) 1,80 m

VM 200 HC+ (FPM 618.186 ) 2,00m

VM 200 GHC+ (FPM 618.186G) 2,00m

№ 93539

Table of Contents

Need help?

Do you have a question about the VM 155 HC and is the answer not in the manual?

Questions and answers

Summary of Contents for FPM VM 155 HC

Page 1 VM 155 HC (FPM 618 187) 1,55 m VM 155 GHC (FPM 618.187 G) 1,55 m VM 155 HC+ (FPM 618.234) 1,55 m MULCHERS FOR VM 155 GHC+ (FPM 618.234G) 1,55 m VM 180 HC (FPM 618.159) 1,80 m VINEYARDS AND VM 180 GHC (FPM 618.159G) 1,80 m...
Page 2 IMPROVEMENT: FPM Agromehanika DOO constantly strives to improve its products and therefore reserves the right to make changes or improvements when necessary, without any obligation to change or supplement previously manufactured or sold equipment.
Page 3: Table Of Contents
Cardan shaft is a product of the company "WALTERSCHEID" and can be purchased under the number: W 200E – SD15 – 710 – F5/1R – for VM 155 (FPM – 618 187) W 300E – SD15 – 710 – F5/1R – for VM 180(FPM – 618 159) W 400E –...
Page 4: Personal Safety
Machine Safety (Official Gazette of the Republic of Serbia, No. 21/2020, valid from 06.03.2020), for each original piece of mulch delivered to the user by the FPM Agromehanika sales network DOO Boljevac by which it guarantees that at the time of delivery every such part of the mulcher is new,...
Page 5: Warning Labels
THE FACTORY IS NOT RESPONSIBLE FOR LOSS OF PROFIT DUE TO SMALL PLANT REMAINS FAILURE OR INJURY TO THIRD PARTIES, NOR FOR ADDITIONAL COSTS OF WORK FOR REMOVING AND REPLACEMENT OF PARTS. The customer is responsible and bears the costs of the following: 1.
Page 6 Picture 1. strana | 6...
Page 7 WARNING LABELS _________________________________________________________________________________ Sticker Description Before working with the machine, read the manual carefully. During any adjustment, lubrication or cleaning of the implement, turn off the tractor and wait for all moving parts to stop. Never transport other persons on the tool. Rotating elements! Keep feet and hands away from rotating elements.
Page 8: Tool Description
TOOL DESCRIPTION ROTARY CUTTERS OF PLANT RESIDUES - MULCHERS: - VM 155 (FPM 618 187 / 234) - working reach 1.55 m - VM 180 (FPM 618 159) – working reach 1.80 m - VM 200 (FPM 618 186) – working reach 2.00 m Represent a group of tools for the widest application for mechanical crushing of plant residues on all agricultural, communal and other uncultivated surfaces.
Page 9 Picture 2. PARTS of the PLANT RESIDUE Mulcher strana | 9...
Page 10: Safety
1. Carrying frame (housing) of the grinder 8. Front safety protection (curtain) 2. Connecting frame trinkets - (III points) 9. Grooved PTO shaft 3. The third connection point of the trinket 10. PTO protection 4. Cardan shaft holder 11. Connection points – lower 5.
Page 11 - Blades on the rotor and parts that serve to secure them (nuts, screws, etc.) if they are worn or damaged, immediately replace with original parts of FPM AGROMEHANIKA DOO BOLJEVAC -Before starting to adjust, lubricate or clean the attachment, turn off the tractor engine,remove the ignition key, disengage the PTO shaft, and apply the tractor's parking brake.
Page 12 - In the transport position of the shredder, always take care and block the lateral movement of the connection levers. - When driving on public roads with the implement in the transport position, the tractor's hydraulic controls must be locked against inadvertent lowering. - Mulchar is not used for work on uneven terrain.
Page 13: Specification Of Technical Characteristics
Weight kg Picture 3. A(cm) B(cm) C(cm) D (cm) VM 155 (FPM 618 187 / 234) – 1,55 m 153,5 min 88 VM 180 (FPM 618 159) – 1,80 m 198,5 min 88 VM 200 (FPM 618 186) – 2,00 m...
Page 14 THE AGGREGATION PROCEDURE ON THE TRACTOR WORK BEFORE USE ATTENTION: Attaching a mulcher to a tractor can be a very dangerous operation. Pay special attention and strictly follow the given instructions. Proceed as follows: - Use a tractor whose configuration can meet the needs of the crop residue mulcher. - Make sure that there are no objects, people or animals near the implement, and that the drive shaft of the tractor is switched off.
Page 15 - Using the hydraulics, carefully raise the shredder so that the angle of breaking of the cardan shaft is not too large (never greater than 10º, picture 5.). Once you have raised the tool to its highest position in this way, check the following: a) whether the cardan shaft rotates freely and whether its joints are not stuck somewhere b) whether the cardan shaft is not stretched too much...
Page 16 DANGER: Adjusting the chopping height is dangerous operation. Wear protective gloves and use appropriate accessories Proceed as follows to adjust the chopping height.- Park the tractor on a level surface and lift the implement off the ground using the hydraulics. - Put two stronger side supports under the tool, to secure it from falling.
Page 17: Useful Tips
USEFUL TIPS FOR YOU Here are some useful tips on how to eliminate some problems that may arise during operation. THE PLANT RESIDUES ARE TOO SHORTED - raise the blades slightly from the ground, adjust the height with the roller (the cutting blades must not touch the ground) increase the speed of the tractor THE PLANTS ARE NOT SHORTED ENOUGH...
Page 18: Regular Maintenance
A pair of blades must be mounted opposite each other, in order to maintain the "balance" of the rotor. When replacing worn or broken blades, do the following: -remove the nut (pos. 1, picture 8.) from the screw that tightens the worn blades. Carefully study the position of all parts during the replacement phase, especially the spacer sleeve.
Page 19 Remember that lower maintenance costs and longer tool life depend on consistent adherence to the given instructions. ATTENTION: Before starting any operation, make sure the tool is parked on a level surface. Secure the implement against movement by placing chocks under the wheels.
Page 20 loosen the screw (pos. 1, picture 10) that holds the housing of the drive pulley. loosen the nut of the adjusting screw (pos. 2, picture 10) tighten the adjusting screw (pos. 2, picture 10) as much as necessary to ensure the required tension of the belts.
Page 21 Naziv proizvođača Oznaka masti Rafinerija Beograd LUMA - 2 "FAM" Kruševac FOR - 2 "MODRIČA" Modriča LITMA - 2 "INA" Zagreb LIS - 2 "SHELL" ALVANIJA R-2 "MOBIL" MOBILUX 2 "VALVOLINE" GREASE LB1-2 SERVICE ADJUSTMENTS - AFTER THE FIRST 8 HOURS OF OPERATION Check each tool after the first 8 hours of use.
Page 22: Declaration Of Conformity 98/37/Ce
ORCHARD MULCH WITH HYDRAULIC (for use in fruit growing and viticulture) Model: VM 155 HC (FPM 618 187) 1,55 m VM 155 GHC (FPM 618.187 G) 1,55 m VM 155 HC+ (FPM 618.234) 1,55 m VM 155 GHC+ (FPM 618.234G) 1,55 m VM 180 HC (FPM 618.159) 1,80 m...
Page 23: List Of Spare Parts
Year of manufacture: 2021 in accordance with the requirements established by the European Directive 2006/42/EC (for machines). The product complies with the following standards: SRPS EN ISO 12100:2014 SRPS EN ISO 13857:2020 SRPS EN ISO 4254-1:2016 SRPS EN ISO 4254-5:2018 SRPS EN ISO 4254-12:2013 SRPS EN ISO 4254-12:2013/A1:2017 EN 1553:2000...
Page 24 On your small change on the plate shown in the picture, the series and serial number are stamped. Warranty cases and other issues cannot be resolved without serial and serial number information. GROUP: ATTACHABLE AND MOVEABLE RAM br. crteža / kom.
Page 25 5386 627 13 216 CREVOVOD NP8 15952 627 13 215 SPOJNICA 5390 JUS M.C4.500 Zaptivka A22 x 27 5388 627 13 217 UVLAKAČ SPOJNICE 5389 JUS M.C4.500 Zaptivka A14 x 20 15951 627 13 214 PROVODNI ZAVRTANJ 55346 618 07 879 ČAURA GRANIČNIKA 7954 JUS M.B2.011...
Page 26 GROUP: CARRYING RAM strana | 26...
Page 27 br. crteža / kom. po poz. ident naziv / dimenzija napomena standard sklopu 46281 618 07 055 VOĆARSKI MULČAR 1,55 m – z. sklop 1,55 m 46282 618 07 060 VOĆARSKI MULČAR 1,80 m – z. sklop 1,80 m 46276 618 07 051 SAONIK –...
Page 28 br. crteža / kom. po poz. ident naziv / dimenzija napomena standard sklopu 12892 JUS M.B1.053 vijak M12 x 45 7988 JUS M.B1.622 navrtka M12 46389 618 07 061 KUĆIŠTE Y-LEŽAJA – zavareni sklop 5326 JUS M.B2.139 podloška 40 46257 618 07 049 NOSAČ...
Page 29 GROUP: ROTOR - mounting assembly strana | 29...
Page 30 GROUP: MULTIPLICATOR WITH SIDE TRANSMISSION SHAFT br. crteža / kom. po poz. ident naziv / dimenzija napomena standard sklopu 24568 627 14 455 KONUSNI ČEP M18x1,5 42597 020 03 007 ODUŠAK TSS M18x1,5 4570 JUS M.B1.053 vijak M12 x 30 18527 JUS M.B2.014 podloška 12...
Page 31 GROUP: SIDE TRANSMITTER br. crteža / kom. po poz. ident naziv / dimenzija napomena standard sklopu 46769 618 07 170 POKLOPAC BOČNOG PRENOSNIKA JUS M.B2.011 podloška 12 4671 JUS M.B1.622 navrtka M12 JUS M.B1.053 vijak M12 x 35 46718 618 07 047 ELASTIČNI VEZNI ELEMENT 40 x 80 46710 618 07 043...
Page 32 GROUP: ROLLER - mounting assembly 618 07 030 – 1,55 m 618 07 035 – 1,80 m 618 08 185 – 2,00 m br. crteža / kom. po poz. ident naziv / dimenzija napomena standard sklopu 1.1. JUS M.B1.053 vijak M12 x 35 1,55 / 1,80 m 1.2.
Page 33 GROUP: COUNTER KNIFE HOLDER - mounting assembly 618 07 095 – 1,55 m 618 07 100 – 1,80 m 618 08 555 – 2,00 m br. crteža / kom. po poz. ident naziv / dimenzija napomena standard sklopu 1.1. 46774 618 07 074 KONTRA NOŽ...
Page 34 This machine meets the safety requirements of the European Machinery Directive. RUKOVALAC TREBA DA SE PRIDRŽAVA SVIH PROPISA O BEZBEDNOSTI I ZDRAVSTVENOJ ZAŠTITI, KAO I PROPISA O SAOBRAĆAJU NA PUTEVIMA. U CILJU SOPSTVENE BEZBEDNOSTI, KORISTITE SAMO ORIGINALNE DELOVE KOJE JE PROIZVEO FPMAGROMEHANIKA DOO - BOLJEVAC. PROIZVOĐAČ...
Page 35 FOR YOUR PERSONAL SAFETY AND TO GET THE BEST OUT OF YOUR LITTLE PLANT RESIDUE, USE ONLY ORIGINAL MANUFACTURER PARTS FPM AGROMEHANIKA DOO BOLJEVAC FPM AGROMEHANIKA DOO 19370 Boljevac, ul. Đorđa Simeonovića br.25 TELEFONI: Služba prodaje: Tel: +381 30 461 171 Mob: +381 63 485 312 Služba Servisa: Tel: +381 30 463 619...
