- Page 2 Performance Features Advanced Polycarbonate Composite Shell Advanced Polycarbonate shell specifically engineered to maximize impact dispersal Magnetic Ratchet System Patent pending Neodymium magnetic face shield mechanism replaces detents with fluid shield movement. Fastened with brass finished hex bolt (M3 hex key included) KwikWick III Liner Fabric ®...
- Page 3 Your helmet ventilation systems should be kept clear of any obstructions including dirt, insects or other items which could interfere It is important for maximum safety that your ScorpionEXO helmet fit ®...
- Page 4 Face Shield removal Peak Visor Installation PEAK VISOR INSTALLATION FACE SHIELD REMOVAL With the face shield removed, simply align the peak-visor tabs 1. Ensure that the face shield is fully opened. with the corresponding tabs on the baseplate. 2. Remove the hex screw with M3 hex key provided. 3.
- Page 5 Side Cover Installation SIDE COVER INSTALLATION The purpose of the provided side covers is to protect the shield mechanism from debris plus, if you choose to ride with goggles, the side cover will also protect your goggle straps from wear against the face shield baseplate. With the face shield removed, 1.
- Page 6 Aeroskirt removal / installation AEROSKIRT REMOVAL Simply grasp the aeroskirt where it meets the leading edge of the cheek pad and firmly pull it away from the chin bar. (fig 1) fig 3 fig 2 AEROSKIRT INSTALLATION Be sure to align the leading edge of the Aeroskirt to fit in between the bottom rubber gasket and the chin bar EPS (fig 2).
- Page 7 Cheek Pad removal / installation fig 1 fig 2 CHEEK PAD REMOVAL First, remove the aeroskirt. Next, grasp the cheek pad at the temple area then gently pull the cheek pad away from the helmet (fig 1). This will release the pad from the top hook-and-loop fastener and two bottom snaps.
- Page 8 Crown Liner removal / installation fig 2 fig 3 CROWN LINER REMOVAL With both the Aeroskirt and Cheek Pads removed, first grasp the crown pad at the bottom/rear of the helmet releasing the two rear snaps (fig 1, 2). Once done, grasp/pinch the front edge of the crown pad and gently pull it away from the helmet.
- Page 9 Securing and Wearing your Helmet Cleaning Your Helmet System None of the components of your ScorpionEXO helmet can ® DO NOT SIMPLY PULL YOUR HELMET DOWN ONTO YOUR HEAD LIKE A be damaged by water. All headliners and sweat-wicking HAT. YOUR SCORPIONEXO HELMET SHOULD BE WORN AS FOLLOWS: ®...
- Page 10 There is no warranty for the helmets involved to protect you and is not recommended. in accidents or that have been dropped or impacted. SCORPIONEXO USA Warranty/Tech Center 12145 Mora Drive, Unit 13 Santa Fe Springs CA 90670...
- Page 11 As with all ScorpionEXO has several optional items ® specifically designed to fit the HX1 Helmet. See what’s available at ScorpionUSA.com today. NOTES: __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________ __________________________________________________...
- Page 12 SCORPIONEXO USA Warranty/Tech Center 12145 Mora Drive, Unit 13 Santa Fe Springs CA 90670 T: 1.888.672.6774 E: warranty@scorpionusa.com Printed in China...
