- Page 2 Performance Features Composite Shell ® Developed exclusively by Scorpion, the revolutionary TCT ® (Thermodynamic Composite Technology) process consists of a proprietary 5 layer blend of interlaced and specially formulated fiberglass, Aramid and organic poly-resin fibers. 4 Shell Sizes To optimize weight, fitment, and comfort. Pinlock Ready FaceShield ®...
-
Page 3: Ventilation Systems
Introduction FaceShields Ellip-Tec Function Ventilation Systems Ventilation helps decrease the possibility of fogging and condensation. - Page 4 Face Shield Lock/Vent Lever Note: First, Close Shield to the lowest position to Lock/Unlock. To lock the faceshield, turn Locking-lever counter clockwise to the 2 o’clock position approximately. Check face shield if it’s securely locked. Note: When the lever is positioned at 3 o’clock, the shield is closed, but it is also unlocked.
- Page 5 Emergency Release System SNAP Slot SNAP PULL PUSH Cheek Pad SNAP Emergency Safety Release System PRECAUTION SNAP Hole Locate the emergency labeling on the 1. SNAP may come off from the Cheek Pad neck roll. Simply reach under the during Cheek Pad removal. neck roll and grab the release strap, 2.
- Page 6 Neck Roll & Cheek Pads Removal Fig. 1 Occassionally the neck roll and cheek pads may require removal for washing or replacement. First step: Remove the Aero Skirt. (refer to page 7). Fig. 2 Second step: Slide your thumb between the neck roll and cheek pad at the area closest to the AirFit inflation pump and gently tug the neck roll away from the helmet interior...
- Page 7 Crown Liner Removal Occassionally the crown liner may require removal for washing, replacement or to change sizes. First step is to remove the cheek pads. (refer to page 5). At the back of the helmet pull the crown liner away from the shell unsnapping the two snaps (shown in yellow).
- Page 8 Aero Skirt Removal The pliable Aero Skirt was designed to reduce wind from entering behind the face shield area, specifically to keep your face warmer in cold weather. You do however have the option to remove the Aero Skirt for cleaning or for warmer riding conditions.
- Page 9 Inflatable Liner DO NOT ATTEMPT TO ADJUST THE FIT WHILE RIDING DEFLATION INFLATION While wearing the helmet press the large Press the small button to release the air. DO NOT ball until you reach the desired fitment. remove the helmet without first deflating the liner. DO NOT modify, puncture, or damage the air bladders in any way.
- Page 10 Securing and Wearing your Helmet FaceShield Replacement Do not simply pull your helmet down onto your head like a hat. Your Scorpion- Exo™ helmet should be worn as follows: Using both hands grab the helmet’s bottom rim while holding the chin straps with your thumbs. Then “roll” the helmet onto your head starting at the forehead.
-
Page 11: Warranty
Warranty benzene, thinner or cleaning agents. DO NOT paint over your helmet’s finish without totally protecting For on-line registration of your new ScorpionExo helmet, please and isolating the shock-absorbing liner and plastic parts. log onto www.scorpionsports.eu and click on “Support”.
