Diamond SKYLINE SBET/XC-06 Service Manual

Oven 6-10 electric
Hide thumbs Also See for SKYLINE SBET/XC-06:

Advertisement

Quick Links

Download this manual
08/2019
Mod: SBET/XC-06
Production code: 228720

Advertisement

loading
Need help?

Need help?

Do you have a question about the SKYLINE SBET/XC-06 and is the answer not in the manual?

Questions and answers

Related Manuals for Diamond SKYLINE SBET/XC-06

Summary of Contents for Diamond SKYLINE SBET/XC-06

  • Page 1 08/2019 Mod: SBET/XC-06 Production code: 228720...
  • Page 2 Document made by Product Care – Technical Training & Service – Vallenoncello PN/Italy All the images and information of this document are property of ©Diamond Professional Spa. This document and all of its contents cannot be copied or used, in part or entirely without the written authorization of Diamond Professional Spa.
  • Page 3 This manual is available in digital format by: contacting the dealer or reference customer care; downloading the latest and up to date manual/technical bulletin(s) on the web site;: www.Diamond.com/professional. The manual must always be part of the documentation available when servicing the machine.
  • Page 4 THIS MANUAL IS FOR 6-10 ELECTRIC OVENS, IN SPECIFIC, THE MODELS COVERED BY THE SERVICE MANUAL ARE: MODEL LEGEND EXAMPLE: Model for Zanussi LW Model for Alpeninox/Multibrand LW PNC : 217720 Model for Horecaland (Diamond) Model for Diamond LW FACTORY MODEL : Combi Electric ECOE61T2A0 6 GRIDS 1/1...
  • Page 5 SKYLINE OVEN 6-10ELECTRIC NDEX 1 GENERAL INFORMATION ........................10 GENERAL INFORMATION ....................... 10 SAFETY INFORMATION/PRECAUTIONS ..................11 PERSONAL PROTECTION EQUIPMENT ................. 12 GENERAL INFORMATION ......................12 RESIDUAL RISKS ........................13 DATA PLATE (IDENTIFICATION STICKER) ..................15 TECHNICAL DATA ..........................16 OVERALL DRAWINGS WITH MEASUREMENTS ................
  • Page 6 SKYLINE OVEN 6-10ELECTRIC INSTALLATION ACCESSORIES ....................... 34 FIRST START UP ..........................34 WIZARD AUTOMATIC, FIRST STARTUP ................. 35 2.6.1.1.1 REACTIVATE THE WIZARD PROCEDURE / WIZARD RECAP ........35 2.6.1.1.2 FIRST TIME POWER ON ....................36 2.6.1.1.3 WIZARD: SETTINGS ...................... 36 2.6.1.1.4 COUNTRY AND LANGUAGE ..................
  • Page 7 SKYLINE OVEN 6-10ELECTRIC 4 DETAILED APPLIANCE AND COMPONENTS DESCRIPTION/FUNCTIONING ........54 FUNCTIONAL / TECHNICAL DESCRIPTION ..................54 SWITCHING ON / OFF ....................... 54 SETTINGS ............................54 LEVEL T, K (TOUCH SCREEN) ....................54 4.2.1.1 SETTINGS AND SERVICE AREA ..................54 4.2.1.1.1 CLEANING ........................
  • Page 8 SKYLINE OVEN 6-10ELECTRIC 4.2.2.2.7 DIGITAL INPUT and I/O ....................86 4.2.2.2.8 LAMBDA PROBE CALIBRATION ................... 87 4.2.2.3 SOFTWARE UPDATE(LEVEL B,C) ................... 88 EQUIPMENT FUNCTIONING ......................89 WATER SYSTEM ........................89 STEAM SYSTEM ........................90 4.3.2.1 APPLIANCE WITH BOILER & HUMIDIFIER..............90 4.3.2.2 APPLIANCE WITHOUT BOILER - ISG ................
  • Page 9 SKYLINE OVEN 6-10ELECTRIC 4.4.24.5 BOILER PROBES ......................119 4.4.24.5.1 LEVEL PROBES (SL-WL)................... 120 4.4.24.5.2 TEMPERATURE (TBOI) ..................... 121 4.4.24.5.3 SAFETY (TSB) ......................121 4.4.24.6 LAMBDA ........................... 122 4.4.24.7 FOOD PROBE (TFP) ......................124 4.4.24.8 SAFETY PROBE SSR (NHSC, NHSB) ................124 MICROSWITCH COOLING AIR FILTER PRESENCE (AFS) AND DOOR (DS) .....
  • Page 10 SKYLINE OVEN 6-10ELECTRIC 6.3.5.3.1 LEVEL T, K (TOUCH SCREEN) ................... 159 6.3.5.3.2 LEVEL B, C (DIGIT) ...................... 160 6.3.5.3.3 ACCESS DISPLAY AND REPLACEMENT OF MEMBRANE STICKER ...... 160 LEVEL T, K (TOUCH SCREEN)....................161 LEVEL B, C (DIGIT) ........................164 6.3.5.4 POWER BOARD, ACU .....................
  • Page 11 SKYLINE OVEN 6-10ELECTRIC GENERAL INFORMATION GENERAL INFORMATION To ensure safe use of the machine and a proper understanding of the manual it is necessary to be familiar with the terms and typographical conventions used in the documentation. The following symbols are used in the manual to indicate and identify the various types of hazards: WARNING Danger for the health and safety of operators.
  • Page 12 SKYLINE OVEN 6-10ELECTRIC SAFETY INFORMATION/PRECAUTIONS • Risks mainly of a mechanical, thermal and electrical nature exist in the machine. Where possible the risks have been neutralized: – directly, by means of adequate design solutions. – indirectly by using guards, protection and safety devices. •...
  • Page 13 SKYLINE OVEN 6-10ELECTRIC PERSONAL PROTECTION EQUIPMENT Summary table of the Personal Protection Equipment (PPE) to be used during the various stages of the ma- chine's service life. Stage Protective Safety footwear Gloves Glasses Safety helmet garments ● ○ ○ Transport —...
  • Page 14 SKYLINE OVEN 6-10ELECTRIC • The measured sound level emitted “A“ does not exceed 70 dB (“A“). • Turn the appliance off in case of fault or poor operation. • Do not use products (even if diluted) containing chlorine (sodium hypochlorite, hydrochloric or muriatic acid, etc.) to clean the appliance or the floor under it.
  • Page 15 SKYLINE OVEN 6-10ELECTRIC Safety signs to be placed near the machine area Prohibition Meaning do not remove the safety devices do not use water to extinguish fires (placed on electri- cal parts) Keep the area around the appliance clear and free from combustible materials.
  • Page 16 SKYLINE OVEN 6-10ELECTRIC DATA PLATE (IDENTIFICATION STICKER) The identification sticker is located on the side panel. The meaning of the various information is listed below: SERIAL NUMBER (PRODUCTION DATE) is necessary to find the correct spare part or to ask tech. support. 9 03 1 0001 EXAMPLE: Serial Number YEAR...
  • Page 17 SKYLINE OVEN 6-10ELECTRIC TECHNICAL DATA ELECTRIC MODELS Dimensions / connections: CWI1= G3/4” (water inlet) CWI2 = G3/4” (water inlet) D = 1 ¼” (water drain)
  • Page 18 SKYLINE OVEN 6-10ELECTRIC OVERALL DRAWINGS WITH MEASUREMENTS The minimum entrance dimension, if you dismantle the handle is: NOTES When removing the handle...
  • Page 19 SKYLINE OVEN 6-10ELECTRIC CONTROL PANEL INTERFACES There are two type of interfaces (U.I) : Level T, K are TOUCH (touch screen) Level B,C are DIGIT (buttons) LEVEL T,K (TOUCH SCREEN) A. Control panel screen B. ON/OFF button C. USB key in/out D.
  • Page 20 SKYLINE OVEN 6-10ELECTRIC LEVEL B, C (DIGIT) Level B ( with boiler) & C (appliance without boiler / boiler less) A. Control panel screen B. ON/OFF button C. USB key in/out D. Print out E. Openable flap A. Cooking cycles B.
  • Page 21 SKYLINE OVEN 6-10ELECTRIC GENERAL REFERENCE TO APPLICABLE PRODUCT CERTIFICA- TIONS EQUIPMENT MODULES AND INTERACTIONS DEFINITIONS/GLOSSARY COMPONENTS DEFINITION EXPLANATION Power board Appliance control unit PRIDE-SERVICE Web portals available for technical documentation consultation PORTAL- AGE- User Board Different for touch and digit appliances Electric wiring diagram CAVITY inner liner, inside cooking chamber...
  • Page 22 SKYLINE OVEN 6-10ELECTRIC INSTALLATION AND COMMISSIONING INSTALLATION The following chapters are intended only for authorized technicians / engineers GENERAL EQUIPMENT SPECIFICATIONS / SCOPING OF WORKS For authorized technicians refer to the documentation available on the web sites (PRIDE-SERVICE PORTAL- AGELUX etc..) In case of any doubt, refer to your local country customer care. GENERAL INSTALLATION All the non-standard or out-of-standard situations should be reported on the commissioning form and duly documented for future reference.
  • Page 23 SKYLINE OVEN 6-10ELECTRIC Position the appliance on a flat surface. If necessary adjust the height of the appliance by means of the adjustable levelling feet, where present, or adjust the stand’s feet. 2.1.2.2 ROOM REQUIREMENTS To guarantee continuous operation, the room temperature range must be between 5°C and 40°C. Outdoor functioning is strictly allowed only if the machine can be protected against any conditions being out of the above temperature range and against any atmospheric agents.
  • Page 24 SKYLINE OVEN 6-10ELECTRIC 2.1.2.3 LIMITATIONS All appliance sides must remain at 50 mm from any surface. In case of no access to the side panels it will be necessary to predispose When possible leave a space of at least flexible supply connections sufficiently long to 500 mm between the left side of the ap- permit extraction of the appliance for mainte- pliance and the other surfaces to enable...
  • Page 25 SKYLINE OVEN 6-10ELECTRIC 2.1.2.4 LIST OF POSSIBLE INSTALLATION SOLUTIONS Hereinafter, the instructions for the main installation possibilities. The different accessories have a dedicated I.M; please refer also to these documents provided with the accessories or available on PRIDE. 2.1.2.4.1 MOUNTING ONTO AN OVEN STAND (SIZE GN 1/1 – 2/1) Place the oven onto the stand by inserting the locating feet into the tubular uprights.
  • Page 26 SKYLINE OVEN 6-10ELECTRIC 2.1.2.4.4 STACKING INSTALLATIONS & HYGIENIC REQUIREMENTS STAKING INSTALLATIONS indicated here after for safety reasons MUST be fixed to the wall or to the floor by means of the appropriate accessories included in the appliance or to be ordered, according to your model (kit “Wall brackets "or kit “Flanged feet“).
  • Page 27 SKYLINE OVEN 6-10ELECTRIC 2.1.2.4.5 WALL FIXING – WALL BRACKETS Fix the stacked oven to the wall by means of the 2 brackets; Re- fer to the dedicated installation manual provided with the ac- cessory. 2.1.2.4.6 FLOOR FIXING – FLANGED FEET If the stacked ovens cannot be fixed to the wall it is necessary to fix them to the floor.
  • Page 28 SKYLINE OVEN 6-10ELECTRIC APPLIANCE REQUIREMENTS 2.1.3.1 POWER (VOLTS) Refer to the volts range data indicated in the tech specs table § TECHNICAL DATA 2.1.3.2 WATER IMPORTANT ! The periodical check ( PREVENTIVE MAINTENANCE) of filter functionality, according the manufacturer, avoids compromising appliance operation and prevents the risk of corrosion.• For good operation of the water softeners and filters make sure to service them regularly.
  • Page 29 SKYLINE OVEN 6-10ELECTRIC 2.1.3.2.2 CHEMICAL CHARACTERISTICS In CWI2 inlet the appliance must be supplied with suitable drinking water (in particular Ph 6,5 ÷ 8,5 and con- ductivity > 50 μS/cm). To guarantee correct appliance operation, some water treatment systems may therefore have to be installed. For that purpose, follow the indications given in the following charts according to your models:...
  • Page 30 SKYLINE OVEN 6-10ELECTRIC General advices • Periodical maintenance of the water treatment devices avoids compromising appliance operation and pre- vents risk of corrosion. • To prevent damaging the appliance, at every periodical regeneration of the water softener filter, do a filter wash cycle without introducing water into the oven.
  • Page 31 SKYLINE OVEN 6-10ELECTRIC 2.1.3.2.3 CONVERSION TABLE FOR WATER TREATMENT ELECTRIC CONNECTION WARNING ! Take GREAT CARE when connecting / testing anything with live current, if you are unsure what you are doing and how to use your equipment safely, then DON'T DO IT. IMPORTANT ! The connection to the electrical power supply must be in compliance with the current national and local regulations...
  • Page 32 SKYLINE OVEN 6-10ELECTRIC CAUTION / IMPORTANT ! If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. The manufacturer declines any liability if the current na- tional and local regulations and possible safety regulations are not respected HOW TO RECOGNIZE PHASE AND NEUTRAL WARNING!
  • Page 33 SKYLINE OVEN 6-10ELECTRIC WATER CONNECTION TABLE TOP The oven (with boiler or boilerless) has two separate water supply inlets: CWI1 = G3/4” connection for cleaning water and steam condensing CWI2= G3/4” connection (treated water) boiler filling and ISG. Refer to the § WATER for the chemical char- acteristics required.
  • Page 34 SKYLINE OVEN 6-10ELECTRIC STACKING INSTALLATIONS A = Back flow inlet valve 3/4" M -3/4" F; This component is not installed on board but is packed in the accessory bag supplied with each new appliance and must be installed (NOT for UK installations). For UK: A WRAS compliant double check valve or some other no less effective device providing backflow preven- tion protection to at least fluid category three shall be provided by the installer technician.
  • Page 35 SKYLINE OVEN 6-10ELECTRIC INSTALLATION ACCESSORIES All documentation for each ACCESSORY is available for authorized technicians on the web sites (PRIDE- SERVICE PORTAL- AGELUX etc..) and can be downloaded in file. For those that do not have access to the web sites, refer to your local country customer care. FIRST START UP Once that all the supplies connections have been carried out it’s time to startup the appliance.
  • Page 36 SKYLINE OVEN 6-10ELECTRIC WIZARD AUTOMATIC, FIRST STARTUP The “Wizard setup” is an assisted first start up of the appliance carried out trough the electronic board with a series of images shown on the display. This setup is meant to be carried out by an authorized technician. !!! AS THE WIZARD IS NOT YET IMPLEMENTED, PLEASE REFER TO THE PICTOGRAM PROVIDED WITH THE OVEN FOR THE MANUAL TEST TO BE PERFORMED AFTER THE INSTALLATION!!! 2.6.1.1.1 REACTIVATE THE WIZARD PROCEDURE / WIZARD RECAP...
  • Page 37 SKYLINE OVEN 6-10ELECTRIC 2.6.1.1.2 FIRST TIME POWER ON On the first time the appliance is switched on at the customer site an installation verification and appliance performances procedure is started, the default lan- guage is English up to the selection of the user. This procedure must be com- pleted to guarantee the performances of the appliance and allowing the cus- tomer to use it.
  • Page 38 SKYLINE OVEN 6-10ELECTRIC 2.6.1.1.6 DATE In this page the user can set the date format and input the current one Using the angular brackets the user can change the current date, while the se- lected date format is green colored. 2.6.1.1.7 TIME The user can select the time format and input the current one The selected time format...
  • Page 39 SKYLINE OVEN 6-10ELECTRIC 2.6.1.1.8 MEASUREMENT UNITS This step allows the user the set the preferred unit for the data shown on the display (the image shows the generic page). 2.6.1.1.9 SETTINGS END When the afore mentioned steps are concluded the display shows a recap of the status of the wizard. The Settings phase is marked concluded , while the others remain to be performed.
  • Page 40 SKYLINE OVEN 6-10ELECTRIC 2.6.1.1.10 WIZARD: INSTALLATION CHECKS AND SETTINGS This part of the procedure mainly regards visual confirmation of the correct installation of the appliance. 2.6.1.1.11 POWER SUPPLY The operator has to confirm the installation of the appliance power supply according to the following instruc- tions: Refer also to §...
  • Page 41 SKYLINE OVEN 6-10ELECTRIC 2.6.1.1.13 LEVELLING The operator has to con- firm the levelling of the oven and the rack struc- ture: 2.6.1.1.14 CLEARANCES The operator has to con- firm clearance around the appliance: Refer also to § LIMITATIONS 2.6.1.1.15 DRAIN CONNECTION The operator has to con- firm the installation of the drain pipe according...
  • Page 42 SKYLINE OVEN 6-10ELECTRIC 2.6.1.1.16 CLEANING (EXTERNAL LIQUID KIT ONLY) PAR_FAB_CLEAN_LIQ ENABLED The opera- tor has to confirm the in- stallation of the liquid chemical kit according to the specifications: 2.6.1.1.17 MANUAL SETTINGS END When the afore mentioned steps are concluded the display shows a recap of the status of the wizard. The Manual Settings phase is marked concluded while the remaining ones have to be performed.
  • Page 43 SKYLINE OVEN 6-10ELECTRIC 2.6.1.1.18 WIZARD: AUTOMATIC TEST This part is meat to test the performance of the appliance in an automatic mode. The operator is involved on visual check to unforeseen behaviors. 2.6.1.1.19 WATER SYSTEM This step is meat to the automatic testing of the water system. All the available pipes connections for the water are tested and the user is asked to verify the absence of leakage on the external connection.
  • Page 44 SKYLINE OVEN 6-10ELECTRIC 2.6.1.1.20 BOILER WATER LEVEL This test checks the correct working of the boiler water level system. Pressing the button starts the internal automatic procedure during which the display shows the animation: The test consists in draining the boiler, filling it up to the safety level and then working with that level .
  • Page 45 SKYLINE OVEN 6-10ELECTRIC 2.6.1.1.21 DOOR GASKET This test is meat to the check of the sealing of the door gasket to the cabinet. Pressing button starts the internal automatic procedure dur- ing which the display shows the animation: The test consists in creating steam inside the cavity up to the saturation level in order to see if any steam leakage can be seen from the door gasket.
  • Page 46 SKYLINE OVEN 6-10ELECTRIC 2.6.1.1.22 DOOR MECHANIC TEST The test is devoted to the check of the behavior of the door mechanism at high temperature. . Pressing the button starts the internal automatic proce- dure during which the display shows the animation: The test consists in reaching a tempera- ture of 300°C heating the whole structure and then testing the opening and closing...
  • Page 47 SKYLINE OVEN 6-10ELECTRIC 2.6.1.1.23 LAMBDA CALIBRATION (WHEN PRESENT) This part of wizard is devoted to the calibration of the lambda probe. Pressing the button starts the internal automatic procedure during which the display shows the animation: During the test the oven detects the dry point and the steam saturation point of the oven. When the sensor output for these two points is measured the procedure is concluded.
  • Page 48 SKYLINE OVEN 6-10ELECTRIC LEVEL B,C (DIGIT) The appliance is a "plug in" you will have to carry out a manual testing for water leakages and performance test.  TEST FOR LEVEL B (Boiler) APPLIANCES (PLEASE REFER TO THE PICTOGRAM PROVIDED WITH THE APPLIANCE-PICTURE BELOW IS AN EXTRACT)
  • Page 49 SKYLINE OVEN 6-10ELECTRIC  TEST FOR LEVEL C (Boiler less) APPLIANCES (PLEASE REFER TO THE PICTOGRAM PRO- VIDED WITH THE APPLIANCE-PICTURE BELOW IS AN EXTRACT) COMMISSIONING Please refer to the Commissioning form; the document is available for authorized technicians on the web sites (PRIDE-SERVICE PORTAL- AGELUX etc..) In case of any doubt, refer to your local country customer care.
  • Page 50 SKYLINE OVEN 6-10ELECTRIC USE OF APPLIANCE OPERATING INSTRUCTIONS Please refer to the Installation and User Manual of the appliance; the document is available for authorized technicians on the web sites (PRIDE-SERVICE PORTAL- AGELUX etc..) In case of any doubt, refer to your local country customer care.
  • Page 51 SKYLINE OVEN 6-10ELECTRIC CAVITY CLEANING The cavity is normally clean by automatic washing cycles: 3.2.2.1 LEVEL B, AND C (DIGIT) “Cleaning“ function allows to clean the oven cavity automatically choosing the most suitable program. (5 cycles).: Press repeatedly the indicated button to set one of the cleaning cycles. This is the cleaning cycles list to choose: Soft CLn1= Soft washing cycle Medium CLn2= Medium washing cycle...
  • Page 52 SKYLINE OVEN 6-10ELECTRIC FILTER, AIR INTAKE Clean the air filter, located under the control panel, at least once a month. If the control panel shows the alarm icon "ASCH", it is necessary to clean it. Proceed as follows: 1. Unscrew the screws fixing the air filter; 2.
  • Page 53 SKYLINE OVEN 6-10ELECTRIC BOILER DESCALE During the routine washing cycles carried out with the suggested chemicals (rinse & descale tablets) the boiler is maintained scale free (refer to the amount and type of detergent/rinse aid to use as indicated in the User Manual).
  • Page 54 SKYLINE OVEN 6-10ELECTRIC 3.2.5.2 LEVEL T (TOUCH SCREEN) The boiler descale cycle can be carried out through a "special" cycle (available only to the service engineer) started directly from the service area, called “Boiler maintenance”; refer also to the § SETTINGS AND SER- VICE AREA to gain access.
  • Page 55 SKYLINE OVEN 6-10ELECTRIC DETAILED APPLIANCE AND COMPONENTS DESCRIPTION/FUNCTIONING The following chapters are intended only for authorized technicians / engineers WARNING ! Take GREAT CARE when connecting / testing anything with live current, if you are unsure what you are doing and how to use your equipment safely, then DON'T DO IT. FUNCTIONAL / TECHNICAL DESCRIPTION SWITCHING ON / OFF Please refer to User Manual of the appliance;...
  • Page 56 SKYLINE OVEN 6-10ELECTRIC Highlighted chap- ters useful technician set- tings 4.2.1.1.1 CLEANING Before starting any washing cycle the appliance will check the inner cavity temperature, if the inner temperature is too hot the appliance will proceed to a "Forced cooling" Cycle stop Keep hold to stop the cycle;...
  • Page 57 SKYLINE OVEN 6-10ELECTRIC 4.2.1.1.2 ACCESSORIES If any accessories are connected to the oven it may be necessary to grant the item. 4.2.1.1.3 OVEN IDENTITY CARD...
  • Page 58 SKYLINE OVEN 6-10ELECTRIC 4.2.1.1.4 SERVICE “Service” will be accessed through password in Settings->Service. Once the password is correctly entered the “Service” credentials will be active for 15 minutes while navigating the interface. The 15 minutes timeout is continually reset while the appliance is in running state and every time the interface detects a touch. With “Service”...
  • Page 59 SKYLINE OVEN 6-10ELECTRIC ENVIRONMENTS ALARM LOGS TECHNICAL SERVICE ID...
  • Page 60 SKYLINE OVEN 6-10ELECTRIC PARAMETERS LEVEL T, K (TOUCH SCREEN) The parameters are included in the software that is available for authorized technicians on the web sites (PRIDE-SERVICE PORTAL- AGELUX etc..) In case of any doubt, refer to your local country customer care. Identification of parameter and value to set or change.
  • Page 61 SKYLINE OVEN 6-10ELECTRIC PARAMETER LIST (LEVEL T,K,B,C): All documentation for each PNC is available for authorized technicians on the web sites (PRIDE-SERVICE PORTAL- AGELUX etc..) and can be downloaded in file. For those that do not have access to the web sites, refer to your local country customer care.
  • Page 62 SKYLINE OVEN 6-10ELECTRIC Para- Mne- meter Parameter name Short Description Table Min Max monic fault Maximum temperature PAR_MAXT_WATERCOOL trMA to use water in cool down Minimum temperature PAR_MINT_WATERCOOL trMn to use water in cool down Advanced recovery {0, "Disabled"} PAR_FL_FAB_ADV_REC ArEC mode {1, "Enabled"}...
  • Page 63 SKYLINE OVEN 6-10ELECTRIC Para- Mne- meter Parameter name Short Description Table Min Max monic fault {1, "Fan speed 1" } {2, "Fan speed 2" } {3, "Fan speed 3" } Hot air cycle fan speed PAR_HOTAIR_FAN_DEF {4, "Fan speed 4" } default {5, "Fan speed 5"...
  • Page 64 GASt Gas Type Index {4, "G30(Buthane)"} {5, "G31(Propane/LPG)"} {6, "G20(USA Methane"} {7, "G31(USA Pro- pane/LPG"} Selects the brand of the {0, “Diamond”} appliance. This selection {1, “Zanussi”} PAR_SEL_BRAND BrAn impacts on function {2, “Diamond”} names and availability {3, “Multi Brand”} {0, "Not installed”}...
  • Page 65 SKYLINE OVEN 6-10ELECTRIC Para- Mne- meter Parameter name Short Description Table Min Max monic fault PAR_DB_FAN_SPEED_4 FSP4 Fan speed 4 1800 1200 PAR_DB_FAN_SPEED_5 FSP5 Fan speed 5 1800 1500 {1, "Fan speed 1" } Steam cycle fan speed PAR_DB_STEAM_FAN_DEF {2, "Fan speed 2" } default {3, "Fan speed 3"...
  • Page 66 SKYLINE OVEN 6-10ELECTRIC Para- Mne- meter Parameter name Short Description Table Min Max monic fault Index for boiler level PAR_INDEX_LEVEL_SENSING IndL sensing sensitivity Boiler temperature to PAR_BOL_STOP_TEMP bPHt be kept in stop mode User HACCP data log PAR_sPRN_HACCP tPrn 3600 sample time.
  • Page 67 SKYLINE OVEN 6-10ELECTRIC COUNTERS Here it is possible check the time and cycle used in the units, as: -How many cycle used -How many hours used -Reset the counters Counter name Mnemonic Description CNT_CLN_XS CCL4 Counter extra strong cleaning cycles CNT_CLN_S CCL3 Counter strong cleaning cycles...
  • Page 68 SKYLINE OVEN 6-10ELECTRIC Counter name Mnemonic Description CNT_WATER_SPRAY_ACTIVATIONS CSPA water sprayer activations (EV4) CNT_HH_WATER_SPRAY_ACTIVATE CHSA water sprayer active time (EV4) CNT_INLET_WATER_ACTIVATIONS CInA inlet water cleaning valve activations (EV7) CNT_HH_INLET_WATER_ACTIVATE CHIA inlet water cleaning valve active time (EV7) CNT_DRAWER_LOADING_ACTIVATIONS CdLA drawer loading valve activations (EV11) CNT_HH_DRAWER_LOADING_ACTIVE CHdL drawer loading valve active time (EV11)
  • Page 69 SKYLINE OVEN 6-10ELECTRIC LAMBDA PROBE CALIBRATION TEST DIGITAL I/O...
  • Page 70 SKYLINE OVEN 6-10ELECTRIC RESTORE AUTOMATIC MODE CLEAR: PROGRAM MODE, MULTI TIMER DATA, FSC LOG, HACCP LOG...
  • Page 71 SKYLINE OVEN 6-10ELECTRIC MANAGE PASSWORDS INSTALLATION WIZARD RECAP Here you will find a RECAP of the wizard carried out in the wizard setup, if you would like to see what was set by the previous installer/commissioner.
  • Page 72 SKYLINE OVEN 6-10ELECTRIC BOILER MANTENANCE The boiler descale operation cannot be carried out “manually”; the boiler is not equipped with an external access like in previous models. The boiler maintenance is carried out trough a "special" cycle started directly from the service area. Refer also to the § SETTINGS AND SERVICE AREA If the cycle is completed without interruption the counter parameter relative to the descale will add 1 unit (+1);...
  • Page 73 SKYLINE OVEN 6-10ELECTRIC 4.2.1.2 BY-PASS ENVIRONMENT Once you are logged as SERVICE § SETTINGS AND SERVICE AREA the By-Pass environment is auto- matically available in the secondary menu From this environment it is possible to manually activate the following devices: ...
  • Page 74 SKYLINE OVEN 6-10ELECTRIC 4.2.1.3 USB TRANSFER AMBIENT ( SERVICE FUNCTIONS) The Transfer ambient is used to manage data transfer between UI and a USB key. It contains four functional- ities: - Download all: Used to copy all data (parameters, recipes,…) from UI to USB key; - Upload all: Used to copy all data from USB key to UI;...
  • Page 75 SKYLINE OVEN 6-10ELECTRIC The presence of the "SERVICE" icon means that you are logged in as "ser- vice user". If “User” credentials are active, the space will be left blank. “Service” credentials will be active for 15 minutes while navigating the interface.
  • Page 76 SKYLINE OVEN 6-10ELECTRIC USER (chef or generic user) SERVICE VIEW OF USB AREA “User” credentials are active, the space is left blank. Not all folders can be selected with User credentials !!.
  • Page 77 SKYLINE OVEN 6-10ELECTRIC 4.2.1.4 FIRMWARE RELEASE, RECOVERY MODE 4.2.1.4.1 FIRMWARE RELEASE In the Identity card is possible to check the complete software release, made of 3 main environments:  UI App version  ACU FW version  Inverter FW version ...
  • Page 78 SKYLINE OVEN 6-10ELECTRIC 4.2.1.5 SOFTWARE UPDATE(LEVEL T,K) The software for each PNC is available for authorized technicians on the web sites (PRIDE-SERVICE POR- TAL- AGELUX etc..) and can be downloaded in a zip file. For those that do not have access to the web sites, refer to your local country customer care.
  • Page 79 SKYLINE OVEN 6-10ELECTRIC LEVEL B, C (DIGIT) 4.2.2.1 UTILITIES ACTIVATED WITH OVEN ON These functions can be accessed directly from the user board without entering service area, the access is granted when the appliance is turned ON 4.2.2.1.1 FIRMWARE RELEASE The firmware of the USER / ACU / INVERTER electronic boards can be read following the procedure : Appliance turned ON, but no cycles must be active.
  • Page 80 SKYLINE OVEN 6-10ELECTRIC 4.2.2.1.3 PROBE TEMPERATURES READINGS The following temperatures can be read during the functioning of the appliance; press the indicated combina- tion of buttons on the user board to gain access: Indicated in the following picture are the buttons used for access. On the Display you will see: VALUE...
  • Page 81 SKYLINE OVEN 6-10ELECTRIC press one of the following indicated combinations for 1,5" to visualize the value and name on the display Display Button combination Meaning of the NAME on the display NAME NTC PUMP nHSC NTC CAVITY SOLID STATE RELAY TEMP. nHSb NTC BOILER SOLID STATE RELAY TEMP LAMb...
  • Page 82 SKYLINE OVEN 6-10ELECTRIC 4.2.2.2 SERVICE AREA AND UTILITIES To enter into the dedicated “Service area ” ; follow the procedure by pressing a combination of BUTTONS: Start pressing combina- tion of buttons immediately after the first digit appears on the display or the access to the service area will not be...
  • Page 83 SKYLINE OVEN 6-10ELECTRIC 4.2.2.2.1 PARAMETER SETTING Once entered into the service area PARAMETER NUMBERING PARAMETER NAME By pressing " " you will visualize the value of the desired parameter. By pressing the By pressing the right right and left and left buttons you can buttons you will change the parameter navigate in the...
  • Page 84 By pressing " " you will reset the selected parameter to the default value of the specific electronic board when it was programmed at Diamond factory. Repressing again " " will save the new parameter value and return into the parameter list.
  • Page 85 3"; all parameters will be set to the default value of the specific electronic board when it was programmed at Diamond factory. PdEF 4.2.2.2.5 ACTIVATION OF LOADS In case you need to activate specific components for testing purpose:...
  • Page 86 SKYLINE OVEN 6-10ELECTRIC 4.2.2.2.6 PROBE TEMPERATURES READINGS In area service / parameters accessed The button that activates this function is by pressing button " " for 1,5" on the display will be shown the first NAME, by pressing rapidly " "...
  • Page 87 SKYLINE OVEN 6-10ELECTRIC 4.2.2.2.7 DIGITAL INPUT and I/O In area service / parameters accessed The buttons that activate these functions are by pressing for 1,5" on the display will be shown the first NAME of the digital input, by pressing rapidly "5" the list will be scrolled sequentially Display Display...
  • Page 88 SKYLINE OVEN 6-10ELECTRIC 4.2.2.2.8 LAMBDA PROBE CALIBRATION In case of need to reset the Lambda probe or if replaced; in area service / parameters accessed, start the automatic procedure, press for 1,5" On the display you will LAMB Then press (start/stop) On the display you will see led digits become il-...
  • Page 89 SKYLINE OVEN 6-10ELECTRIC 4.2.2.3 SOFTWARE UPDATE(LEVEL B,C) The software for each PNC is available for authorized technicians on the web sites (PRIDE-SERVICE POR- TAL- AGELUX etc..) and can be downloaded in a zip file. For those that do not have access to the web sites, refer to your local country customer care.
  • Page 90 SKYLINE OVEN 6-10ELECTRIC EQUIPMENT FUNCTIONING WATER SYSTEM CWI2 TREATED WATER CWI1 TAP WATER STEAM BOILER ISG / HU- FILL CLEA- FILL DE- Function QUEN- SHOWER FILL MIDIFIER * NING SCALING CHING EV11 Solenoid valve [l/min] ±10% [l/min]±0.05 [l/min]±10% [l/min]±10% [l/min]±10% [l/min]±10% nominal 0,25...
  • Page 91 SKYLINE OVEN 6-10ELECTRIC STEAM SYSTEM 4.3.2.1 APPLIANCE WITH BOILER & HUMIDIFIER BOILER HUMIDIFIER The steam generated in the cavity during this cy- cle is obtained by the means of filling the BOILER or injecting water trough a pipe called also HU- MIDIFIER .
  • Page 92 SKYLINE OVEN 6-10ELECTRIC 4.3.2.2 APPLIANCE WITHOUT BOILER - ISG The functional level “K, C” do not have a boiler; they manage 10 levels of humidity which are obtained by injecting water directly on the cavity fan. The steam generated in the cavity during this cycle is obtained by the means of injecting water trough a pipe called also ISG (instant steam generator).
  • Page 93 SKYLINE OVEN 6-10ELECTRIC QUENCHING SYSTEM AND STEAM Circumstances that activate the quenching (EV2 Valve): -The quenching will be activated for a few seconds when the appliance is turned on, this to be sure that all pipes are full of water (refer also to SAFETY / PUMP (NM8).
  • Page 94 SKYLINE OVEN 6-10ELECTRIC CLEANING SYSTEM LEVEL T, B (BOILER) Refer also to the § SETTINGS AND SERVICE AREA 2= WATER FILL (EV7 ON) 1= BOILER DRAIN 3= DETERGENT RECIRCULA- BV3= Cavity drain valve (close) TION – CAVITY CLEANING BV6= Boiler Drain Valve (open) (Pump M8 ON)
  • Page 95 SKYLINE OVEN 6-10ELECTRIC 4= BOILER DESCALE (EV11 ON) 6= BOILER CLEANING 5= CAVITY RINSE AID (EV11 ON – EV12 ON – Pump ON) BV3= Open EV11= D dispencer fill, for boiler de- BV6= Close & Open scale cycle; EV5= On & Off EV12= drain dispencer aid COMPONENTS TECHNICAL DESCRIPTION/FUNCTIONING IMPORTANT !
  • Page 96 SKYLINE OVEN 6-10ELECTRIC EXAMPLE WIRING DIAGRAM (not all heating elements could be present on all ovens; EX: boiler less ovens would not have a boiler and therefore a H.E..).
  • Page 97 SKYLINE OVEN 6-10ELECTRIC SOLID STATE RELAY (SSR = KC1,KC2,KB1,KB2) 1 = Cooling heat sink 2 = Conductive thermal pad 3 = SSR relay 4 = Green led 5 = Fix screw Functioning of the LED and it's meaning: WARNING ! Even if the led is not turned "on"...
  • Page 98 SKYLINE OVEN 6-10ELECTRIC Aisi 303 hub connection, conical, AISI 304 fan. The fan rotate clockwise and counter clock wise. The fan blades are radial. MOTOR FAN (M1) The motor fan will rotate clockwise and counter clock wise for cooking uniformity reasons. Ovens 6/1- 10/1 = 450W Model : Hanning Ovens 6/2 /10/2 = 750W Model: Fir 300rpm to 1500rpm...
  • Page 99 SKYLINE OVEN 6-10ELECTRIC AIR BREAK A = Boiler drain / B = Door condense drain / C = Condense overflow / D = Cavity drain valve E = Oven Drain / F = Safety overflow / G = Inspection access (screwed plug) WASH PUMP(M8) AND WATER FILL (EV7) Power 160-230W at 220-240V / 50-60Hz - Absorbed current 0,7/1 Amp - Condenser 5µF...
  • Page 100 SKYLINE OVEN 6-10ELECTRIC DRAIN VALVE BOILER (BV6) Drain valve 1" GRUNER (CE) 220-240V 50/60HZ EV5 = BOILER FILL VALVE / BV6= BOILER DRAIN DRAIN VALVE CAVITY (BV3) EV1= ISG / EV2= QUENCHING / EV4= SHOWER / BV3= DRAIN VALVE...
  • Page 101 SKYLINE OVEN 6-10ELECTRIC FLOW METER (FM) FM= Flow meter, is also the CWI1 (not treated water) water inlet point. Connection dimension ¾” male flanged. Inside is a magnet, a signal output sent to the ACU X39. WATER VALVES (FM, EV 2, EV7, EV11 AND EV4). FM= Flow meter (X39), is also the CWI1 (not treated water) water inlet point.
  • Page 102 SKYLINE OVEN 6-10ELECTRIC INLET WATER VALVES (EV1 / EV5) This valve is the CWI2 (treated water) inlet point EV1 = ISG (X2) EV5= BOILER FILL (X5) CWI2 TREATED WATER CWI1 TAP WATER STEAM BOILER ISG / HUMI- FILL CLEA- FILL DE- Function QUEN- SHOWER...
  • Page 103 SKYLINE OVEN 6-10ELECTRIC DISPENSER RINSE AID / SENSOR (DRS); VALVES (EV11 EV12) Note: the magnets used to close off the contact of the reed sensor DRS are inserted into the removable drawer cup. A= pipe to EV12, drain dispenser aid B= pipe to EV11, water inlet C= pipe to boiler for descale cycle D= magnetic reed DRS sensor to check that the plug cap is present.
  • Page 104 SKYLINE OVEN 6-10ELECTRIC SHOWER ASSEMBLY AND VALVE (EV4) The shower assembly drawer will be supplied with water when EV4 is power supplied. EV4 is normally closed; when the door opens the reed sensor DS Refer to § MICROSWITCH AIR INTAKE FILTER PRESENCE (AFS) AND DOOR (DS) will consense and permit power supply to contact X2/3 and therefore open the EV4 valve so...
  • Page 105 SKYLINE OVEN 6-10ELECTRIC BOILER There are available two different models of boiler: material AISI 316 / AISI 304.Identification of the material can be found using the "model legend" (explained at page 3) and the model of your oven located (that can be found on the data plate identification sticker).
  • Page 106 SKYLINE OVEN 6-10ELECTRIC INVERTER (MD / MOTOR DRIVE) WARNING! Danger of electrocution - dangerous voltage. Before checking any electric components, be sure to disconnect the main supply and verify with a meter the main electrolytic capacitors (i.e. being fitted on Inverter, SMPS) are discharged to safe voltage levels. The charge capacitor may hold high-voltage even after the power is disconnected.
  • Page 107 SKYLINE OVEN 6-10ELECTRIC SWITCHING FEEDERS (SMPS) WARNING! Danger of electrocution - dangerous voltage. Before checking any electric components, be sure to disconnect the main supply and verify with a meter the main electrolytic capacitors (i.e. being fitted on Inverter, SMPS) are discharged to safe voltage levels. The charge capacitor may hold high-voltage even after the power is disconnected.
  • Page 108 SKYLINE OVEN 6-10ELECTRIC 4.4.16.1 The device can be identified in an easy manner: it has WHITE CONNECTORS 4.4.16.2 The device can be identified in an easy manner: it has GREEN CONNECTORS...
  • Page 109 SKYLINE OVEN 6-10ELECTRIC DOOR ADJUSTMENT & DOOR LATCH Door handle refer to DOOR REMOVAL, LED BAR & DOOR HANDLE DOOR LED BAR (H1) Supplied through X12 of the ACU CURRENT ABSORP- TION : 400mAmp VOLTAGE = 12V TEMPERATURE COLOR = 5600K...
  • Page 110 SKYLINE OVEN 6-10ELECTRIC POWER BOARD (ACU)
  • Page 111 SKYLINE OVEN 6-10ELECTRIC...
  • Page 112 SKYLINE OVEN 6-10ELECTRIC USER INTERFACE (UI) The user board UI, is supplied trough relay KSM that is activated with the ON/OFF button SM. Phase and Neutral (L/N) will arrive to the Switching feeders SMPS 12V and 24V that then will supply voltage to their X14 &...
  • Page 113 SKYLINE OVEN 6-10ELECTRIC 4.4.20.1 LEVEL T,K (TOUCHSCREEN) The UI of the touchscreen appliances is supplied from the ACU connector X27 into contact J7/4. If the user interface (user board) cannot communicate with any other board for more than a determinated time (ex 15") any running cooking cycle will be stopped.
  • Page 114 SKYLINE OVEN 6-10ELECTRIC 4.4.20.2 ♦LEVEL B,C (DIGIT) If the user interface (user board) cannot communicate with any other board for more than a determinated time (ex 15") any running cooking cycle will be stopped. The error icon will show a message "ECom". No cooking cycle can be launched till the comunication is established again.
  • Page 115 SKYLINE OVEN 6-10ELECTRIC SAFETY THERMOSTATS (TSC-TBS) In case of tripping of the safety thermostat TSC (cavity) or TBS (boiler) any cooking cycle in function will be stopped. If the issue is present: LEVEL T,K (touch) appliances, the dedicated icon will blink on the display "EtC" or "EtB" will be shown. LEVEL B,C (digit) appliances, the "temperature display"...
  • Page 116 SKYLINE OVEN 6-10ELECTRIC COOLING FAN (FAN1) The control of the fan is regulated according to the temperature of the inner electronic compartment. Once the appliance is turned on the ventilator will turn on at low speed. If the temperature of the inner electronic com- partment reaches 60°C to 70°C a warning message will be shown on the display "ASCH"...
  • Page 117 SKYLINE OVEN 6-10ELECTRIC ELECTRIC COMPONENTS ASSEMBLY The electric components and their function. KC1 = Cavity solid state relay, coil is activated by X30 of the ACU and controls the cavity H.Element KC2 = Cavity solid state relay, coil is activated by X30 of the ACU and controls the cavity H.Element KB1 = Boiler solid state relay, coil is activated by X31 of the ACU and controls the boiler H.Element...
  • Page 118 SKYLINE OVEN 6-10ELECTRIC PROBES Cavity (TCAV) , Boiler (TBOI) and quenching (TQS) Probes are all thermocouple type “ K ” and have the same design. For the tech specifications, refer to sheet enclosed. Specific chapters are dedicated for each thermo- couple.
  • Page 119 SKYLINE OVEN 6-10ELECTRIC 4.4.24.2 QUENCHING (TQS) Refer to technical pictures at § PROBES TQS wire color: 1 = white color The TQS thermocouple probe type “ K ” is placed in the quench- 2= yellow color ing pipe. The purpose of this probe is to sense the temperature. High temperature equals to the presence of steam that is gen- erated in the cavity and pushed through the cavity drain into the...
  • Page 120 SKYLINE OVEN 6-10ELECTRIC 4.4.24.4 COMPONENTS COMPARTMENT (NCC) The probe is an NTC 10K sensor, it is connected to the ACU on contacts X40 1/2 The NCC probe is placed in the side electronic compartment. The purpose of this probe is to sense if the compartment is heating up. If the probe will reach temp 65C° the warn- ing notification ASCH will be displayed.
  • Page 121 SKYLINE OVEN 6-10ELECTRIC 4.4.24.5.1 LEVEL PROBES (SL-WL) When the water level inside the boiler is lower than the SL the cooking cycle is paused till the water level is not restored to SL. In case of low water level: LEVEL T (touch) appliances, the dedicated icon will blink on the display. LEVEL B (digit) appliances, the "temperature display"...
  • Page 122 SKYLINE OVEN 6-10ELECTRIC 4.4.24.5.2 TEMPERATURE (TBOI) SEE PICTURES AT PROBES. If the boiler temperature is higher than the stetted PAR_MAX_TBOL parameter, any running cycle will be stopped. No cooking cycles can be started until the temperature has reached a value lower than PAR_MAX_TBOL. If the alarm is present: LEVEL T,K (touch) appliances, the error icon will light up and a message on the dis- played "...
  • Page 123 SKYLINE OVEN 6-10ELECTRIC 4.4.24.6 LAMBDA If there is a failure in the lambda sensor any cooking cycle involving the humidity control will be stopped. If the failure is present: LEVEL T,K (touch) appliances, the error icon will light up and a message on the displayed " ELMb " will show. LEVEL B,C (digit) appliances, the error icon will light up and on the temperature display "...
  • Page 124 SKYLINE OVEN 6-10ELECTRIC Lambda sensor is sequentially feeded from approximately 8V to 13V on pin 3 and 4, after a first warm up period where the supplied voltage is <2V to avoid any thermal chock on ceramic sensor. At the switch on of the oven the Lambda is cold and there may be some water condensation on it. After a first warm up, the Lambda is the ready for a correct oxygen reading.
  • Page 125 SKYLINE OVEN 6-10ELECTRIC 4.4.24.7 FOOD PROBE (TFP) If one of the food measuring points fails the message " Eprb" will be shown on the display; any cooking cycle involving the probe will be stopped. If the alarm is active: LEVEL T,K (touch) appliances have a multipoint food probe, core temperature cycles will be active only if the appliance is equipped with a multi sensor food probe and at least one "point"...
  • Page 126 SKYLINE OVEN 6-10ELECTRIC MICROSWITCH COOLING AIR FILTER PRESENCE (AFS) AND DOOR (DS) In case that the contact of the micro switch AFS is OPEN the feedback to the ACU will result in "air filter absent"; a warning message will be displayed "ACF". The door sensor DS is the door read that will detect if the door is open/closed.
  • Page 127 SKYLINE OVEN 6-10ELECTRIC VENTING VALVE (VV1) The venting air valve , when opened, will help to eliminate the humidity from the cavity. The negative pressure behind the fan will cause dry air from the kitchen be sucked into the cavity (refer also to QUENCHING SYSTEM STEAM).
  • Page 128 SKYLINE OVEN 6-10ELECTRIC TROUBLESHOOTING INTRODUCTION The following chapters are intended only for authorized technicians / engineers. TECHNICIAN TROUBLESHOOTING ALARMS & WARNINGS Type of Anomaly Description Possible causes Instructions to User Action for Service anomaly Air filter absent, it is possi- Check filter microswitch connections;...
  • Page 129 SKYLINE OVEN 6-10ELECTRIC Type of Anomaly Description Possible causes Instructions to User Action for Service anomaly Broken heating ele- The oven has detected a Boiler excessive ment Verify boiler heating element; Solid N°224 low performance in the Warning temperature rais- Broken Solid State state relay;...
  • Page 130 SKYLINE OVEN 6-10ELECTRIC Type of Anomaly Description Possible causes Instructions to User Action for Service anomaly Do not switch the oven Off; Activates at 95C°. Check room tem- Wait for the temperature to perature considering the oven needs Inlet air filter dirty; decrease;...
  • Page 131 SKYLINE OVEN 6-10ELECTRIC Type of Anomaly Description Possible causes Instructions to User Action for Service anomaly Activates at 115C°. Carry out a de- scale cycle with C25; check boiler & probes For level Touch perform boiler N° Parameter bSCt maintenance command Warning Descale boiler Scale in the boiler...
  • Page 132 SKYLINE OVEN 6-10ELECTRIC Type of Anomaly Description Possible causes Instructions to User Action for Service anomaly Food probe misuse Check X15, X16 and X17 on ACU (for example, wire §POWER BOARD Stops It is possible to run cycles N°320 pulled or Check food probe only food Core probe fai-...
  • Page 133 SKYLINE OVEN 6-10ELECTRIC Type of Anomaly Description Possible causes Instructions to User Action for Service anomaly Check cavity temperature sensor Launch a cooling cycle; if readings not possible open the door §CAVITY (TCAV) and let the oven to cool Check correct cavity temperature The cavity is dirty;...
  • Page 134 SKYLINE OVEN 6-10ELECTRIC Type of Anomaly Description Possible causes Instructions to User Action for Service anomaly Stops cleaning, stop cooking Water solenoid Switch the oven Off/On; boiler filling not working. For service, cycles, N°228 valve EV5 not If the error persists, manu- check X5 excluding Hd05...
  • Page 135 SKYLINE OVEN 6-10ELECTRIC Type of Anomaly Description Possible causes Instructions to User Action for Service anomaly Parameters memory cor- Stops Memorized para- Issue with the SW Default all parameters / reload soft- PFAC rupted; Try to switch the machine meters corrupted or with the HW ware oven Off/On...
  • Page 136 SKYLINE OVEN 6-10ELECTRIC TROUBLESHOOTING OTHERS THERMOCOUPLE PROBES TYPE “ K ” The thermocouple probe “K” is connected to the boiler, is communicating with the ACU and gives feedback regarding the temperature. To check if the TC is working correctly with a standard volt meter; set to the Ohm’s /Continuity function by checking across the positive and negative leads, in order to determine if the probe circuit is open or not.
  • Page 137 SKYLINE OVEN 6-10ELECTRIC SERVICING THE APPLIANCE The following chapters are intended only for authorized technicians / engineers WARNING ! Take GREAT CARE when connecting / testing anything with live current, if you are unsure what you are doing and how to use your equipment safely, then DON'T DO IT. LIST OF NEEDED TOOLS Complete Socket &...
  • Page 138 SKYLINE OVEN 6-10ELECTRIC REPLACING EQUIPMENT COMPONENTS Integral explanation according to the systems reported in section FUNCTIONAL/TECHNICAL DESCRIPTION DISASSEMBLY/REASSEMBLE OF COMPONENTS This chapter explains how to remove various parts of the equipment to access its functional components: please always refer to this guide to access various parts. To locate the component of interest, please refer to the ELECTRIC COMPONENTS AND PROBES HEAT-...
  • Page 139 SKYLINE OVEN 6-10ELECTRIC PANELS REMOVAL...
  • Page 140 SKYLINE OVEN 6-10ELECTRIC CONTROL PANEL ATTENTION The stainless steel control panel is NOT removable like previous models!! It is fixed to the oven frame. Only the panel of the electronic board can be opened like indicated...
  • Page 141 SKYLINE OVEN 6-10ELECTRIC DOOR REMOVAL, LED BAR & DOOR HANDLE...
  • Page 142 SKYLINE OVEN 6-10ELECTRIC 6.3.3.1 DOOR ADJUSTMENT...
  • Page 143 SKYLINE OVEN 6-10ELECTRIC HEATING AND HYDRAULIC SYSTEM Pos. Component § Boiler heating element 6.3.4.1 6.3.4.3 Motor ventilator 6.3.4.3 Cavity heating ele- 6.3.4.2 ment Air Break 6.3.4.4 Cavity drain valve 6.3.4.5 Wash pump 6.3.4.6 Boiler drain valve 6.3.4.5 Inlet water valves 6.3.4.7 Valves assembly 6.3.4.8...
  • Page 144 SKYLINE OVEN 6-10ELECTRIC 6.3.4.1 BOILER HEATING ELEMENT Remove the panels At page PANELS REMOVAL...
  • Page 145 SKYLINE OVEN 6-10ELECTRIC 6.3.4.2 CAVITY HEATING ELEMENT Remove the panels At page PANELS REMOVAL...
  • Page 146 SKYLINE OVEN 6-10ELECTRIC 6.3.4.3 FAN AND MOTOR VENTILATOR Remove the panels At page PANELS REMOVAL...
  • Page 147 SKYLINE OVEN 6-10ELECTRIC 6.3.4.4 AIR BREAK Remove the panels At page PANELS REMOVAL...
  • Page 148 SKYLINE OVEN 6-10ELECTRIC 6.3.4.5 BOILER AND CAVITY, DRAIN VALVE Remove the panels At page PANELS REMOVAL = CAVITY DRAIN VALVE = BOILER DRAIN VALVE REMOVE PLAS- TIC CUP UNSCREW...
  • Page 149 SKYLINE OVEN 6-10ELECTRIC 6.3.4.6 WASH PUMP Remove the panels At page PANELS REMOVAL...
  • Page 150 SKYLINE OVEN 6-10ELECTRIC 6.3.4.7 INLET WATER VALVES Remove the panels At page PANELS REMOVAL...
  • Page 151 SKYLINE OVEN 6-10ELECTRIC 6.3.4.8 VALVE ASSEMBLY Remove the panels At page PANELS REMOVAL...
  • Page 152 SKYLINE OVEN 6-10ELECTRIC 6.3.4.9 DISPENSER RINSE AID...
  • Page 153 SKYLINE OVEN 6-10ELECTRIC 6.3.4.10 SHOWER ASSEMBLY & VALVE...
  • Page 154 SKYLINE OVEN 6-10ELECTRIC 6.3.4.11 BOILER Remove the panels At page PANELS REMOVAL...
  • Page 155 SKYLINE OVEN 6-10ELECTRIC 6.3.4.12 FLOWMETER Remove the panels At page PANELS REMOVAL...
  • Page 156 SKYLINE OVEN 6-10ELECTRIC 6.3.4.13 CAVITY AIR VENT VALVE Remove the panels At page PANELS REMOVAL...
  • Page 157 SKYLINE OVEN 6-10ELECTRIC ELECTRIC COMPONENTS AND PROBES § Pos. Component Inverter 6.3.5.1 Switching feeder 1 6.3.5.2 Switching feeder 2 6.3.5.2 User board Level 6.3.5.3 User board Level 6.3.5.3 Display Level T.K. B23a 6.3.5.4.1 Power board 6.3.5.5 Door led bar 6.3.3 Safety thermostat 6.3.5.6 cabinet...
  • Page 158 SKYLINE OVEN 6-10ELECTRIC 6.3.5.1 INVERTER Remove the control panel At page PANELS REMOVAL WARNING! Danger of electrocution - dangerous voltage. Before checking any electric components, be sure to disconnect the main supply and verify with a meter the main electrolytic capacitors (i.e. being fitted on Inverter, SMPS) are discharged to safe voltage levels. The charge capacitor may hold high-voltage even after the power is disconnected.
  • Page 159 SKYLINE OVEN 6-10ELECTRIC 6.3.5.2 SWITCHING FEEDER 1 AND 2 Remove the control panel At page PANELS REMOVAL WARNING! Danger of electrocution - dangerous voltage. Before checking any electric components, be sure to disconnect the main supply and verify with a meter the main electrolytic capacitors (i.e.
  • Page 160 SKYLINE OVEN 6-10ELECTRIC 6.3.5.3 USER BOARD Remove the control panel At page PANELS REMOVAL 6.3.5.3.1 LEVEL T, K (TOUCH SCREEN) Disconnect all cables...
  • Page 161 SKYLINE OVEN 6-10ELECTRIC 6.3.5.3.2 LEVEL B, C (DIGIT) 6.3.5.3.3 ACCESS DISPLAY AND REPLACEMENT OF MEMBRANE STICKER ATTENTION The replacement of the membrane sticker requires also the replacement of the frame, this because the glue of the membrane cannot be removed as it is a particular adhesive glue/resin and once exposed to air becomes very difficult to take off and clean.
  • Page 162 SKYLINE OVEN 6-10ELECTRIC LEVEL T, K (TOUCH SCREEN) Use a new frame!! Disconnect all cables, take great attention to not damage the Indicated cables...
  • Page 163 SKYLINE OVEN 6-10ELECTRIC...
  • Page 164 SKYLINE OVEN 6-10ELECTRIC ATTENTION Reconnect / fit back particular adhesive glue/resin of the membrane , once ex- posed to air, becomes very difficult to re- move. The reaction will be complete in approx. 30 minutes. In case of need to realign the new membrane time is very limitated...
  • Page 165 SKYLINE OVEN 6-10ELECTRIC LEVEL B, C (DIGIT)
  • Page 166 SKYLINE OVEN 6-10ELECTRIC ATTENTION = the particular adhesive glue/resin of the membrane , once exposed to air, becomes very difficult to remove. The re- action will be complete in approx. 30 minutes. In case of need to realign the new membrane time is very limitated...
  • Page 167 SKYLINE OVEN 6-10ELECTRIC 6.3.5.4 POWER BOARD, ACU Remove the control panel At page PANELS REMOVAL...
  • Page 168 SKYLINE OVEN 6-10ELECTRIC 6.3.5.5 SAFETY THERMOSTAT CAVITY AND BOILER Remove the panels At page PANELS REMOVAL GAIN ACCESS FIRST FOLLOW OPERA- TIONS AT § POWER BOARD Additional information RESET THE SAFETY THERMOSTAT AS INDICATED.
  • Page 169 SKYLINE OVEN 6-10ELECTRIC 6.3.5.6 ELECTRIC COMPONENTS ASSEMBLY Remove the panels At page PANELS REMOVAL A = SOLID STATE RELAY H.E. CAVITY KC1 KC2 B = SOLID STATE RELAY H.E. BOILER KB1, KB2 C = TOROIDAL CHOKE COIL D = TERMINAL BOARD E = CONTACTOR/RELAY, KS F = CLAMP JOINT G = FUSE TERMINAL, F1, F2...
  • Page 170 SKYLINE OVEN 6-10ELECTRIC 6.3.5.7 COOLING DOWN MOTOR VENTILATOR Remove the panels At page PANELS REMOVAL...
  • Page 171 SKYLINE OVEN 6-10ELECTRIC 6.3.5.8 PROBES Remove the panels At page PANELS REMOVAL 6.3.5.8.1 SAFETY PUMP (NM8) The drain probe is positioned behind the shower as- sembly, please refer to this chapter before to proceed § SHOWER ASSEMBLY 6.3.5.8.2 CAVITY (TCAV) To gain access follow the dismantling instructions of chapter §...
  • Page 172 SKYLINE OVEN 6-10 ELECTRIC 6.3.5.8.5 LAMBDA Remove the panels At page PANELS REMOVAL...
  • Page 173 SKYLINE OVEN 6-10 ELECTRIC SKYLINE OVEN 6-10 GAS 6.3.5.8.6 WATER LEVEL SL-WL Remove the panels At page PANELS REMOVAL...
  • Page 174 SKYLINE OVEN 6-10 ELECTRIC 6.3.5.8.7 FOOD PROBE Remove the panels At page PANELS REMOVAL GAIN ACCESS FIRST FOL- LOW OPER- ATIONS AT § POWER BOARD Page 165 Image 1 / 2 / 3 / 4...
  • Page 175 SKYLINE OVEN 6-10 ELECTRIC 6.3.5.8.8 SAFETY PROBE (SSR) Remove the panels At page PANELS REMOVAL 6.3.5.8.9 COMPONENTS COMPARTMENT PROBE (NCC) Remove the panels At page PANELS REMOVAL...
  • Page 176 SKYLINE OVEN 6-10 ELECTRIC 6.3.5.8.10 DOOR SENSOR (DS) Remove the panels At page PANELS REMOVAL The DS sensor is located under the drip tray. PREVENTIVE MAINTENANCE All documentation for each PNC is available for authorized technicians on the web sites (PRIDE-SERVICE PORTAL- AGELUX etc..) and can be downloaded in file.
  • Page 177 SKYLINE OVEN 6-10 ELECTRIC RELATED DOCUMENTS EXPLODED VIEW All documentation for each PNC is available for authorized technicians on the web sites (PRIDE-SERVICE PORTAL- AGELUX etc..) and can be downloaded in file. For those that do not have access to the web sites, refer to your local country customer care.
  • Page 178 SKYLINE OVEN 6-10 ELECTRIC ELECTRICAL WIRING DIAGRAM All documentation for each PNC is available for authorized technicians on the web sites (PRIDE-SERVICE PORTAL- AGELUX etc..) and can be downloaded in file. For those that do not have access to the web sites, refer to your local country customer care.
  • Page 179 SKYLINE OVEN 6-10 ELECTRIC...
  • Page 180 SKYLINE OVEN 6-10 ELECTRIC...
  • Page 181 SKYLINE OVEN 6-10 ELECTRIC...
  • Page 182 SKYLINE OVEN 6-10 ELECTRIC...
  • Page 183 SKYLINE OVEN 6-10 ELECTRIC...
  • Page 184 SKYLINE OVEN 6-10 ELECTRIC WATER PIPING DIAGRAM BV3= Cavity drain valve EV7= Cleaning / water fill valve, BV6= Boiler Drain Valve (depending on level) EV11= Rinse dispenser, for boiler descale cycle CWI1= Cold water inlet EV12= Drain dispenser aid CWI2= Cold water inlet (treated water) FM= Flow meter EV1 = HUMIDIFIER / ISG valve (depending on level) M8= Pump...
  • Page 185 SKYLINE OVEN 6-10 ELECTRIC CERTIFICATES OF CONFORMITY All documentation for each PNC is available for authorized technicians on the web sites (PRIDE-SERVICE PORTAL- AGELUX etc..) and can be downloaded in file. For those that do not have access to the web sites, refer to your local country customer care.
  • Page 186 SKYLINE OVEN 6-10 ELECTRIC Diamond Professional SpA Sede legale Viale Treviso, 15 33170 Pordenone, ITALY Fax (+39) 0434 380 201 http:// professional.Diamond.com...

This manual is also suitable for:

228720
