CD Stereo System
NSX-R71
EZ
8C-NF6-906-01
020320AKH-U-M
OPERATING INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MODE D'EMPLOI
BEDIENUNGSANLEITUNG
ISTRUZIONI PER L'USO
GEBRUIKSAANWIJZING
NÁVOD K OBSLUZE
HASZNÁLATI UTASÍTÁS
INSTRUKCJA OBS£UGI
En
(English)
E
(Español)
F
(Français)
D
(Deutsch)
I
(Italiano)
NL
(Nederlands)
Cz
(Česky)
M
(Magyar)
Po
(Polski)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NSX-R71 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aiwa NSX-R71

Summary of Contents for Aiwa NSX-R71

  • Page 1 CD Stereo System NSX-R71 8C-NF6-906-01 020320AKH-U-M OPERATING INSTRUCTIONS MANUAL DE INSTRUCCIONES MODE D'EMPLOI BEDIENUNGSANLEITUNG ISTRUZIONI PER L'USO GEBRUIKSAANWIJZING NÁVOD K OBSLUZE HASZNÁLATI UTASÍTÁS INSTRUKCJA OBS£UGI (English) (Español) (Français) (Deutsch) (Italiano) (Nederlands) (Česky) (Magyar) (Polski)

  • Page 2: Precautions

    Invisible laser radiation when open and interlocks defeated. Avoid exposure to beam. NOTE AIWA CO. LTD. - JAPAN - DECLARES UNDER ITS OWN RESPONSIBILITY THAT THE PRODUCT DESCRIBED IN THIS MANUAL IS IN COMPLIANCE WITH THE DIRECTIVES OF D.M 28.8.95 No. 548, ACCORDING TO THE STIPULATIONS OF PARAGRAPH 3 OF ATTACHMENT A OF D.M.

  • Page 3: Table Of Contents

    CD OPERATIONS ... 10 RADIO OPERATIONS ... 12 TAPE OPERATIONS ... 16 SOUND ADJUSTMENTS ... 19 TIMER OPERATIONS ... 20 REFERENCE ... 22 System and accessories NSX-R71 CX-NR71 CD stereo cassette receiver SX-NR70 Front speakers Remote control FM antenna MW/LW antenna...

  • Page 4: Preparations

    PREPARATIONS Connection Plug in the AC power cord to the wall socket after all other connections are made. 1 Connect the front speakers. Connect the right front speaker (marked "R" on the rear side) to the SPEAKERS R terminals and place it on the right side of the unit.

  • Page 5: Parts And Controls

    PARTS AND CONTROLS Main unit: rear 1 CD DIGITAL OUT (OPTICAL) jack Outputs CD digital sound signals to digital audio equipment. Remove the dust cap and connect using an optional optical cable plug. When this jack is not being used, attach the supplied dust cap. 2 MW/LW LOOP, FM 75 Ω...

  • Page 6: Phones Jack

    Main unit: front 1 Dial Function Selects a function (TAPE, TUNER, VIDEO/AUX or CD). DECK 1/2 Selects DECK 1 or 2 in Tape function. BAND Select a band in Tuner function. 2 POWER 6STANDBY/ON Switches the unit on and off (standby). DEMO/ECO When the unit is turned off: switches DEMO on and off.
  • Page 7 Remote control Buttons with the same or similar names with the main unit basically have the same function. 1 POWER Enters Graphic Equalizer setting mode. SOUND ENTER 2 0-9, +10 CD: selects a CD track of the specified number. Radio: tunes in to the station with the specified preset number.

  • Page 8: Adjustments Before Operations

    ADJUSTMENTS BEFORE OPERATIONS Power Turning the unit on Press POWER 6 STANDBY/ON (POWER on the remote control). Turning the unit off Press POWER 6STANDBY/ON again. The unit goes into standby. Volume Turn VOLUME (Press VOLUME +, - on the remote control).

  • Page 9: Setting The Clock

    ECO mode Reduces power consumption with the following operations, etc. ECO ON mode - The unit blacks out when the unit is turned off. Only the red indicator lights up. (Only when the clock is set.) - If dimmer mode is set to on, the unit illumination brightens (for 10 seconds) only when you operate the unit.

  • Page 10: Cd Operations

    CD OPERATIONS This unit plays back finalized CD-R/RW discs as well as audio CDs. Playback 1 Turn the Dial Function to select the CD function and load disc(s). Press zCD OPEN/CLOSE to open the disc compartment and place one or two disc(s) with the labelled side up. To place three discs, press DISC CHANGE so that the trays rotate, then place the third one.

  • Page 11: Programmed Playback

    Programmed playback Plays back up to 30 selected tracks in programmed order. 1 Press SHIFT+PROGRAM on the remote control during stop. "PRGM " flashes on the display. 2 Press CD DIRECT on the remote control and then press the numbered button (1-3) within 3 seconds to select a disc.

  • Page 12: Radio Operations

    RADIO OPERATIONS Manual tuning 1 Turn the Dial Function to select the TUNER function. 2 Press BAND to select a band (FM, MW or LW). 3 Press f or g to tune in to a station. "TUNE " is displayed when a station is tuned in. "1"...

  • Page 13: Rds Features

    Tuning in to preset stations On the unit 1 Turn the Dial Function to select the TUNER function and press BAND to select a band. 2 Press d repeatedly or turn MULTI JOG. With each press, the station with the succeeding preset number is tuned in.

  • Page 14: Pty Search

    PTY Search The unit can search for a station broadcasting your desired PTY easily. To do so, you need to preset every available station in advance since the unit searches only the preset stations. 1 Press PTY. 2 Press f or g to select a desired program type and then press PTY.

  • Page 15: Clock-Time (Ct)

    Auto Graphic equalizer (AG) The unit automatically selects a sound equalization curve to match the music program type (PTY) data being transmitted from the station. (e.g. 'POP' curve is selected for POP M [PTY].) Press AG when tuning in to an RDS station. "AG "...

  • Page 16: Tape Operations

    TAPE OPERATIONS Playback Use only type I (normal) tapes. 1 Turn the Dial Function to select the TAPE function. 2 Press z PUSH EJECT/CLOSE on either side (DECK 1 and DECK 2) to open the outer cassette holder and insert the tape in the deck. Insert with the exposed side down and playback side facing out from the unit.

  • Page 17: Ai Edit Recording

    Basic recording Use only type I (normal) tapes. DECK 2 is the recording deck. Only one side of the tape can be recorded at a time. 1 Insert the recording tape in DECK 2. Press zPUSH EJECT/CLOSE to open the outer cassette holder, and insert with the exposed side down and the side to be recorded on facing out from the unit.

  • Page 18: Programmed Edit Recording

    6 Press wREC/REC MUTE to start recording on side A. On the remote control, press REC MODE and then press wREC/REC MUTE within 3 seconds. The tape is rewound to the beginning of side A and recording starts. Go to the next step when recording on side A finishes. 7 Press SHIFT+CD EDIT/CHECK once on the remote control.

  • Page 19: Sound Adjustments

    SOUND ADJUSTMENTS Graphic equalizer Selects a sound equalization curve to match the music type. Press MODE once and then turn MULTI JOG within 4 seconds to select one of the four equalization curves. On the remote control, press GEQ and then press PRESET N or M repeatedly within 4 seconds.

  • Page 20: Timer Operations

    TIMER OPERATIONS Sleep timer Turns off the unit automatically after a specified time. 1 Press SHIFT+SLEEP on the remote control. "SLP" appears on the display. 2 Press f or g repeatedly to set the sleep timer duration. With each press, the timer duration changes in 5-minute steps between 5 to 240 minutes.

  • Page 21: Timer Recording

    To display the timer setting Press TIMER. The timer-on time, the source and the timer-activated duration are displayed for 6 seconds. Tip: Timer setting can be displayed even while the unit is turned off, and at that time if you press ENTER or a within 6 seconds after TIMER is pressed, you can enter the timer setting mode and change the setting.

  • Page 22: Reference

    REFERENCE Care and maintenance Occasional care and maintenance of the unit and the software are needed to optimize the performance of your unit. To clean the cabinet Use a soft and dry cloth. If the unit surfaces are extremely dirty, use a soft cloth lightly moistened with mild detergent solution.

  • Page 23: Specifications

    Specifications MAIN UNIT CX-NR71 TUNER FM tuning range 87.5 MHz to 108 MHz FM usable sensitivity (IHF) 16.8 dBf FM antenna terminal 75 ohms (unbalanced) MW tuning range 531 kHz to 1602 kHz (9 kHz step) 530 kHz to 1710 kHz (10 kHz step) MW usable sensitivity 350 µV/m LW tuning range...
  • Page 24 ADVARSEL! Usynlig laserståling ved åbning, når sikkerhedsafbrydereer ude af funktion. Undgå udsættelse for stråling. VAROITUS! Laitteen käyttäminen muulla kuin tässä käyttöohjeessaa mainitulla tavalla saattaa altistaa käyttäjän turvallisuusluokan 1 ylittävälle näkymättömälle lasersäteiylle. VARNING! Om apparaten används på annat sätt än i denna bruksanvisning specificerats, kan användaren utsätta för osnylig laser- strålning, som överskrider gränsen för laserklass 1.
