COOKERS

Majestic

User Instructions, Installation, Maintenance

Cookers characteristics

These warnings refer to different models of cookers.

Be sure that you have correctly identified the model that you possess (see the rating

plate).

MODEL

UM30

UM09

UMD10

UM12

UM15

UMI30

UMI09

UMDI10

DIMENSIONS

29 7/8" (W) x 27 9/16" (D) x 35 55/04" (H)

35 7/8" (W) x 27 9/16" (D) x [34 1/4"- 36 1/8"] (H)

39 3/8" (W) x 27 9/16" (D) x [34 1/4"- 36 1/8"] (H)

47 7/8" (W) x 27 9/16" (D) x [34 1/4"- 36 1/8"] (H)

59 1/2" (W) x 27 9/16" (D) x [34 1/4"- 36 1/8"] (H)

29 7/8" (W) x 27 9/16" (D) x 35 55/04" (H)

35 7/8" (W) x 27 9/16" (D) x [34 1/4"- 36 1/8"] (H)

39 3/8" (W) x 27 9/16" (D) x [34 1/4"- 36 1/8"] (H)

cod.EI33960100000EN

48/2022
