Andrus 18" Terrafab Fire Column
ITM./ART.#: ANBCFC1818A
MODEL#: F190006-A1
ANS Z21.97 CSA 2.41-2017
Outdoor Decorative Gas Appliances
Maximum inlet supply pressure: 13 in wc (3.24 KPa)
Minimum inlet supply pressure: 8 in wc (1.99 KPa)
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference
DANGER
FIRE OR EXPLOSION HAZARD
If you smell gas:
Shut off gas to the appliance.
Extinguish any open flame.
If odor continues, leave the area immediately.
After leaving the area, call your gas supplier or fire
department.
Failure to follow these instructions could result in
fire or explosion, which could cause property
damage, personal injury, or death.
DANGER
WARNING:
If the information in this manual is not followed exactly, a fire or explosion may result causing
property damage, personal injury, or loss of life.
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such as a camper,
tent, car or home.
WARNING: For Outdoor Use Only.
Installation and service must be
performed by a qualified installer,
service agency, or the gas supplier.
WARNING
Do not store or use gasoline, or other
flammable vapors and liquids,in the
vicinity of this or any other
appliance.
An LP-cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
01
Advertisement
Related Manuals for Foremost Groups Andrus Terrafab F190006-A1
Summary of Contents for Foremost Groups Andrus Terrafab F190006-A1
- Page 1 Andrus 18" Terrafab Fire Column ITM./ART.#: ANBCFC1818A MODEL#: F190006-A1 ANS Z21.97 CSA 2.41-2017 Outdoor Decorative Gas Appliances Maximum inlet supply pressure: 13 in wc (3.24 KPa) Minimum inlet supply pressure: 8 in wc (1.99 KPa) INSTALLER: Leave this manual with the appliance. WARNING: For Outdoor Use Only.
- Page 2 IMPORTANT SAFETY INFORMATION The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1 NFPA 54; National Fuel Gas Code; Natural Gas and Propane Installation Code, CSA B149.1; ● or Propane Storage and Handling Code, CSA B149.2, as applicable.
- Page 3 IMPORTANT SAFETY INFORMATION ABOUT PROPANE (LP) GAS The LP-gas supply cylinder to be used must be constructed and marked in accordance with the U.S. Deparment of Transportation (D.O.T.) Specifications for LP-Gas Cylinders, or the Standard for Cylinders, Spheres and Tubes for Transportation of Dangerous Goods and Commission, CAN/CSA-B339, as applicable. The LP-gas supply cylinder to be used must have a listed overfilling prevention device (See Figure 1).
- Page 4 PACKAGE CONTENTS PART DESCRIPTION QUANTITY Fire table 1 pc 1 pc Door 1 pc Weather cover Lava rock (5.51 Ibs) 1 box ASSEMBLY INSTRUCTIONS Carefully unpack all parts from the box, compare parts with package content listed above, make sure all parts are present before beginning assembly of product.
- Page 5 4. Place the gas cylinder into the cylinder holder. Secure the cylinder by tightening clockwise the retention point found on the cylinder holder, so that the cylinder cannot move from side to side or fall down. Connect the regulator, screw the black handle clockwise to tighten, turn the black handle counterclockwise to remove. The hose must point down.
- Page 6 BATTERY Make sure the control knob is in the “OFF” position. Unscrew the push button cap on the ignitor module located on the control panel to access the battery compartment. The ignitor module requires one AAA size battery (See Figure 6), BATTERY IS NOT INCLUDED. WARNING: 1.
- Page 7 gas valve-hose connection (Figure 9) inlet tube-bellows connection (Figure 10) To perform a leak test: Make 2~3 oz. of leak solution by mixing one part liquid dishwashing detergent and three parts water. NOTE: make sure control knob is “OFF”. Apply several drops of solution where the cylinder attaches to regulator (See Figure 7), inspect the solution at the connection looking for bubbles.
- Page 8 Observe Flame Height When Lit: The burner will display blue and yellow flames. These flames should be a blue / yellow color between 1~2 in. height (See Figure 12). These flames should not be yellow or produce thick smoke. This would indicate an obstruction of airflow through the burners. The flames should be blue with straight yellow tops.
- Page 9 REPLACEMENT PARTS LIST F190006-A1-A Fire table assembly F190006-A1-B Door F190006-A1-C Weather cover F190006-A1-D Lava rocks F190006-A1-E Thermocouple F190006-A1-F Hose assembly F190006-A1-G Foot glider...
- Page 10 Should replacement of the warranted item be unavailable, Foremost Groups Inc. reserves the right to substitute items of our choice similar in style, color and quality. For quality control purposes and verification, we reserve the right to request photographs of the damage item(s).
