FIRE-78-8-UA
Installation and Operating Manual
Version 0.1
3116 West Vanowen St.
Burbank, CA 91505
Tel: 818-840-8131
Fax: 818-840-8138
www.adrftech.com
Advanced RF Technologies, Inc.
i

Advertisement

loading
Need help?

Need help?

Do you have a question about the FIRE-78-8-UA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ADRF FIRE-78-8-UA

Summary of Contents for ADRF FIRE-78-8-UA

  • Page 1 FIRE-78-8-UA Installation and Operating Manual Version 0.1 3116 West Vanowen St. Burbank, CA 91505 Tel: 818-840-8131 Fax: 818-840-8138 www.adrftech.com Advanced RF Technologies, Inc.
  • Page 2 Information in this document is subject to change without notice. Advanced RF Technologies, Inc. 1996-2022. All rights reserved.  Please send comments to: E-Mail: info@adrftech.com Phone: (818) 840-8131 (800) 313-9345 Fax: (818) 840-8138  Address: Advanced RF Technologies, Inc. Attention: Technical Publications Department 3116 Vanowen St.
  • Page 3 Revision History Version Author Descriptions Date CK CHO Initial Release 2022/04/17 Change List Version Change list Contents Advanced RF Technologies, Inc.
  • Page 4 Summary Alarm ............................20 RF ................................21 Optic ................................22 Battery ............................... 23 This port connects to the ADRF-BBS/BBL-24 (24V battery backup unit) via a dedicated cable provided by the ADRF............................. 23 Grounding ..............................24 ADXV-R-3378P-UA Wiring Compartment ....................25 3.8.1 AC 100-240V Terminal Block ......................
  • Page 5 Figure 1-1 FIRE-78-8-UA Quick View (front and bottom) ..................9 Figure 2-1 FIRE-78-8-UA DAS topology ........................ 17 AC Power port..............오류! 책갈피가 정의되어 있지 않습니다. Figure 3-1 Figure 3-2 External Alarm port ..........................19 Figure 3-3 RF port ..............................21 Figure 3-4 Optic port............................
  • Page 6 The following is a list of abbreviations and terms used throughout this document. Abbreviation/Term Definition Automatic Gain Control Automatic Level Control AROMS ADRF’ Repeater Operation and Management System Band Combiner Unit Base Transceiver Station Bi-directional Amplifier CDMA Code Division Multiple Access...
  • Page 7 1. INTRODUCTION FIRE-78-8-UA which is the wireless Head end of Distributed Antenna System for PS-700/800 band has roles which interfaces with Base Station via wireless and optically distributes by connection with multiple ADXV-R-3378P-UA, which is one of the ADRF’s DAS product lineups, via optic lines.
  • Page 8 Parts List Table 1-1 Parts List Label Quantity Description FIRE-78-8-UA Wall Mount Bracket Mounting Bracket Template AAI Alarm Cable AC Power Cable Ethernet Cable (Crossover) Anchor Bolt Documentation CD PSR-ANN (Annunciator) Figure 1-1 FIRE-78-8-UA Parts List Advanced RF Technologies, Inc.
  • Page 9 Optic 5~8 Port Battery backup Port AC Input Port Donor Port Annunciator Communication / (4.3-10 Female) Power Port Summary AAI FIRE-78-8-U AAI Alarm Port Alarm Port Heat Sink Figure 1-2 FIRE-78-8-UA Quick View (front and bottom) Advanced RF Technologies, Inc.
  • Page 10 Audible Alarm Speaker Alarm Indicator Lights Data/Power Port Repeater / Wall Mount Bracket Figure 1-3 PSR-ANN Annunciator Advanced RF Technologies, Inc.
  • Page 11 ADXV-R-3378P-UA Parts List Table 1-2 Parts List Label Quantity Description ADXV-R-3378P-UA Wall Mount Bracket Mounting Bracket Template AAI Alarm Cable AC Power Cable Ethernet Cable (Crossover) Anchor Bolt Documentation CD PSR-ANN (Annunciator) Figure 1-4 ADXV-R-3378P-UA Parts List Advanced RF Technologies, Inc.
  • Page 12 1.5 Remote Unit (RU) for ADXV-R-3378P-UA ADXV-R-3378P-UA is for PS78 ADXV-R-3378P-UA_RU is composed of an ORU, a PSU and an RM(PS78)  Specifications Size: 9.85 x 15.76 x 6.6 (in) Weight: 28.6lbs Power Input: 110VAC 1.6 Quick View Figure 1-5 ADXV-R-3378P-UA Front and Bottom View Advanced RF Technologies, Inc.
  • Page 13 Optic Port Backup Battery Port AC Input Port 100~240VAC Annunciator Port Server Port (4.3-10 Female) ADXV-R-3379P-U_ AAI Alarm Port Heat Sink Figure 1-2 ADXV-R-3378P-UA Quick View (front and bottom) 1.6.1 Port 78PS: SERVER, OPTIC, AC IN, BATTERY, EXTERNAL ALARM Advanced RF Technologies, Inc.
  • Page 14 1.7 Warnings and Hazards WARNING! ELECTRIC SHOCK Opening the FIRE-78-8-UA could result in electric shock and may cause severe injury. WARNING! DAMAGE TO REPEATER Operating the FIRE-78-8-UA with antennas in very close proximity facing each other could lead to severe damage to the repeater.
  • Page 15 Preclude indications that Home/ personal use are prohibited. Use of unauthorized antennas, cables, and/or coupling devices not conforming with ERP/EIRP is prohibited. FCC Part 15.21 Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. FCC Part 15 Class A NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 16 Regulatory Warning Statement FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 80 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
  • Page 17 2. TOPOLOGY Figure 2-1 FIRE-78-8-UA DAS topology Advanced RF Technologies, Inc.
  • Page 18 3.1 FIRE-78-8-UA Wiring Compartment The bottom of the FIRE-78-8-UA is a wiring compartment with pre-cut holes. These holes are designed to be used in conjunction with conduit hubs to prevent water ingress. A total of 5 pre-cut holes are available to use for the various cables that will be needed for the proper operation of the FIRE-78-8-UA.
  • Page 19 Line or Hot 12AWG AC_G Ground 12AWG 3.2 External Alarm Figure 3-3 External Alarm port This port should be connected to ADRF External Alarm Box for dry-contact alarming of FIRE-78-8-UA Table 3-3 External Alarm Port Pin Description Advanced RF Technologies, Inc.
  • Page 20 AUX_IN_N 12-NEG 3.3 Summary Alarm Figure 3-4 Summary Alarm port This port should be connected to ADRF External Alarm Box for dry-contact alarming of All RUs Table 3-4 Summary Alarm Port Pin Description ADRF External Alarm Box Pin Color Pin Description (24 pins) Description Advanced RF Technologies, Inc.
  • Page 21 Black SUMRU_Donor antenna malfunction_P 1-POS Black SUMRU_Donor antenna malfunction_N 1-NEG Brown SUMRU_Active RF device malfunction_P 2-POS Brown SUMRU_Active RF device malfunction_N 2-NEG SUMRU_Low battery capacity (70%)_P 3-POS SUMRU_Low battery capacity (70%)_N 3-NEG Orange SUMRU_System component malfunction_P 4-POS Orange SUMRU_System component malfunction_N 4-NEG Yellow SUMRU_Normal AC Power_P...
  • Page 22 3.5 Optic LINK 4 LINK 3 LINK 2 LINK 1 SC / APC Adpator OPTIC Conduit for optic Inside of FIRE - 78 - 8-U ( Conduit connector ) Figure 3-6 Optic port ODU located inside of equipment has 8 optic ports (SC/APC type) for link to ADXV-R-3378P-UA. You must verify to keep optic contact be clean and optic line’s curvature be not allowed in order to be free from optic loss when you install optic line and conduit.
  • Page 23 Figure 3-9 Battery Backup Port If an ADRF-BBS/BBL-24 is connected to the repeater, the battery switch on the PSU must be switched to the ON position. This will enable the repeater to charge the ADRF-BBS/BBL-24 battery backup unit when AC power is present.
  • Page 24 Figure 3-10 Battery Switch The FIRE-78-8-UA can be connected to an ADRF-BBS/BBL-24 to provide power during a power failure. If an ADRF-BBS/BBL-24 is utilized, connect it to the FIRE-78-8-UA via the external battery port. (WARNING: The circuit breaker switch on the ADRF-BBS/BBL-24 must be set to OFF before connecting it to the FIRE-78-8-UA to prevent damage to the repeater or the ADRF-BBS/BBL-24 and personal injury.)
  • Page 25 To maintain UL 2524 Listed status, unused ports must be properly weather proofed. Table 3-5 Pre-cut hole size and labels Silkscreen Label Location Diameter AC 100-240V BOTTOM 22.2mm (7/8”) ANNUNCIATOR BOTTOM 22.2mm (7/8”) BATTERY ADRF-BBU ONLY NON LPS BOTTOM 22.2mm (7/8”) Optic BOTTOM 22.2mm (7/8”) Advanced RF Technologies, Inc.
  • Page 26 Figure 3-12 Wiring Compartment Cutout Holes 3.8.1 AC 100-240V Terminal Block The AC 100-240V Terminal Block is located on the left side of the wiring compartment. One side of the terminal block will be pre-wired and connected to the PSU and the chassis ground. The open terminals must be connected to an AC power source between 100-240V AC and secured in an electrical breaker box on its own circuit.
  • Page 27 3.9 External Alarm Figure 3-14 External Alarm port This port should be connected to ADRF External Alarm Box for dry-contact alarming of ADXV-R-3378P-UA Table 3-7 External Alarm Port Pin Description Pin Description ADRF External Alarm Box Color (24 pins) Pin Description...
  • Page 28 SERVER Figure 3-15 RF port The RF connections are made via three “4.3-10” female connectors. The RF connector labeled “SERVER” must be connected to each antenna pointing towards the base station. The RF connections must be made through cables with characteristic impedance of 50 ohms. 3.11 Optic LINK SC / APC...
  • Page 29 Figure 3-17 Optic Connector Cleaning (left) and Optic Port Cleaning (right)   Figure 3-18 SC/APC Optic Connector Dust Cap 3.12 Battery This port connects to the ADRF-BBS/BBL-24 (24V battery backup unit) via a dedicated cable provided by the ADRF. Figure 3-19 Battery Backup Port Advanced RF Technologies, Inc.
  • Page 30 If an ADRF-BBS/BBL-24 is connected to the repeater, the battery switch on the PSU must be switched to the ON position. This will enable the repeater to charge the ADRF-BBS/BBL-24 battery backup unit when AC power is present. Figure 3-20 Battery Switch The ADXV-R-3378P-UA can be connected to an ADRF-BBS/BBL-24 to provide power during a power failure.
  • Page 31 Figure 3-21 Protective Earthing Conductor Ground terminals located on the side consisted of a 16mm²(6AWG) and should be permanently connected to earth(Protective earthing conductor). Advanced RF Technologies, Inc.
  • Page 32 4. INSTALLATION 1. To mount on a wall. Using appropriate screws and anchors, attach the BDA to the wall at the four mounting holes 2. Ensure that the isolation between the donor antenna and the service antenna is at least 15 dB greater than the BDA gain.
  • Page 33 Power of FIRE-78-8- PS 800 33dBm 30dBm UA+ADXV-R-78PS PS 700 + PS 800 33dBm 30dBm System total Gain (dB) [FIRE-78-8-UA+ADXV-R-3378P-U] System total Input power -62dBm -55dBm [FIRE-78-8-UA+ADXV-R-3378P-U] Wideband 2 (non-contiguous) Up to 16 (non-contiguous) @ PS 700 Narrowband (N Mode)
  • Page 34 Remote Alarming / Dry Contacts, Web-GUI, SNMP, SNMP-Traps (External Network Management Wireless Modem Required) Annunciator Support up to 2 PSR-ANN-L annunciators Relative Humidity 5% - 90% Operating Temperature -22°F to +131°F (-30°C to +55°C) 5.2 FIRE-78-8-UA_Mechanical Specifications Dimension (W x D x H) 11.0 x 12.2 x 21.3 in (280 x 310.5 x 540mm) w/out mounting bracket Weight...
  • Page 35 If you are not the Administrator, please type in your assigned username & password which you should have received from the Administrator. The default username and password for the General User is adrf & adrf, respectively. The default Administrator login is admin & admin, respectively.
  • Page 36 6.2 Status Tab  Figure 5-2 Status Tab Advanced RF Technologies, Inc.
  • Page 37 6.2.1 Navigation Tree The navigation tree located on the left hand side of the Web-GUI allows the user to switch between the various modules that are connected to the system. Table 5-1 Navigation tree Parameters Description Expands the entire navigation tree Collapses the entire navigation tree The module has the expandable subordinate modules The branch is currently expanded...
  • Page 38  Figure 5-3 Band Info Display 6.2.4 Power & Gain This section displays the Input, Gain, and Output for both downlink and uplink.  Figure 5-4 Power & Gain Display Input [dBm] – Displays the in-band Downlink/Uplink signal level. The system will display “--.-“ when the input level is <...
  • Page 39 Repeater Info: Displays the serial number, latitude, longitude, firmware version, and Web-GUI version Repeater Location: Displays the address where the repeater is installed Technical Support: Displays ADRF’s Technical Support contact information Installer Contact Info: Displays the installer’s name, phone, and e-mail address...
  • Page 40 Note: Once successfully logged in, the repeater model name and the site/cascade ID will be displayed on the top of all the windows (except for the Main Window). 6.3 Control Tab  Figure 5-7 Control page Advanced RF Technologies, Inc.
  • Page 41 6.3.1 General Setting The General Setting section allows the user to enable/disable amplifiers and the ALC routine.  Figure 5-8 General Setting ALC ON: Enables or disables Automatic Level Control (ALC) PSR 700 DL HPA On: Enables or disables the Downlink High Power Amplifier (HPA) for 700MHz PS PSR 800 DL HPA On: Enables or disables the Downlink High Power Amplifier (HPA) for 800MHz PS PSR 700+800 UL HPA On: Enables or disables the Uplink High Power Amplifier (HPA) for 700+800MHz PS To enable/disable any of the settings, click on the checkbox and click the Apply button.
  • Page 42 6.3.4 Alarm Settings  Figure 5-11 Alarm Settings DL Signal Low Level: Allows the user to specify how low the signal can be before triggering a “Downlink Signal Low” soft-fail alarm DL Signal Not Detected Level: Allows the user to specify how low the signal can be before triggering a “Downlink Signal Not Detected”...
  • Page 43 6.4 Install Tab 6.4.1 Install  Figure 5-12 Install Page Advanced RF Technologies, Inc.
  • Page 44 6.4.2 Technology This section allows the user to set the repeater mode to either use PS700, PS800, or PS700+PS800.  Figure 5-13 Technology The following choices are available from the dropdown:  PS700 (758-768MHz)  PS800 (851-861MHz)  PS700 +PS800 (758-861MHz) 6.4.3 Band Selection ...
  • Page 45 Downlink/Uplink Gain: Minor gain adjustments can be performed on a per channel basis to equalize signal levels Downlink Freq - Start: Displays the start frequency of the pass-band once the band selection has been set Downlink Freq - End: Displays the end frequency of the pass-band once the band selection has been set 6.4.4 SNMP ...
  • Page 46  Figure 5-18 Repeater Location Info / Repeater Installer Info 6.4.8 Date & Time This section allows the user to specify the current date and time.  Figure 5-19 Date & Time Setting Advanced RF Technologies, Inc.
  • Page 47 6.5 System The System tab allows the user to perform firmware updates, upload closeout packages, view any changes to the system, backup existing configuration, and add/remove user accounts, and change the login credentials of the Administrator. 6.5.1 System: Account 6.5.1.1 System: Account – Account Management The Account Management section allows the Administrator to delete any user accounts.
  • Page 48 6.5.1.4 System:Log - Event Log 6.5.2 User Log This section displays system events that have taken place. The Event Log displays who has made the changes, the time and date of when the event took place, and what changes were made to the system. The System Log tracks the following events ...
  • Page 49  Figure 5-24 System – User Log 6.5.4 System – Update To perform a firmware update, click on the Update tab and the following screen will appear.  Figure 5-25 System – Update Click on the Choose File button and locate the firmware file. Click on the Upgrade button to perform the firmware update.
  • Page 50  Figure 5-26 System Backup Advanced RF Technologies, Inc.
  • Page 51 6.6 Help If an internet connection is available, clicking on the Help Tab will redirect the user to our Technical Support page.  Figure 5-27 Help 6.7 Logout Clicking the Logout button will log the current user off the system. Advanced RF Technologies, Inc.
