- Page 1 Mounting instruction Adjusting the door on 20-x/1 ovens Invoq Combi & Invoq Hybrid 20-1/1 GN 20-2/1 GN Invoq Bake Other languages: 16 - 400x600 EN EN - English Part number 113149 Original English document...
- Page 3 Before replacement Tools ..............................6 Estimated working time ....................6 Oven overview Adjusting the door on 20-x/1 ovens Installing the 20-x/1 oven ....................8 Adjusting the oven door ....................10 Invoq Combi, Invoq Hybrid & Invoq Bake, mounting instruction, revision 12/2024, SW: 0.7.60...
- Page 4 General information Target group This document is aimed at service technicians who have been trained in installing and servicing the oven. The oven must only be installed and serviced by qualified service technicians. Technical changes This document is subject to changes without notice. More documentation You find more documentation about the oven at https://asset-library.invoqoven.com/...
- Page 5 All maintenance and repair must be carried out by qualified installation and service technicians only. Installation and/or service by others than qualified service technicians may result in injury to the operator and/or damage to the oven. Invoq Combi, Invoq Hybrid & Invoq Bake, mounting instruction, revision 12/2024, SW: 0.7.60...
- Page 6 Before replacement • Make sure the required tools are available. • Unpack the spare parts and check if all parts are available. • Make sure the working area is tidied up, clean and safe to prevent personal injury and damage to the equipment. Tools •...
- Page 7 OvEN OvERvIEW Oven overview Invoq Combi, Invoq Hybrid & Invoq Bake, mounting instruction, revision 12/2024, SW: 0.7.60...
- Page 8 Adjusting the door on 20-x/1 ovens Installing the 20-x/1 oven fore more information about how to install the oven, see the installation manual, which can be downloaded from the Asset library on https://asset-library.invoqoven.com/. Make sure that the tilt of the floor is no more than 2% equalling 20 mm per 1000 Make sure the oven and the roll-in trolley are parallel.
- Page 9 Connect the oven to power. Connect the oven to the water supply. Connect the oven to a HydroShield water filter or a reverse osmosis system. Connect the oven to drain. Invoq Combi, Invoq Hybrid & Invoq Bake, mounting instruction, revision 12/2024, SW: 0.7.60...
- Page 10 Adjusting the oven door Insert the roll-in trolley, and close the oven door. Warm up the oven to 300°C for 15 minutes. IMPORTANT! Steam and water might escape from the oven. 300°C 15 min Cool down the oven for 10 minutes by activating the fan via Settings । Oven setup । Test functions ।...
- Page 11 - Adjust the door gasket (C) up and down. - Adjust the rubber plugs (d) back and forth. - Adjust the catch for the handle (E) back and forth. Invoq Combi, Invoq Hybrid & Invoq Bake, mounting instruction, revision 12/2024, SW: 0.7.60...
- Page 12 Insert the roll-in trolley, and close the oven door. Remove the handle from the roll-in trolley. Warm up the oven to 300°C for 15 minutes. 300°C 15 min 10. Cool down the oven for 10 minutes by activating the fan via Settings । Oven setup । Test functions ।...
- Page 13 15. The door is correctly adjusted if: • less than 3 dl water escape from the oven, and • it is possible to close the door gently. Invoq Combi, Invoq Hybrid & Invoq Bake, mounting instruction, revision 12/2024, SW: 0.7.60...
- Page 14 This page is intentionally left blank.
- Page 15 AdjUSTING THE dOOR ON 20-x/1 OvENS This page is intentionally left blank. Invoq Combi, Invoq Hybrid & Invoq Bake, mounting instruction, revision 12/2024, SW: 0.7.60...
- Page 16 GET IN TOUCH. As your oven specialist, we always do our utmost to help our customers. Worldwide.
