- Page 1 Mounting instruction Mounting a Stackit oven Invoq Combi & Invoq Hybrid 6-1/1 GN 10-1/1 GN 6-2/1 GN 10-2/1 GN Invoq Bake Other languages 6 - 400x600 EN 9 - 400x600 EN Electric EN - English Part number 110274 Original English document...
-
Page 2: Table Of Contents
Table of contents General information Target group ..........................4 Technical changes .......................4 More documentation ......................4 Warranty ............................4 Permissions ...........................4 Safety information Before replacement Tools ..............................6 Estimated working time ....................6 Oven overview Stackit kit overview - standard oven Stackit kit overview - PassThrough oven 9 Mounting a Stackit oven Unpacking the ovens and Stackit kit .............. - Page 3 ........................31 Mounting the sideplates, standard ..............31 Mounting the sideplates, PassThrough ............32 Mounting the pipe protection cover on a PassThrough Stackit oven ..................33 Testing the oven ........................35 Invoq Hybrid, Invoq Combi and Invoq Bake, mounting instruction, revision 05/2024, SW. 0.7.41...
-
Page 4: General Information
General information Target group This document is aimed at service technicians who have been trained in installing and servicing the oven. The oven must only be installed and serviced by qualified service technicians. Technical changes This document is subject to changes without notice. More documentation You find more documentation about the oven at https://asset-library.invoqoven.com/... -
Page 5: Safety Information
All maintenance and repair must be carried out by qualified installation and service technicians only. Installation and/or service by others than qualified service technicians may result in injury to the operator and/or damage to the oven. Invoq Hybrid, Invoq Combi and Invoq Bake, mounting instruction, revision 05/2024, SW. 0.7.41... -
Page 6: Before Replacement
Before replacement • Make sure the required tools are available. • Unpack the spare parts and check if all parts are available. • Make sure the working area is tidied up, clean and safe to prevent personal injury and damage to the equipment. •... -
Page 7: Oven Overview
Stakit kit Bottom oven Stand for Stackit Table 1 for more information about mounting a Stackit oven on stand, see the mounting instruction “How to mount a stand”. Invoq Hybrid, Invoq Combi and Invoq Bake, mounting instruction, revision 05/2024, SW. 0.7.41... -
Page 8: Stackit Kit Overview - Standard Oven
Stackit kit overview - standard oven Position Description Manifold assembly for drain Cover for cooling Plate for Stackit pipes Bracket Manifold assembly for exhaust Side plate for Stackit Drain trap lip sealing Pipe air intake manifold Pipe Table 2... -
Page 9: Stackit Kit Overview - Passthrough Oven
- PassThrough oven Position Description Manifold assembly for drain Cover for cooling Plate for Stackit pipes Bracket Side plate for Stackit Drain trap lip sealing Pipe, Pipe Table 3 Invoq Hybrid, Invoq Combi and Invoq Bake, mounting instruction, revision 05/2024, SW. 0.7.41... -
Page 10: Mounting A Stackit Oven
Mounting a Stackit oven Unpacking the ovens and Stackit kit When transporting the oven, use a pallet lifter or other appropriate lifting equipment. DANGER Risk of squeezing • Never only lift the oven from the left-hand side. Leave the plastic film covering the oven surfaces until IMPORTANT! the oven is installed. -
Page 11: Mounting Two Standard Ovens As A Stackit Unit
Remove the lip sealing (1) from the exhaust pipe (2) on the bottom oven. Mount the bracket (3) on the roof of the bottom oven using two hexagon screws M5 l:12 (4). Invoq Hybrid, Invoq Combi and Invoq Bake, mounting instruction, revision 05/2024, SW. 0.7.41... - Page 12 Place the manifold assembly for drain (4) on the exhaust pipe (5). apply a silicone-based lubricant on the exhaust pipe IMPORTANT! to assure that the manifold assembly for drain easily slides onto the pipe. fasten the manifold assembly for drain (4) to the bracket (6) using two hexagon screws M5 l:12 (7).
-
Page 13: Mounting The Air Intake Manifold On The Bottom Oven
Place the air intake manifold (5) on the air intake pipe (6) for the bottom oven. fasten the air intake manifold using two hexagon screws M5 l:12 (7). Invoq Hybrid, Invoq Combi and Invoq Bake, mounting instruction, revision 05/2024, SW. 0.7.41... -
Page 14: Mounting The Legs On Top Of The Bottom Oven
Mount the pipe (8) in the hole on the air intake manifold (9). Mounting the legs on top of the bottom oven Mount the leg (1) on the rearmost, left-hand side of the oven using four hexagon screws M5 l:12 (2). - Page 15 MOUNTING a STaCkIT OvEN Mount the leg (3) on the anterior, left-hand side of the oven using four hexagon screws M5 l:12 (4). Invoq Hybrid, Invoq Combi and Invoq Bake, mounting instruction, revision 05/2024, SW. 0.7.41...
- Page 16 Mount the leg (5) on the rearmost, right-hand side using four hexagon screws M5 l:12 (6). Mount the leg (7) on the anterior, right-hand side using four hexagon screws M5 l:12 (8).
-
Page 17: Mounting The Upper Oven On The Bottom Oven
If possible, use a crane to lift the upper oven. Otherwise, the upper oven must be placed on top of the bottom IMPORTANT! oven by at least two persons but preferably three or four persons. Invoq Hybrid, Invoq Combi and Invoq Bake, mounting instruction, revision 05/2024, SW. 0.7.41... -
Page 18: Mounting The Pipes For Exhaust And Drain
lead the four allen screws 10x25 (2) through the holes in the legs on the roof of the bottom oven. fasten the screws in the holes, where the legs were mounted, on the upper oven. Mounting the pipes for exhaust and drain Place the plate for the exhaust and drain pipes (1) on the exhaust pipe (2). - Page 19 MOUNTING a STaCkIT OvEN Slide the exhaust pipe (3) through the hole of the plate (4) and place it in the manifold assembly for exhaust (5). Invoq Hybrid, Invoq Combi and Invoq Bake, mounting instruction, revision 05/2024, SW. 0.7.41...
- Page 20 Slide the drain pipe (6) through the hole of the plate (7) and place it in the manifold assembly for drain (8). Place one end of the lower drain pipe (9) in the manifold for drain (10) Place the other end of the lower drain pipe (9) in the drain trap (11). Drill holes on the back plate of the bottom oven in the marked areas using a 4.2 drill and a M5 threaded tap.
-
Page 21: Mounting The Cooling Plate
“Mounting the sideplates, standard”. • for more information about how to test the ovens, see section “Testing the oven”. Invoq Hybrid, Invoq Combi and Invoq Bake, mounting instruction, revision 05/2024, SW. 0.7.41... -
Page 22: Mounting Two Passthrough Ovens As A Stackit Unit
Mounting two PassThrough ovens as a Stackit unit Mounting the manifold assembly for drain and the exhaust pipe Remove the lip sealing (1) from the exhaust pipe (2) on the bottom oven. Mount the bracket (3) on the roof of the bottom oven using one hexagon screws M5 l:12 (4). - Page 23 (4) to the bracket (6) using two hexagon screws M5 l:12 (7). Mount the pipe (8) on the air intake (9). Invoq Hybrid, Invoq Combi and Invoq Bake, mounting instruction, revision 05/2024, SW. 0.7.41...
-
Page 24: Mounting The Legs On Top Of The Bottom Oven, Passthrough
Mounting the legs on top of the bottom oven, PassThrough Mount the leg (1) on the rearmost, left-hand side of the oven using four hexagon screws M5 l:12 (2). Mount the leg (3) on the anterior, left-hand side of the oven using four hexagon screws M5 l:12 (4). - Page 25 Mount the leg (5) on the rearmost, right-hand side using four hexagon screws M5 l:12 (6). Mount the leg (7) on the anterior right-hand side using four hexagon screws M5 l:12 (8). Invoq Hybrid, Invoq Combi and Invoq Bake, mounting instruction, revision 05/2024, SW. 0.7.41...
-
Page 26: Mounting The Upper Oven On The Bottom Oven, Passthrough
Mounting the upper oven on the bottom oven, PassThrough Make sure to mount the stand on the bottom oven before you mount the upper oven on the bottom oven. IMPORTANT! Please refer to the mounting instruction “How to mount a stand”. Remove the four legs (1) from the upper oven. -
Page 27: Mounting The Pipes For Exhaust And Drain, Passthrough
MOUNTING a STaCkIT OvEN Mounting the pipes for exhaust and drain, PassThrough Place the plate for the exhaust and drain pipes (1) on the exhaust pipe (2). Invoq Hybrid, Invoq Combi and Invoq Bake, mounting instruction, revision 05/2024, SW. 0.7.41... - Page 28 Slide the exhaust pipe (3) through the hole of the plate (4) and mount it on the exhaust pipe (5). Slide the drain pipe (6) through the hole of the plate (7) and place it in the manifold assembly for drain (8).
- Page 29 Drill holes on the back plate of the bottom oven in the marked areas using a 4.2 drill and a M5 threaded tap. Mount the drain trap (11) on the bottom oven using two hexagon screws M5 l:12. Invoq Hybrid, Invoq Combi and Invoq Bake, mounting instruction, revision 05/2024, SW. 0.7.41...
-
Page 30: Mounting The Cooling Plate, Passthrough
Mounting the cooling plate, PassThrough Push the two cooling plates (1) in place below the air intake filters of the upper oven. -
Page 31: Connecting The Upper And Bottom Oven To Electricity
Mounting the sideplates, standard Click the three sideplates (1) in place on the left-hand and right-hand side as well as on the front. Invoq Hybrid, Invoq Combi and Invoq Bake, mounting instruction, revision 05/2024, SW. 0.7.41... -
Page 32: Mounting The Sideplates, Passthrough
Mounting the sideplates, PassThrough Click the two sideplates (1) in place on the left-hand and right-hand side. Click the two sideplats (2) in place on the front and back side of the oven. -
Page 33: Mounting The Pipe Protection Cover On A
Cool down the oven before servicing or maintaining the oven. Drill eight Ø4.2 holes in the side plate on the right-hand side of the Assembly drawing, symbols according to ISO128-1:2020 oven. Invoq Hybrid, Invoq Combi and Invoq Bake, mounting instruction, revision 05/2024, SW. 0.7.41... - Page 34 Thread the holes with a M5 threaded tap. Mount the pipe protection cover. fasten the pipe protection cover with eight M5 screws. When mounting a 6-1/1 oven on a 6-1/1 oven, remove the IMPORTANT! bottom part of the pipe protection cover (3).
-
Page 35: Testing The Oven
MOUNTING a STaCkIT OvEN Testing the oven follow the installation checklist to assure that the drain connection as well as the Stackit installation are tight. Invoq Hybrid, Invoq Combi and Invoq Bake, mounting instruction, revision 05/2024, SW. 0.7.41... - Page 36 GET IN TOUCH. as your oven specialist, we always do our utmost to help our customers. Worldwide.
