20V 1/4"
HEX IMPACT DRIVER
MODEL HCID200
ATTACH YOUR RECEIPT HERE
Serial Number _____________________ Purchase Date ______________________
Questions, problems, missing parts? Before returning to your retailer, call
our customer service department at 1-877-888-1880, 8:30 a.m. – 8:00 p.m.
EST (Monday – Friday) & 10:00 a.m. – 6:00 p.m. EST (Saturday and Sunday).
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Hammerhead HCID200
Summary of Contents for Hammerhead HCID200
- Page 1 20V 1/4" HEX IMPACT DRIVER MODEL HCID200 ATTACH YOUR RECEIPT HERE Serial Number _____________________ Purchase Date ______________________ Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-877-888-1880, 8:30 a.m. – 8:00 p.m. EST (Monday – Friday) & 10:00 a.m. – 6:00 p.m. EST (Saturday and Sunday).
- Page 2 TABLE OF CONTENTS Product Specifications ........... . 3 Safety Information .
- Page 3 SAFETY INFORMATION PRODUCT SPECIFICATIONS COMPONENT SPECIFICATIONS Rated voltage 20V d.c. Collet size 1/4" Hex No-load speed 0-2800 /min Maximum torque 1590in.lbs Impact per minute 0-3600 ipm Recommended working temperature 41 ~ 104°F (5 ~ 40°C)) Recommended storage temperature 41 ~ 104°F (5 ~ 40°C) 20V 1/4"...
- Page 4 Please read and understand this entire manual before attempting to assemble or operate this product. If you have any questions regarding the product, please call Hammerhead customer service at 1-877-888-1880, 8:30 a.m. – 8:00 p.m. EST (Monday – Friday) &...
- Page 5 IMPORTANT: This tool should only be serviced only by a qualified service technician. IMPORANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS-This manual contains important safety and operating instructions for cordless impact driver Model HCID200. DANGER To reduce the risk of fire or electric shock, carefully follow these operating instructions...
- Page 6 SAFETY INFORMATION • Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock. •...
- Page 7 SAFETY INFORMATION • Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired. • Disconnect the plug from the power source and/or remove the battery pack, if detachable, from the power tool before making any adjustments, changing accessories, or storing power tools.
- Page 8 SAFETY INFORMATION • Do not use a battery pack or tool that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury. • Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or temperature above 265 °F may cause explosion.
- Page 9 PACKAGE CONTENTS PARTS DESCRIPTION Quick-change Collet Direction-of-Rotation(forward/center-lock/ reverse) Selector Soft Grip Variable-Speed Trigger Switch LED Worklight PH2 Screw Bit 20V 1/4" HEX IMPACT DRIVER...
- Page 10 OPERATING INSTRUCTIONS 1. Install and Remove Bits Your tool is equipped with a quick-change collet, making bit installation and removal very easy. Lock the variable-speed trigger switch “OFF” by placing the direction-of-rotation selector in the center position. To install the bit: Pull the locking sleeve forward, insert the bit as far as it will go into the collet, and release the locking sleeve to lock the bit.
- Page 11 This cordless impact driver must be used only with the battery packs and charger listed below: Battery pack Charger 1.5Ah 2.0Ah 4.0 Ah Hammerhead Hammerhead Hammerhead Hammerhead Hammerhead HCBT015 HCBT020 HCBT040...
- Page 12 OPERATING INSTRUCTIONS 3. Direction-of-Rotation (Forward/ Center-Lock/Reverse) Selector WARNING: After tool use, lock the direction-of-rotation selector in the “OFF”position (center-lock) to help prevent accidental starts and possibleinjury. Your tool is equipped with a direction- of-rotation selector, located above the variable-speed trigger switch. This selector is used to change the direction of rotation of the bit and to lock the Reverse...
- Page 13 OPERATING INSTRUCTIONS 5. LED Worklight Your tool is equipped with an LED worklight, located on the base of the tool, that illuminates when the variable-speed trigger switch is squeezed. This provides additional light on the surface of the workpiece for operation in lower light LED worklight areas.
- Page 14 CARE AND MAINTENANCE WARNING: To avoid serious personal injury, always remove the battery pack from the tool when cleaning or performing any maintenance. Service WARNING: Preventive maintenance performed by unauthorized personnel may result in misplacing of internal wires and components which could cause serious hazard.
- Page 15 TROUBLESHOOTING Suspected malfunctions are often due to causes that the users can fix themselves. Therefore, check the product using this section. In most cases the problem can be solved quickly. WARNING: Only perform the steps described within these instructions! All further inspection, maintenance and repair work must be performed by an authorised service centre or a similarly qualified specialist if you cannot solve the problem yourself! PROBLEM...
- Page 16 This cordless impact driver is warranted to the original purchaser from the original purchase date for 24 Months, Hammerhead consumer portable power tool models will be free from defects in material or workmanship for a period of ninety days if the tool is used for professional use.
