- Page 1 COMPACT IMPACT DRIVER/ AUTO HAMMER MODEL HCID120 CHARGE THE INTEGRATED LITHIUM-ION MADE IN CHINA 2015 BATTERY BEFORE FIRST USE.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Product Specifications ........... . 2 Safety Information . -
Page 3: Safety Information
WARNING — That the vibration emission during actual use of the power tool can differ from the declared total value depending on the ways in which the tool is used. — Avoid vibration risk Suggestion: 1) wear glove during operation 2) limit operating time and shorten trigger time. -
Page 4: General Power Tool Safety Warnings
SAFETY INFORMATION Know the Tool To operate this tool, carefully read this manual and all labels affixed to the impact driver/ auto hammer before using it. Keep this manual available for future reference. Some of the following symbols may be used on this tool. Please study them and their meaning. - Page 5 2) Electrical safety a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock. b) Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and refrigerators.
- Page 6 4) Power tool use and care a) Do not force the power tool. Use the correct power for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
-
Page 7: Preparation
6) Service Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. Specific Safety Warnings for Right-Angle Impact Driver Function • Hold power tools by their insulated gripping surfaces when performing an operation where the cutting accessory may contact hidden wiring. -
Page 8: Package Contents
PACKAGE CONTENTS COMPACT IMPACT DRIVER/AUTO HAMMER... - Page 9 PACKAGE CONTENTS PARTS DESCRIPTION Dual-Function Switch Quick-Release 6.35mm Hex Collet LED Worklight Variable-Speed Trigger Forward/Lock/Reverse Selector Integrated 12V Lithium-Ion Battery Auto Hammer Adaptor Impact Bit COMPACT IMPACT DRIVER/AUTO HAMMER...
-
Page 10: Operating Instructions
OPERATING INSTRUCTIONS 1. How To Charge NOTICE: The integrated Lithium-Ion battery is shipped partially charged. Before using it the first time, fully charge the battery. A fully discharged battery will normally charge in about 30min in a surrounding temperature between 0°C and 55°C a. - Page 11 OPERATING INSTRUCTIONS 2. Variable-speed Trigger a. To turn the tool ON, depress the variable-speed trigger. b. To turn it OFF, release the variable-speed trigger. NOTICE: The variable-speed trigger delivers higher speed with increased trigger pressure and lower speed with decreased trigger pressure. VARIABLE- SPEED TRIGGER...
- Page 12 OPERATING INSTRUCTIONS 4. LED Worklight a. The LED worklight, located on the head of the tool, illuminates when the variable-speed trigger is depressed. This provides additional light on the surface of the workpiece for operation in lower-light areas. b. The LED worklight will turn off FUEL when the variable-speed trigger GAUGE...
- Page 13 OPERATING INSTRUCTIONS 6. Auto Hammer Adaptor The auto hammer adapter permits the tool to be used in the auto hammer function. When not in use, the auto hammer adaptor provided with the tool can be placed in the storage area located on the base of the tool.
- Page 14 WARNING: The bit may be hot after prolonged use. Use protective gloves when removing the bit or adaptor from the tool, or first allow the bit to cool down. OPERATING INSTRUCTIONS 8. Tightening and Loosening Screws and Nuts a. Set the dual-function switch to the impact driving function, marked with “...
- Page 15 WARNING: To avoid possible serious injury, do not exert excessive force on the tool or apply side pressure. Hold the tool firmly while pushing steadily to allow the hammerhead to drive the nail automatically. COMPACT IMPACT DRIVER/AUTO HAMMER...
-
Page 16: Care And Maintenance
OPERATING INSTRUCTIONS Recommended Nails to Use The tool is versatile for use with a variety of nails. Bright common and finishing nails from 2d to 8d are recommended for use with this tool. Recommended Nailing Materials for the Impact Driver/Auto-hammer The tool may be used for nailing into all types of woods, wood-like materials, and plaster board. - Page 17 CHARGER FOR COMPACT IMPACT DRIVER/ AUTO HAMMER MODEL HCCH120 MADE IN CHINA 2015...
- Page 18 TABLE OF CONTENTS Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Preparation .
-
Page 19: Safety Information
SAFETY INFORMATION Know the Tool To operate this tool, carefully read this manual and all labels affixed to the charger before using it . Keep this manual available for future reference . Some of the following symbols may be used on this charger . Please study them and their meaning . - Page 20 • Never charge a frozen battery . • To reduce the risk of injury, close supervision is necessary when an appliance is used near children . • For a portable appliance—to reduce the risk of electrical shock, do not put battery in water or other liquid .
-
Page 21: Preparation
SAFETY INFORMATION • Do not operate the charger with a damaged cord or plug, which could cause shorting and electric shock . If damaged, have the charger repaired or replaced by an authorized service technician . • Do not operate the charger if it has received a sharp blow, been dropped, or has otherwise been damaged in any way . -
Page 22: Package Contents
PACKAGE CONTENTS PARTS DESCRIPTION Electrical contacts Charging indicators Plug CHARGER FOR COMPACT IMPACT DRIVER/AUTO HAMMER... -
Page 23: Operating Instructions
OPERATING INSTRUCTIONS 1. How To Charge NOTICE: The integrated battery is shipped partially charged . Before using it the first time, fully charge the battery . A fully discharged battery will normally charge in about 30min in a surrounding temperature between 0°C and 55°C a . - Page 24 OPERATING INSTRUCTIONS 2. Charger Display INTEGRATED GREEN ACTION INDICATOR BATTERY Normal Flashing Charging Charging Fully Charging is complete Charged Hot/Cold Normal charging will begin when Battery battery returns to 0°C- 55°C Integrated battery or charger is defective or bad connection Defective Flashing between battery and charger...
-
Page 25: Care And Maintenance
OPERATING INSTRUCTIONS 6. Battery Normal Charging If the integrated battery is within the normal surrounding temperature range of 0°C and 55°C, the green LED will begin flashing, the red LED will be off during normal charging . 7. Battery Full If the integrated battery is within the normal temperature range, the green LED will illuminate and the red LED will be off . - Page 26 CHARGER FOR COMPACT IMPACT DRIVER/AUTO HAMMER...
- Page 27 CHARGER FOR COMPACT IMPACT DRIVER/AUTO HAMMER...
