BleBox uremote User Manual

remote
CONTROL DEVICES WITH A REMOTE CONTROL
The product contains batteries described in Directive
2013/56 / WE, which can not be disposed of with other
household waste.
Avoid mechanical damage. Batteries can explode or cause burns if they
are damaged (e.g. crushed), or exposed to fire or high temperature.
Do not remove the casing of the device. The removal of the casing will
cause permanent damage to the product and will result in the loss of the
warranty.
1
2
3
4
1
The μRemote remote control has a multi-colored LED. The PRO version
also has a vibration function. It is powered by a built-in lithium-polymer
battery, charged via the USB C connector from a standard 5V charger or USB
connector. The start of charging is signaled on the remote control by the LED
lighting up purple. When the remote control is charged, the LED will turn off.
The remote control communicates directly with wBox controllers - no router
is required. The communication of the remote control is bidirectional, the
user receives feedback information about the execution of the command of
the controller by using the signal of the LED diode (in the PRO version also
by using the vibration). The red LED indicates that an error has occurred.
2
Currently there are four groups (channels) to which controllers can be
assigned. Each group is defined by a different color. Group 1 (channel 1) - blu
. Group 2 (channel 2) - pink. Group 3 (channel 3) - green. Group 4 (channel
4) - white. The selection of the group is made by briefly pressing the button
(4), which changes the colors of the LED signaling, indicating the selection
of the group.
3
Pairing is a procedure aimed at creating a safe connection between the
remote control and the wBox controller.
You need to prepare the controller which is to be paired to the remote
control, by connecting to the phone with the application wBox and going to
the settings menu and next:
miniature universal remote control
v2
1
2
3
4
GENERAL INFORMATION
GROUP SELECTION
PAIRING
user manual
2 sec 3 sec
a) select a determinated group by scrolling them with a short
pressing of the button 4
b) press and hold for approx. 2 sec. button
blinking
c) press and hold (together) for about 2 seconds the central
buttons of the remote control:
faster
d) press and keep pressed (together) for about 3 seconds the
buttons of remote control:
faster
e) briefly press the remote control button
pairing mode - the LED will be permanently illuminated
f) within a maximum of 20 seconds, in the controller settings menu,
pleasepress the "Add remote control" button. The correct pairing
will be confirmed by the correct message and in the PRO version
with a vibration of the control remote.dodatkowo wibracją.
An error in the previous procedure will be signaled by a blinking LED in red
color. In this case youn need to repeat the procedure from the beginning.
4
The unpairing is a procedure aimed at removing the connection between
the remote control and the wBox controller.
The remote control can be unpaired from the controller using two methods,
depending on the situation:
Method 1 – remove the remote control from the list of "remote controls"
in the controller. This is a standard method in case we have access to
the controller but we do not want to control it anymore with the remote
control. In the controller settings, in the "remote controls" section, delete the
determined remote control from the list. The controller from now on will not
respond to the commands of the remote control, while the remote control at
the first attempt to control, will automatically remove the association with
the device, and will signal the error with a blink of a red LED and additionally
in the Pro version with the vibration."
Method 2 – remove the controller association in the remote.
This method is recommended when we don't have access to the controller,
and we want to clear the memory of the whole group. Follow the pairing
procedure in accordance with points a) - d) However, in point e), instead of
pressing the button (1), it is necessary to press and keep pressed the button
(2). The control remote immediately unpairfrom all the controllers in this
group and will not be able to control them anymore. It should be noted that
in the controller settings, in the "Remote controls" section, the given pilot will
still be visible in the device list.
3 sec 0,5 sec
Piloty
My wLightBoxS
Dodaj pilota
Instrukcje parowania
- the LED will start
4
2 and 3 - the LED will blink
4 and 1 - the LED will blink even
to enter to the
1
UNPAIRING
