BakerStone O-AJKXX-O-000 Product Manual

Gas pizza oven box
Hide thumbs

Advertisement

Quick Links

Download this manual
Pizza Oven Box
Wood fired pe ormance at home
Important, Retain for Future Reference: Read Carefully
Note to Installer: Product Guide must be le with the consumer.
WARNING: This product guide contains important information
necessary for the proper assembly and safe use of the appliance.
Read and follow all warnings and instructions before assembling
Follow all leak-check procedures in the Product Guide before
If you smell gas:
1.
Shut o gas to the appliance.
2.
Extinguish any open flame.
3.
If odor continues, keep away from appliance and immediately
call your gas supplier or your fire department.
DANGER
Failure to follow these instructions could result in fire or explosion
which could cause property damage, personal injury or death.
Do not store or use gasoline or other flammable liquids or vapors
1.
in the vicinity of this or any other appliance.
2.
An LP cylinder not connected for use shall not be stored in the
WARNING
vicinity of this or any other appliance.
Gas
Product Guide
Model # O-AJKXX-O-000
and using the appliance.
using the appliance.
This appliance is for outdoor use only.
www.bakerstonebox.com - (855) 657 OVEN (6836)
3617 W. MacArthur Blvd, Unit 500
Santa Ana, California, USA 92704

Advertisement

loading
Need help?

Need help?

Do you have a question about the O-AJKXX-O-000 and is the answer not in the manual?

Questions and answers

Related Manuals for BakerStone O-AJKXX-O-000

Summary of Contents for BakerStone O-AJKXX-O-000

  • Page 1 Pizza Oven Box Wood fired pe ormance at home Product Guide Model # O-AJKXX-O-000 Important, Retain for Future Reference: Read Carefully Note to Installer: Product Guide must be le with the consumer. WARNING: This product guide contains important information necessary for the proper assembly and safe use of the appliance.
  • Page 2 WARNINGS Failure to follow these instructions could result in fire or explosion which could cause property damage, personal injury or death. The installation must conform with local codes or, in the absence of local codes, with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or the Natural Gas and Propane Installation Code, CSA B149.1, or the Propane Storage and Handling Code,CSA B149.2, or the Standard for Recreational Vehicles, ANSI A119.2/NFPA 1192, and CSA Z240 RV Series, Recreational Vehicle Code, as applicable.
  • Page 3 Do not place gasoline, alcohol, wood products, charcoal or any other combustible material (unless BakerStone approved) in the baking chamber. Remove any appliance cover and place at least 10 feet (3 Meters) from appliance before use.
  • Page 4 Table of Contents Page What’ s in the package Assembly of the Pizza Oven Box Assembly of the Cart LP Gas Cylinder Requirements LP Gas Cylinder Placement LP Gas Cylinder Connection LP Gas Leak Test Pre-Use Safety Checks Lighting Instructions How to Use Routine Care &...
  • Page 5 What’s in the package Before assembling your Pizza Oven Box, ensure that all parts below are included. A x1 B x1 C x2 D x1 Housing Back Panel Stone Supports Vent Catch E x1 F x1 G x2 H x1 Top Stone Base Stone Side Stones...
  • Page 6 (A) by removing its 4 SCREWS (K) and 4 FLAT WASHERS (I). You will identify the BACK PANEL (B) by the embossed BakerStone flame logo on this panel. STEP 4. Identify the TOP STONE (E), this is the largest stone in the box. NOTE: There are notches on both sides of this stone.
  • Page 7 STEP 6. Identify the 2 SIDE STONES (G). Fit the 2 SIDE STONES into the notches of the TOP STONE (E). NOTE: The flat end of the SIDE STONES (G) should face the front of the oven. STEP 7. The other large stone is the BASE STONE (F). Fit this in between and on top of the 2 SIDE STONES (G).
  • Page 8 STEP 10. Locate the VENT CATCH (D) and place into the vent of the oven and resting on the BASE STONE (F). STEP 11. Place the STONE SUPPORTS (C) across the HOUSING (A) and secure with SELF TAPPING SCREWS (K) and LOCK WASHERS (J). Ensure the upper lip of the VENT CATCH (D) sits inside the rearmost STONE SUPPORT (C).
  • Page 9 Assembly of the Cart STEP 1. Identify the LEFT SIDE FRAME (M) and BASE (T). Attach the BASE to the LEFT SIDE FRAME using 2 M6 SCREWS (W). STEP 2. Identify the LOWER FASCIA (P). Attach the LOWER FASCIA to the LEFT SIDE FRAME using 2 M6 SCREWS (W).
  • Page 10 STEP 4. Identify the RIGHT SIDE FRAME (N). Attach the RIGHT SIDE FRAME to the BASE, UPPER FASCIA AND LOWER FASCIA using 6 M6 SCREWS (W). STEP 5. Identify the 2 WHEELS (Q), WHEEL BOLTS (R) and HEX NUTS (S). Attach the WHEELS to the RIGHT SIDE FRAME using the WHEEL BOLTS and HEX NUTS as shown below.
  • Page 11 STEP 7. Identify the FIREBOX (L). Attach the FIREBOX to the LEFT SIDE FRAME and RIGHT SIDE FRAME using 4 M6 SCREWS (W). STEP 8. Identify the 2 SIDE TABLES (U). Attach the SIDE TABLES to the LEFT SIDE FRAME and RIGHT SIDE FRAME using SHOULDER SCREWS (V).
  • Page 12 LP Gas Cylinder (tank) Requirements The appliance is only to be fueled by an LP (liquid propane) gas cylinder measuring 12” (30.5cm) diameter and 18” (45.7cm) high with a 20lb. (9.1kg) capacity. The gas cylinder (tank) must incorperate a Type 1 cylinder valve and an over filling protection device (OPD). The LP gas cylinder must be constructed and marked in accordance with the Specifications for LP gas Cylinders of the U.S.
  • Page 13 LP Gas Cylinder Placement Place the LP Gas Cylinder into the Base and secure with the LP Gas Cylinder retention bolt. Turn the LP Gas Cylinder retention bolt clockwise to tighten. LP Gas Cylinder Base LP Gas Cylinder retention bolt WARNING: The pressure regulator and hose assembly supplied with the appliance must be used.
  • Page 14 LP gas cylinder connection: Step 1 Ensure the LP cylinder used conforms to the requirements listed on the previous page. Also inspect the LP gas cylinder valve rubber seal for deterioration such as cracks, deformation or tears. Step 2 Inspect the LP gas cylinder valve to ensure the threads match that of the included hose and regulator.
  • Page 15 LP Gas Leak Test Before first use and a er each time the LP gas cylinder LP Gas Cylinder Valve is reconnected or changed the LP gas Leak Test must be performed. Do not use an open flame to check for leaks. Do not smoke or be in the presence of any ignition sources while performing a leak test.
  • Page 16 WARNING: Read and follow all instructions and warnings listed on prior pages before attempting to use the appliance. LIGHTING INSTRUCTIONS STEP 1 Ensure both burner valves are in the o position before you turn on the gas tank valve. STEP 2 Push and turn one of the burners to (HIGH) [see Figure - 7 Figure - 7] while pressing and holding the...
  • Page 17 NEVER cover slots, holes, or passages in the oven bottom or cover any rack or cooking su ace with material such as aluminum foil. Doing so blocks air flow through the oven and may cause carbon monoxide poisoning. WARNING Aluminum foil linings may trap heat causing a fire hazard. How to use WARNING: Please completely read all safety...
  • Page 18 STEP 6 Using the pizza peel, launch your pizza into the appliance [see Figure - 13]. NOTE: This can be accomplished by placing the pizza peel just over half-way into the appliance, and using a quick back and fo h shaking motion while sliding the peel out of the appliance.
  • Page 19 STEP 12 When finished baking, turn the burners on the appliance to the o position [see Figure - 16] and allow the appliance to cool for a period of at least ninety (90) minutes. NOTE: If cleaning is required, leave the burners on and continue to heat the oven for 15 minutes prior to cleaning.
  • Page 20 Periodic Care & Cleaning of burner system This appliance will periodically require more detailed cleaning a er continued storage of 3 months or more. Periodically check and clean burner/venturi tubes for insects and insect nests. WARNING: A clogged tube can lead to a fire beneath the appliance.
  • Page 21 STEP 11 Turn o the appliance according to the instructions provided in this guide. STEP 12 With the appliance o and cool to the touch, place the Pizza Oven Box on top of the firebox [see Figure - 23]. Figure - 23 STEP 13 To inspect the flame with the Pizza Oven Box in place, first ignite the burners according to the instructions provided in this guide.
  • Page 22 Within 14 calendar days from the date of purchase, any missing parts or damages must be reported to BakerStone. NOTE: Slight chips or scratches in the stones are not considered damages and do not a ect the pe ormance of the appliance.
  • Page 23 Disclaimer Use of this appliance is at the discretion of the user. BakerStone is not responsible for personal injury or property damage resulting from the misuse of this appliance. FAILURE TO NOT FOLLOW THE PRECAUTIONS AND INSTRUCTIONS IN THE PRODUCT GUIDE MAY RESULT IN THE VOIDING OF THE WARRANTY OF THIS APPLIANCE.
  • Page 24 Frequently Asked Questions Why is my Pizza Oven Box not lighting? - LP Gas Cylinder Valve turned o . - LP Gas Cylinder out of fuel. - Excess flow limiting device may have been activated. To deactivate: 1. Turn all burners to the OFF position. 2.
