This disassembly information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service or
repair the product or products dealt with in this disassembly information by anyone else could result in serious injury or death.
LCD Monitor
27B2G5200
WARNING
27B2G5200
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Philips 27B2G5200
Summary of Contents for Philips 27B2G5200
- Page 1 27B2G5200 LCD Monitor 27B2G5200 WARNING This disassembly information is designed for experienced repair technicians only and is not designed for use by the general public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
- Page 2 Content Index General Safety Instructions ............................1 1. General Guidelines ..............................1 2. Important Notice ..............................1 3. How to Read this Instruction ..........................3 Exploded view diagram with list of items ........................5 Disassembly SOP ..............................6...
- Page 3 27B2G5200 General Safety Instructions 1. General Guidelines When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.
- Page 4 27B2G5200 2-6 Safety Check after Repairment Confirm that the screws, parts and wiring which were removed in order to service are put in the original positions, or whether there are the positions which are deteriorated around the serviced places serviced or not.
- Page 5 27B2G5200 2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly. 3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
- Page 6 27B2G5200 Warning: A “warning” is used when there is danger of personal injury. Reference: A “reference” guides the reader to other places in this binder or in this manual, where he/ she will find additional information on a specific topic.
- Page 7 27B2G5200 Exploded view diagram with list of items...
- Page 8 1. Suggest Tools Here are some tools that can be used for the LCD monitor’s service and repair. Philips-head Screwdriver Use a Philips-head screwdriver to fasten/remove the K- or B-typed screws P/N：N/A Gloves To protect LCD Panel and your hand...
- Page 9 27B2G5200 2. Disassembly Procedures Step Figure Description Press the release button to slide out the stand Remove stand assy. assembly Remove vesa cover. Release screws to take out vesa.
- Page 10 27B2G5200 Use the tool to Remove back open all the cover latches. Disconnect cable. Tear out all the tapes and mylar. Release screws and disconnect Remove main all the cables. frame Lift up mainframe to disconnect cable.
- Page 11 27B2G5200...
- Page 12 27B2G5200...
- Page 13 27B2G5200 Release all the Remove deco screws. Take out mylar Release screws Separate boards to take out switch from main frame board Keep sponge in place.
- Page 14 27B2G5200 Take out sponge Release screws to take out key board. Release screw to take out sensor board.
- Page 15 27B2G5200 Disconnect cables. Remove speakers Take out speakers.
