LifeSpan Kids Yardtopia Oslo XL User Manual

Bbq/grill gazebo set

Hide thumbs

page of 44

/ 44
Bookmarks

Quick Links

Download this manual

USER MANUAL

Yardtopia Oslo XL

BBQ/Grill Gazebo Set

YT024 & YT025 & YT026 & YT027

WARNING: The disassembled product may contain small parts

which pose a choking hazard to children under 3.

IMPORTANT:

This product may contain sharp points and small parts prior to assembly. The owner's manual contains

safety, assembly, use and maintenance instructions. This product must be assembled by an adult who

has read and understood these instructions. Keep the packaging away from children and dispose of all

packaging before use.

For the installer and your children's safety, it is important to fully read and understand the instructions

and safety hazards before commencing the assembly of the product.

NOTE:

This manual should not be used to guide your purchasing decision. Your product, and the contents

inside its carton, may vary from what is listed in this manual. This manual may also be subject to

updates or changes. Updated manuals are available through our website at www.lifespankids.com.au.

Find the Digital

Manual Online

Need help?

Do you have a question about the Yardtopia Oslo XL and is the answer not in the manual?

Questions and answers

Summary of Contents for LifeSpan Kids Yardtopia Oslo XL

Page 1 USER MANUAL Yardtopia Oslo XL BBQ/Grill Gazebo Set Find the Digital Manual Online YT024 & YT025 & YT026 & YT027 WARNING: The disassembled product may contain small parts which pose a choking hazard to children under 3. IMPORTANT: This product may contain sharp points and small parts prior to assembly. The owner’s manual contains safety, assembly, use and maintenance instructions.
Page 2 TABLE OF CONTENTS I. SAFETY WARNINGS AND MAINTENANCE INSTRUCTIONS II. WOOD ADVICE III. PREPARATION IV. ASSEMBLY INSTRUCTIONS V. WARRANTY...
Page 3 I. SAFETY WARNINGS AND MAINTENANCE INSTRUCTIONS IT IS IMPORTANT TO CHECK AND TIGHTEN ALL HARDWARE AT THE BEGINNING AND DURING THE SEASON AS THEY MAY LOOSEN. IMPORTANT: Owners are responsible for maintaining the legibility of warning labels. Retain this manual for future reference on maintenance instructions. •...
Page 4 II. WOOD ADVICE Lifespan Kids uses 100% cedar wood. While we carefully select the highest quality lumber available, wood is a natural product and may be susceptible to weathering, which can affect the appearance of your set.
Page 5 WHEN SHOULD WOOD CRACKS BE A CONCERN? Most of the wood splits will never become large enough to affect the reliability and strength of our products, however, there can be rare cases where splits can occur. This happens when a crack develops past the halfway point from the timber, splitting it into two separate pieces.
Page 6 OWNER’S MANUAL: BASIC SETUP DIMENSIONS & ASSEMBLY NOTES Post mounts are provided with your structure to allow for permanent installation on a pre-existing concrete surface. • Hardware to attach the post mounts to the structure is included. • Hardware to mount the structure permanently to a concrete surface is not included and must be purchased separately.
Page 7 III. SET UP DIMENSIONS 90cm...
Page 8 IV. ASSEMBLY INSTRUCTIONS P A R T S L I S T Part No. Quantity Reference Image B105 B106 D102 G103 H104 H105 K103 K104 K105 K106...
Page 9 Part No. Quantity Reference Image S104 S105 Part No. Quantity Reference Image Part No. Quantity Reference Image AAA-1 AAA-2 BBB-4 BBB-6 DDD-3 CCC-3 DDD-7 EEE-1 EEE-2 RRR-1 RRR-2 RRR-12 RRR-21 ASSEMBLY INSTRUCTIONS...
Page 10 Part No. Quantity Image Description AA-1 M8x145 AA-4 M8x60 BB-2 92+4 M5x30 BB-4 M5x40 M10x80 M6x70 M6x25 32+2 M8x25 M6x70 M5x90 10+2 M6x45 18+2 NN-2 94+6 M6x12 Ø6x200 M10x80 ASSEMBLY INSTRUCTIONS...
Page 11 EXPLODED DIAGRAM S104 S105 B105 K103 H104 D102 K104 G103 DDD-3 K106 B106 K105 D102 K104 H105 D102 DDD-7 H105 K106 K103 K103 DDD-7 D102 K104 K105 CCC-3 K104 B106 G103 DDD-3 B105 CCC-3 K103 DDD-7 H104 RRR-2 RRR-1 BBB-6 RRR-21 BBB-4 RRR-1...
Page 12 STEP 1 BBB-4 BBB-4 BBB-4 M8x25 FF 12X ASSEMBLY INSTRUCTIONS...
Page 13 STEP 2 BBB-4 FF 2X M8x25 ASSEMBLY INSTRUCTIONS...
Page 14 STEP 3 STEP1 RRR-21 RRR-21 RRR-1 RRR-2 RRR-1/RRR-2 STEP2 38 4X RRR-21 4X RRR-1 2X RRR-2 2X FF 14X M8x25 ASSEMBLY INSTRUCTIONS...
Page 15 STEP 4 STEP1 STEP2 M8x25 FF 4X M5x90 ASSEMBLY INSTRUCTIONS...
Page 16 STEP 5 BB-2 06 4X M5x30 BB-2 ASSEMBLY INSTRUCTIONS...
Page 17 STEP 6 Note the pilot holes for the post orientation. Note the pilot holes for the post orientation. BBB-6 AA-1 BBB-6 AA-1 BBB-6 M8x145 AA-14 M10x80 ASSEMBLY INSTRUCTIONS...
Page 18 STEP 7 WARNING: Assistance required to hold the timbers while another installs the screws. BBB-6 BBB-6 AA-1 AA-1 M8x145 M10x80 AA-1 ASSEMBLY INSTRUCTIONS...
Page 19 STEP 8 AA-4 First pre-install bolts AA-4 (do not tighten), then tighten bolts DD screws. Finally tighten the pre-installed screws AA-4. Do this for all corners. 26 8X M8x60 AA-4 M6x70 ASSEMBLY INSTRUCTIONS...
Page 20 STEP 9 R=90° 90 ° TIPS: Check the frame measurements are same by measuring from one post to the opposite post diagonally and also the angles of the legs are at 90 degree angles. ASSEMBLY INSTRUCTIONS...
Page 21 STEP 10 EEE-1 EEE-2 BB-2 BB-2 BB-2 BB-2 EEE-1/EEE-2 EEE-1 2X EEE-2 M5x30 BB-2 ASSEMBLY INSTRUCTIONS...
Page 22 STEP 11 BB-2 BB-2 M5x30 BB-2 ASSEMBLY INSTRUCTIONS...
Page 23 STEP 12 NN-2 G103 G103 G103 NN-2 NN-2 RRR-12 NN-2 RRR-12 NN-2 G103 2X RRR-12 M6x12 NN-2 ASSEMBLY INSTRUCTIONS...
Page 24 STEP 13 G103 BB-2 BB-2 M5x30 BB-2 ASSEMBLY INSTRUCTIONS...
Page 25 STEP 14 D102 CCC-3 NN-2 CCC-3 D102 4X CCC-3 M6x12 NN-2 ASSEMBLY INSTRUCTIONS...
Page 26 STEP 15 NN-2 NN-2 D101 NN-2 D102 NN-2 NN-2 M6x12 ASSEMBLY INSTRUCTIONS...
Page 27 STEP 16 NN-2 D102 DDD-7 DDD-7 NN-2 M6x12 ASSEMBLY INSTRUCTIONS...
Page 28 Note: the orientation of the parts from birds eye view. STEP 17 K103 K104 K104 K103 K105 K106 K106 K105 K103 K104 K104 K103 ASSEMBLY INSTRUCTIONS...
Page 29 STEP 18 NN-2 NN-2 K104 D102 K103 D102 NN-2 NN-2 NN-2 NN-2 K106 K105 NN-2 NN-2 K103 K104 K105 K106 M6x12 NN-2 ASSEMBLY INSTRUCTIONS...
Page 30 STEP 19 B106 NN-2 NN-2 G103 K103/K104 NN-2 B105/B106 NN-2 B105 M6x12 NN-2 B106 ASSEMBLY INSTRUCTIONS...
Page 31 STEP 20 STEP.3 B105/B106 H104 D102 H105 H104 H105 NN-2 STEP.2 NN-2 B105/B106 H104 STEP.1 NN-2 H104 DDD-3 H105 NN-2 M6x12 ASSEMBLY INSTRUCTIONS...
Page 32 STEP 21 BB-4 K103 BB-2 BB-2 D102 BB-2 BB-4 M5x30 M5x40 ASSEMBLY INSTRUCTIONS...
Page 33 STEP 22 Warning: Wear gloves when working with metal sheets to avoid injury. Note the orientation of the parts from birds eye view. When overlapping the metal roof start from the middle pieces first and work your way out. ASSEMBLY INSTRUCTIONS...
Page 34 STEP 23 Secure the screws at the overlap. K105 M6x45 ASSEMBLY INSTRUCTIONS...
Page 35 STEP 24 K103 K103 M6x45 ASSEMBLY INSTRUCTIONS...
Page 36 STEP 25 S104 S105 Pre-install the bolts and nut first. S105 M6x70 S104 ASSEMBLY INSTRUCTIONS...
Page 37 STEP 26 G103 S105 S104 Lock the bolt from previous step with washer and nut from underneath the roof. ASSEMBLY INSTRUCTIONS...
Page 38 STEP 27 B105/B106 M6x25 ASSEMBLY INSTRUCTIONS...
Page 39 STEP 28 BB-2 BB-2 AAA-2 AAA-1 Note: the direction for AAA-2 facing outwards and AAA-1 facing inwards. BB-2 BB-2 AAA-1 AAA-2 BB-2 M5x30 ASSEMBLY INSTRUCTIONS...
Page 40 STEP 29 Anchors for Soil Installation Important: Ensure the ground does not have loose soil and rocks that may get in the way of anchoring. Clear any debris in the area. Ground MUST be leveled and not on a slope. 1.
Page 41 STEP 30 Anchors for Concrete Installation Important: Ensure the concrete surface where you intend to install the wedge anchors is safe and can support the objects you plan to fasten. Clear any debris in the area. INSTRUCTIONS: 1. First mark your area then drill a hole into the concrete.
Page 42 If you have purchased this product from the Official Lifespan Kids website, please visit www.lifespankids.com.au/warranty-form For support outside of warranty, if you wish to purchase replacement parts or request a repair or service, please visit www.lifespankids.com.au/warranty-form and fill in our Repair/Service Request Form or...
