USER MANUAL
Yardtopia Fremantle
3m x 3.6m Timber &
Steel Roof Gazebo Set
YT016 & YT017 & YT018 & YT019
WARNING: The disassembled product may contain small parts
which pose a choking hazard to children under 3.
IMPORTANT:
This product may contain sharp points and small parts prior to assembly. The owner's manual contains
safety, assembly, use and maintenance instructions. This product must be assembled by an adult who
has read and understood these instructions. Keep the packaging away from children and dispose of all
packaging before use.
For the installer and your children's safety, it is important to fully read and understand the instructions
and safety hazards before commencing the assembly of the product.
NOTE:
This manual should not be used to guide your purchasing decision. Your product, and the contents
inside its carton, may vary from what is listed in this manual. This manual may also be subject to
updates or changes. Updated manuals are available through our website at www.lifespankids.com.au.
Find the Digital
Manual Online
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LifeSpan Kids Yardtopia Fremantle YT016
Summary of Contents for LifeSpan Kids Yardtopia Fremantle YT016
- Page 1 USER MANUAL Yardtopia Fremantle 3m x 3.6m Timber & Steel Roof Gazebo Set Find the Digital Manual Online YT016 & YT017 & YT018 & YT019 WARNING: The disassembled product may contain small parts which pose a choking hazard to children under 3. IMPORTANT: This product may contain sharp points and small parts prior to assembly.
-
Page 2: Table Of Contents
TABLE OF CONTENTS I. SAFETY WARNINGS AND MAINTENANCE INSTRUCTIONS II. WOOD ADVICE III. PREPARATION IV. ASSEMBLY INSTRUCTIONS V. WARRANTY... -
Page 3: Safety Warnings And Maintenance Instructions
I. SAFETY WARNINGS AND MAINTENANCE INSTRUCTIONS IT IS IMPORTANT TO CHECK AND TIGHTEN ALL HARDWARE AT THE BEGINNING AND DURING THE SEASON AS THEY MAY LOOSEN. IMPORTANT: Owners are responsible for maintaining the legibility of warning labels. Retain this manual for future reference on maintenance instructions. •... -
Page 4: Wood Advice
II. WOOD ADVICE Lifespan Kids uses 100% cedar wood. While we carefully select the highest quality lumber available, wood is a natural product and may be susceptible to weathering, which can affect the appearance of your set. -
Page 5: Preparation
WHEN SHOULD WOOD CRACKS BE A CONCERN? Most of the wood splits will never become large enough to affect the reliability and strength of our products, however, there can be rare cases where splits can occur. This happens when a crack develops past the halfway point from the timber, splitting it into two separate pieces. - Page 6 OWNER’S MANUAL: BASIC SETUP DIMENSIONS & ASSEMBLY NOTES Post mounts are provided with your structure to allow for permanent installation on a pre-existing concrete surface. • Hardware to attach the post mounts to the structure is included. • Hardware to mount the structure permanently to a concrete surface is not included and must be purchased separately.
-
Page 7: Assembly Instructions
IV. ASSEMBLY INSTRUCTIONS P A R T S L I S T Part No. Quantity Image Description ASSEMBLY INSTRUCTIONS... - Page 8 Part No. Quantity Image Description Part No. Quantity Image Description Part No. Quantity Image Description ASSEMBLY INSTRUCTIONS...
- Page 9 AA x 8 BB x 52+4 CC x 8 DD x 8 M8 x 165 M5 x 30 M10 x 80 M6 x 70 FF x 36+2 GG x 4+1 HH x 16 II x 4 M8 x 25 M8 x 60 M6 x 70 JJ x 32+2 KK x 4+1...
- Page 10 STEP 1 M8 x 25 FF 12x ASSEMBLY INSTRUCTIONS...
- Page 11 STEP 2 05 4x M5 x 20 JJ 16x ASSEMBLY INSTRUCTIONS...
- Page 12 STEP 3 M8 x 25 ASSEMBLY INSTRUCTIONS...
- Page 13 STEP 4 M8 x 25 ASSEMBLY INSTRUCTIONS...
- Page 14 STEP 5 Step 1 R1/R2 Step 2 M8 x 25 FF 14x ASSEMBLY INSTRUCTIONS...
- Page 15 STEP 6 Step 1 Step 2 08 4x M5 x 20 M5 x 140 ASSEMBLY INSTRUCTIONS...
- Page 16 STEP 7 Note the pilot holes for the post orientation. Note the pilot holes for the post orientation. 05 4x M8 x 145 M10 x 80 AA 4x CC 4x ASSEMBLY INSTRUCTIONS...
- Page 17 WARNING: Assistance required to hold the STEP 8 timbers while another installs the screws. M10 x 80 M8 x 145 CC 4x AA 4x ASSEMBLY INSTRUCTIONS...
- Page 18 STEP 9 First pre-install bolts HH (do not tighten), then tighten bolts DD on timber 04 and 06. Finally tighten the pre-installed screws DD. 04 4x M6 x 70 M8 x 60 DD 4x HH 8x ASSEMBLY INSTRUCTIONS...
- Page 19 STEP 10 First pre-install bolts HH (do not tighten), then tighten bolts DD on timber 04 and 06. Finally tighten the pre-installed screws DD. 04 4x M6 x 70 M8 x 60 DD 4x HH 8x ASSEMBLY INSTRUCTIONS...
- Page 20 STEP 11 Y1 = Y2 <R=90° TIPS: Check the frame is squared by measuring from one post to the opposite post diagonally and also the angles of the legs are at 90 degree angles. ASSEMBLY INSTRUCTIONS...
- Page 21 STEP 12 Insert P1 into both B1 on both ends. M6 x 15 TT 14x ASSEMBLY INSTRUCTIONS...
- Page 22 STEP 13 Bolt underneath. M5 x 30 M6 x 15 ASSEMBLY INSTRUCTIONS...
- Page 23 STEP 14 M6 x 15 TT 16x ASSEMBLY INSTRUCTIONS...
- Page 24 STEP 15 Bolt on the sides of B1. M6 x 15 TT 16x ASSEMBLY INSTRUCTIONS...
- Page 25 STEP 16 D2/D3 M6 x 15 D2 2x D3 2x ASSEMBLY INSTRUCTIONS...
- Page 26 STEP 17 Bolt to the sides of B1. Bolt on the top of part 07. D2/D3 M6 x 15 ASSEMBLY INSTRUCTIONS...
- Page 27 STEP 18 Please note Please note Please note Please note the direction the direction the direction the direction of the arrows. of the arrows. of the arrows. of the arrows. K28 4x K29 4x M6 x 15 TT 40x K30 2x ASSEMBLY INSTRUCTIONS...
- Page 28 STEP 19 M6 x 15 Q2 2x ASSEMBLY INSTRUCTIONS...
- Page 29 STEP 20 Pre-install the screws but do not tighten. M6 x 15 ASSEMBLY INSTRUCTIONS...
- Page 30 STEP 21 Insert H18 to H17 and pre-install with TT. Insert H16 into H17 and Pre-install the screws but do not tighten. pre-install with TT. ASSEMBLY INSTRUCTIONS...
- Page 31 STEP 22 H16/H18 H16/H18 M6 x 15 ASSEMBLY INSTRUCTIONS...
- Page 32 STEP 23 Bolt D1 to the timber frame (02). Bolt R3 to timber part 07. M5 x 20 M5 x 30 BB 16x ASSEMBLY INSTRUCTIONS...
- Page 33 STEP 24 Step 3 Step 2 Step 1 Step 2 Step 3 Place the metal panels to the roof frame starting from the middle and working your way out. When covering each panel, pre-install with the screws but do not tighten. K29/K30 M6 x 45 MM 4x...
- Page 34 STEP 25 Note the hole for placement for D2/D3 panels. T40/41 D2/D3 When covering each panel, pre-install with the screws but do not tighten. M6 x 45 MM 2x ASSEMBLY INSTRUCTIONS...
- Page 35 STEP 26 Refer to the same steps on Step 24. When covering each panel, pre-install with the screws but do not tighten. M6 x 45 MM 4x ASSEMBLY INSTRUCTIONS...
- Page 36 STEP 27 Refer to the same steps on Step 25. When covering each panel, pre-install with the screws but do not tighten. M6 x 45 MM 2x ASSEMBLY INSTRUCTIONS...
- Page 37 STEP 28 M6 x 70 ASSEMBLY INSTRUCTIONS...
- Page 38 STEP 29 Secure the bolts under roof. GG 4x ASSEMBLY INSTRUCTIONS...
- Page 39 STEP 30 T40/41 D2/D3 After securing bolts EE on D2/D3 on both sides of the roof, tighten all the pre-installed screws. M6 x 25 MM 8x ASSEMBLY INSTRUCTIONS...
- Page 40 STEP 31 Inside Outside M5 x 30 BB 32x ASSEMBLY INSTRUCTIONS...
- Page 41 STEP 32 ANCHORING: Use (1) installation diagram and part UU if you are mounting to dirt ground. Important: Ensure the ground does not have loose soil and rocks that may get in the way of anchoring. Clear any debris in the area. INSTRUCTIONS: 1.
-
Page 42: Warranty
If you have purchased this product from the Official Lifespan Kids website, please visit www.lifespankids.com.au/warranty-form For support outside of warranty, if you wish to purchase replacement parts or request a repair or service, please visit www.lifespankids.com.au/warranty-form and fill in our Repair/Service Request Form or... - Page 44 www.l i f e s p an k i d s . co m . a u...
