USER MANUAL Yardtopia Elmont 3m x 3m Aluminium Pergola with Adjustable Louvre Set Find the Digital Manual Online YT008 &YT009 & YT010 & YT011 WARNING: The disassembled product may contain small parts which pose a choking hazard to children under 3.
Page 2
TABLE OF CONTENTS I. SAFETY WARNINGS AND MAINTENANCE INSTRUCTIONS II. PREPARATION III. ASSEMBLY INSTRUCTIONS IV. WARRANTY...
Page 3
I. SAFETY WARNINGS AND MAINTENANCE INSTRUCTIONS IT IS IMPORTANT TO CHECK AND TIGHTEN ALL HARDWARE AT THE BEGINNING AND DURING THE SEASON AS THEY MAY LOOSEN. IMPORTANT: Owners are responsible for maintaining the legibility of warning labels. Retain this manual for future reference on maintenance instructions. •...
Page 4
• Regularly inspect the stability of the pergola/gazebo, as this is crucial for safety. Any damage caused by the pergola detaching from its foundation due to natural disasters, high winds, or other extreme weather conditions is the responsibility of the homeowner and installer and is not covered under the manufacturer’s warranty.
Page 5
Cordless Hammer Screwdriver Ladder 2 People Drill Use Level Square Assembly Tighten Bolts Measure Distance Gloves Check the ground Check that assembly Do not over tighten and assembly is is square before the mounting bolts. properly leveled. tightening the bolts. Over tightening can cause damage to the pergola.
Page 6
III. ASSEMBLY INSTRUCTIONS P A R T S L I S T Part No. Quantity Image Description ASSEMBLY INSTRUCTIONS...
Page 7
Part No. Quantity Image Description AA x 74 BB x 4 CC x 4 M6 x 15 M6 x 50 M4 x 15 DD x 8 EE x 2 FF x 1 M6 x 5 M6 x 70 GG x 1 HH x 1 JJ x 8 M6 x 63...
Page 8
STEP 1 C x 4 A x 4 AA x 16 WARNING: Please wear gloves when assembling the metal parts. Align the post to the bolt openings for part C and secure with bolts (AA). ASSEMBLY INSTRUCTIONS...
Page 9
STEP 2 D1 x 1 D2 x 1 AA x 6 F x 2 Align the screw holes on F parts to D1/D2 and tighten with screws. ASSEMBLY INSTRUCTIONS...
Page 10
STEP 3 GG x 1 Do not fully tighten at this stage. Assistance is required to hold up the post while securing the bolts. Slide D1 piece into the grove of A. Take note of the orientation. ASSEMBLY INSTRUCTIONS...
Page 11
STEP 4 GG x 1 Do not fully tighten at this stage. Slide D2 piece into the grove of A. Take note of the orientation. ASSEMBLY INSTRUCTIONS...
Page 12
STEP 5 E1 x 1 E2 x 1 Slide the E1/E2 pieces into Do not fully tighten the grove of the A. at this stage. Take note of the orientation of this end must be on the same side. ASSEMBLY INSTRUCTIONS...
Page 13
STEP 6 B x 4 AA x 28 Do not fully tighten at this stage. ASSEMBLY INSTRUCTIONS...
Page 14
STEP 7 H x 1 AA x 8 Do not fully tighten at this stage. ASSEMBLY INSTRUCTIONS...
Page 15
STEP 8 G2 x 2 L x 2 G1 x 2 M x 2 O x 2 P x 2 N x 2 BB x 4 DD x 4 Keep both part “L” facing the same direction. You can swap the direction however both must face the same way.
Page 16
STEP 9 AA x 10 DD x 2 In the middle section, secure the rod on either side to H beam curved bracket, 1x bolt on each side. 1. Place the assembled rods from previous set onto part D1. 2. Note the orientation for the Loop lever must both be on opposite sides, near to the corners.
Page 17
STEP 10 AA x 6 DD x 2 1. Use 2x screws to secure the rod to beam E1 and repeat for the other side for E2. 2. Use 1x screw to secure on the E1 curved bracket to the rod and repeat for E2 side. Tighten all the screws to the frame.
Page 18
STEP 11 K x 66 Begin from the side of the roof that has the loop lever (N) piece. Follow the diagram to click all the panels K into the roof frame. To start assembling roof from the side without control box “N”. ASSEMBLY INSTRUCTIONS...
Page 19
STEP 12 J x 2 CC x 4 On the other end of the roof, place the 2x J pieces and secure with the screws. ASSEMBLY INSTRUCTIONS...
Page 20
STEP 13 ANCHORING: JJ x 16 Important: Ensure the concrete surface where you intend to install the wedge anchors is safe and can support the objects you plan to fasten. Clear any debris in the area. Instructions: 1. First mark your area then drill a hole into the concrete.
Page 21
STEP 14 Q x 1 Attach the Shutter lever (Q) to N piece. You can hook it on either sides for the N piece. ASSEMBLY INSTRUCTIONS...
Page 22
STEP 15 Turn part Q 90 degrees to open or close the shutters. It cannot be turned more than 90 degrees. ASSEMBLY INSTRUCTIONS...
Page 23
If you have purchased this product from the Official Lifespan Kids website, please visit www.lifespankids.com.au/warranty-form For support outside of warranty, if you wish to purchase replacement parts or request a repair or service, please visit www.lifespankids.com.au/warranty-form and fill in our Repair/Service Request Form or...
