- Page 1 ASSEMBLY INSTRUCTION FULL-MOTION TV WALL MOUNT MODEL:FML64S CAUTION : Please read this instruction carefully before assembly. Fits for 42-84in plasma and LCD TV. Weight Capacity : 60KG (132 LBS).
-
Page 2: Part List
CAUTION : SAFETY WARNING: Never let children climb on product or play with product. Do not sit or stand on product. Do not fasten a TV that is heavier than the recommended load rating to the mount. Using suitable wood stud wall. Improper installation may cause property damage and/or personal injury, so the installation must be done by two qualified contractors. -
Page 3: Safety Directions
Safety directions: Step 1 ： Please remove the plaster board on the surface of concrete wall when assembling mount on the concrete wall.Hold wall plate (A) against wall at desired position on concrete wall, then using a pencil mark 4 hole locations . Then drill holes according pencil marks using 3/8"... - Page 4 Step 2 ： Per the hole pattern on the back panel of TV , Choose the suitable unit . 1 . VESA within 75x75/100x100/200x200 Choose TV plate (B) to connect TV directly. 2 . VESA within (200-600)x400 Connect plate (B) to fixed arm (D) using slide TV bracket (C) onto (D).
- Page 5 2. VESA : within (200-600)x400. h/i/j Figure 8 Figure 7 CAUTION : 1.Please use the correct screw & washer & combination to fasten spacer TV brackets to the back of TV. First screw in screws by hand, then use screwdrive to finish tightening. 2.
- Page 6 2. VESA : within (200-600)x400. Figure 10 Forbidden Attention Figure 11 Figure 12...
- Page 7 Step 5 ： You may need rotate the handle to adjust TV to your desired angle, and then don't forget to fasten the handle. Handle ±90° ±90° ±90° Figure 13 PAY EXTRA CARE AND ATTENTION WHEN YOU FASTEN TWO TV MOUNTS TO THE BACK PANEL OF TV IN STEP4 .
