TP-Link deco BE65 Quick Start Manual page 5

Specifications
Hardware
· Ethernet Port: 4 × 2.5 Gigabit ports per unit (WAN/LAN auto-sensing)
· Button: 1 RESET button at the bottom, 1 WPS button on the back
· Port: 1× USB 3.0 Port
· Power Consumption (without power adapter):
· Dimensions (W × D × H): 4.23 × 4.23 × 6.93 in (107.5 × 107.5 × 176 mm)
· Power Adapter Input: 100-240 V ~ 50/60 Hz 0.8 A
· Power Adapter Output: 12 V 2.5 A
1× WPS Button
4× 2.5 Gbps
WAN/LAN Ports
1× USB Port
1× Power Port
Attention: This device may only be used indoors in all EU member states, EFTA countries, and Northern Ireland.
Attention: This device may only be used indoors in Great Britain.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Specifications are subject to change without notice. Google, Google Home, and Google Play are trademarks of Google LLC. All the brands and product names are trademarks or registered trademarks of their respective holders.
Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput, wireless coverage, and quantity of connected devices are not guaranteed and will vary as a result of network conditions, client limitations, and environmental factors, including
†
building materials, obstacles, volume and density of traffic, and client location. The 160 MHz and 240 MHz bandwidth might not be available on the 5 GHz band, and the 320 MHz bandwidth might not be available on the 6 GHz band in some regions/countries due to regulatory limits on the spectrum, hence the
theoretical speeds might vary.
Clients need to support 802.11k/v/r and may require additional setup. Performance may vary depending on the client device.
‡
Use of Wi-Fi 7 (802.11be), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), and other features including MLO, 320 MHz Bandwidth, 4K-QAM, Multi-RU, OFDMA, MU-MIMO, and BSS Color requires clients to also support the corresponding features. The 320 MHz bandwidth is only available on the 6 GHz band. Not all 320
△
MHz channels may be available in the 6 GHz band in some regions/countries due to regulatory restrictions.
2.5 Gbps internet speeds require compatible service plans and equipment. All WAN/LAN ports will operate as either WAN or LAN ports. Only one port can serve as a WAN port at a time.
§
Use of WPA3 requires clients to also support the corresponding feature.
◊
HomeShield includes the Free Basic Plan. Fees apply for the Pro Plan. Visit tp-link.com/homeshield for more information.
*
Wi-Fi generations represent the wireless standard IEEE 802.11 a/b/g/n/ac/ax/be.
**
Users may require an extra modem device that is compatible with their internet service provider to gain internet access.
Actual network speed may be limited by the rate of the product's Ethernet WAN or LAN port, the rate supported by the network cable, internet service provider factors, and other environmental conditions.
This Deco may not support all the mandatory features as ratified in the IEEE 802.11be specification.
Further software upgrades for feature availability may be required.
©2024 TP-Link
Wireless
· Wireless Standards:
802.11a/n/ac/ax/be 5GHz, IEEE 802.11ax/be 6 GHz
· Mesh protocol:
· Frequency:
27.5W max
· Signal Rate:
GHz)
†
· Transmit Power:
· Wireless Security:
Software
· Working Mode:
· WAN Type:
· DHCP: Server
· Protocols:
· Guest Network:
Guest Network ×1
· IoT Network:
· MLO Network:
· Features:
Bandwidth
· Management:
IEEE 802.11b/g/n/ax/be 2.4 GHz,IEEE
802.11k/v/r
2.4 GHz, 5 GHz, 6 GHz
5765 Mbps (6 GHz) + 2882 Mbps (5 GHz) + 688 Mbps (2.4
CE: <20 dBm (2.4 GHz), <30 dBm (5 GHz), <23 dBm(6 GHz)
WPA/WPA2-PSK/WPA3 encryptions
◊
Router, Access Point
Dynamic IP/Static IP/PPPoE/L2TP/PPTP
Supports IPv4 and IPv6
2.4 GHz Guest Network×1, 5 GHz Guest Network×1, 6 GHz
IoT Network×1
MLO Network×1
TP-Link HomeShield*, Multi-Link Operation (MLO)
, 4K-QAM , Multi-RU , MU-MIMO , OFDMA
△ △ △ △
Local Management; Remote Management; Multi-Managers
Others
· Certification: CE, RoHS
· Environment:
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~60°C (-40 °F~140 °F)
Operating Humidity: 10%~90% RH
Storage Humidity: 5%~90% RH
· Package Contents for Deco BE65(1-pack):
1 Deco BE65 unit
1 RJ45 Ethernet cable
1 Power adapter
1 Quick Installation Guide
· Package Contents for Deco BE65(2-pack):
2 Deco BE65 units
1 RJ45 Ethernet cable
2 Power adapters
1 Quick Installation Guide
· Package Contents for Deco BE65(3-pack):
3 Deco BE65 units
1 RJ45 Ethernet cable
, 320 MHz
△
3 Power adapters
, BSS Color
△ △
1 Quick Installation Guide
TP-Link BE9300 Whole Home Mesh Wi-Fi 7 System Deco BE65
w w w.tp-link.com
