- Page 1 OWNER’S MANUAL Stand For LG LED Screen Please read this manual carefully before install & operating your set and retain it for future reference. ST-136H Stand Installation www.lg.com Copyright © 2024 LG Electronics Inc. All Rights Reserved...
- Page 2 2250 x 1450 x 540 mm Weight (Net/Gross) 117/214±5kg Caution: This model (ST-136H) is a stand intended for use only with LG Electronics Inc. LED Video Display AIO 136" model only. Use with other equipment may result in instability causing injury.
- Page 3 Packing List Item Description Photo Qty. Stand Base Left Vertical Support Column Right Vertical Support Column Horizontal Support Beam Steel Tube Linear Actuator Rear Plate Front Plate Mounting Plate Washer M8X22mm Screw...
- Page 4 M6X20mm Screw M6X40mm Screw M10X45mm Flat Head Screw With Nut M4X10mm Flat Head Screw M3X8mm Flat Head Screw M10X20mm Flat Head Screw M4X20mm Flat Head Screw 8mm Hex Key M10 Socket 5mm Hex Key Handset Regulation Book...
- Page 5 Note: The following tools may be used during the installation, such as screwdriver. Please use the tools provided with the panel. Screwdriver <Rear Side> <Front Side> < Overall Side View>...
- Page 6 Assemble the stand Step1. Install the vertical support column to the stand base. Note: The slider block is facing front < Side View > <Rear View> Use 8pcs M8X22 screws (Item 11) marked in square, use 16pcs M8X22 screws (Item 11) with 16pcs washer (Item 10) marked in circle to install the Item 2 and Item 3 on the stand base (Item 1).
- Page 7 Step3. Loosen the screws and remove the gaskets of the vertical support column. Both Sides Same Loosen the screws marked in circle, and remove the gaskets. Step4. Install the horizontal support beam to the vertical support column. Use 24pcs M6X40 screws (Item13) to install the Item 4.
- Page 8 Step5. Install the to the stand main body. linear actuator Align the 2 holes in red circle, and use 1pcs M10X45 (Item14) flat head screw with nut connect Item5, Item6 marked in circle. Use 12pcs (Item13) screws to connect Item4, Item6 marked in square. M6X40...
- Page 9 Step6. Install the rear plate. Both Sides Same Use 3pcs M4X20 (Item18) flat head screws to connect Item1, Item7 marked in circle, and use 12pcs M3X8 (Item16) flat head screws to connect Item2, Item3, Item7 marked in square. Step7. Connect the cable routing. Pull Port 1 Port HS...
- Page 10 Step7-B. Connect the handset cable and power cord. Down Before connecting the handset (Item 22) cable, pull the controller cover, pass the handset cable through the hole from the outside to the inside, and then connect the handset cable to the port HS. Push Pass the power cord cross the hole marked in circle.
- Page 11 Step8. Install the front plate. Both Side Same Use 4pcs M4X10 (Item15) flat head screws to connect Item7, Item8 marked in circle, and use 6pcs M4X20 (Item18) flat head screws to connect Item7, Item8 marked in square. < Front View > The handset can be placed here.
- Page 12 Screen assembly Step1. Install the mounting plate to the panel. < Rear View > Use 8pcs M10X20 screws (Item17) to connect Item9 and panel.
- Page 13 Step2. Install the panel to the stand. Note: Please install the left cabinet onto the stand first, and then install the right cabinet. < Rear View > After installing the left cabinet, loosen the screw marked in circle and make it downward to coincide with the gap of the horizontal support beam.
- Page 14 Leveling caster Wheel Seat Casing Handle Wheel Unlock Support Base Lock Note: 1. For safety, after completing the screen installation, lock the casters to prevent the stand from moving. 2. Rotate the handle clockwise to lock, and counterclockwise to unlock.
