- Page 1 OWNER’S MANUAL Stand For LG LED Screen Please read this manual carefully before install & operating your set and retain it for future reference. ST-1364F Stand Installation www.lg.com Copyright © 2023 LG Electronics Inc. All Rights Reserved.
-
Page 2: Technical Data
Weight (Net/Gross) 81kg/175kg This model (ST-1364F) is a stand for the LAEC015-GN2 AIO model only. The stand has 3 levels to adjust the height of the screen. The height can be adjusted if needed, and it is described on the page of 9. -
Page 3: Packing List
Packing List <Main Body Part> Item Description Photo Qty. Left Support Base Right Support Base Horizontal Support Beam... - Page 4 <Mounting Plate Part> Item Description Photo Qty. Left Top Support Beam Right Top Support Beam Left Bottom Support Beam Right Bottom Support Beam Horizontal Rib Left Vertical Rib Right Vertical Rib Rib Support...
- Page 5 M6×20mm Hexagon Screw M4×15mm Pan Head Screw 13-1 Roller1 13-2 Roller2 M12 Nut Mounting Lock+Bolt M12 Hexagon Socket M6 Hex Key Screwdriver Gloves...
-
Page 6: Assemble The Stand
Assemble the stand Step1. Connect the Support Base (item 1 and item 2) with the support beam (item 3). Use 8pcs M6 screws (Item 11) to connect the Item1 and Item 2 with Item 3. Step2. Connect the panel mounting plate(Below). Use 16pcs M4 screws (Item 12) to connect the Item 6 and Item 7 with Item 10. - Page 7 Step3. Connect the panel mounting plate(Top). Use 16pcs M4 screws (Item 12) to connect the Item 4 and Item 5 with Item 10. Step4. Connect the vertical rib to the horizontal rib. Use 4pcs M6 screws (Item 11) to connect the Item 9 with Item 8.
- Page 8 Step5. Install the assembly parts in step 2, step 3 and step 4. Use 16pcs M4 Pan Head screws (Item 12) to connect assembly parts in step 3 with step 4. Use 4pcs M6 Hexagon screws (Item 11) to connect assembly parts in step 2 with step 4.
- Page 9 Step6. Fix the screw as the following position. Use 2pcs Item 13-1 and Item 14 to fix the positions as shown below. Step7. Fix the screw as the following position is LEVEL 1, LEVEL 2 and LEVEL 3. Use 2pcs Item 13-2 and Item 14 to fix the positions as shown below. : The position is for LEVEL 1 : The position is for LEVEL 2 : The position is for LEVEL 3...
- Page 10 Adjust the stand height. Step1. Fixing the screw as the following position. < LEVEL 1 > Install the mounting plate part at the “0” LEVEL1 marking of the main body part < LEVEL 2 > Install the mounting plate part at the “200” LEVEL2 marking of the main body part.
- Page 11 < LEVEL 3> Install the mounting plate part at the “500” LEVEL3 marking of the main body part. Step2. After following the step1, the final assembled product is as shown below. < Height: LEVEL 3 > < Height: LEVEL 2 > <...
-
Page 12: Screen Assembly
Screen assembly The 8pcs fixed mounting lock (item 15) behind the cabinet are assembled to the cabinet and locked with tools. Note: The remaining 7pcs mounting lock are in the accessory list of AIO product. Mounting lock+ Bolt (item 15) <...
