Cytech UCMA/4G7608 Quick Start Manual

UCMA/4G7608
This is the UCMA/4G7608 Quick Start Guide. Please download the full Manual
from http://www.cytech.biz/ucmgsm_manual.html
The UCMA/4G7608 provides a 4G (LTE) cellular network connection to Comfort.
This gives Comfort the following abilities;
Acts as a backup for alarm dialout when the land line is faulty or cut.
•
Alternately, it can be used as the primary dialler without a fixed telephone line,
for installations where a telephone line is not available.
Allows the user to dial to the GSM number instead of the fixed telephone line to
•
access Comfort menus.
Allows Comfort to report alarms to the users mobile phones via SMS. The SMS
•
message will show time stamp, Text Identification, Alarm type and Zone or
User name.
Allows authorised Mobile phones to send commands to control or check the
•
status of appliances and the security system via SMS. Each Phone can be
independently authorised to arm, disarm, and access automation control.
Allows date and time update by Internet Time servers
•
The UCMA/4G7608 requires a Nano-SIM card to be inserted, just like with a
cellular phone. This can be a prepaid card, or a postpaid one which is billed
monthly.
Features of UCMA/4G7608
Zone and Alarm Names (32 characters) are stored in UCMA/4G7608 EEPROM.
•
64 Customised messages can be sent by SMS
•
Help Messages are sent by SMS after reciving (1)
•
Query Security Mode and Control Status
•
Home Control SMS Command will reply with Status
•
Arm/Disarm Security System will reply with Security Mode status.
•
Alarm SMS messages from Comfort include Time Stamp
•
Alarm SMS messages from Comfort includes User Names instead of Number for
•
user alarms e.g. Arm and disarm
Each Phone has Permissions for SMS Arm, SMS Disarm, SMS Control
•
GSM Signal Level 0 to 4 in Comfigurator status bar
•
Support for non-English character sets using UCS2.
•
Differences betweem UCM/4G and UCMA/4G7608
( UCM/4G does not support VoLTE (Voice Over LTE). It uses 3G Voice band for
Voice calls, but it uses 4G for SMS. It will not be able to make voice calls
without a 3G network
( UCMA/4G7608 supports VoLTE
Specifications
UCMA/4G7608
PCB Size: 108 x 88 mm
•
Power Supply (from Comfort): 12V 50 ma (idle), 250 ma (transmit)
•
UCMA/4G7608 Quick Start Guide
1
