- Page 1 HELIFLU Anti scaling User Manual...
- Page 2 Heliflu TZN Anti scaling — Instruction manual Content Chapter 1: Introduction to Anti Scaling TZN Meters ........................4 Generation of Signal ............................................5 Chapter 2: Meter Components by Meter Size ..........................6 Meter Body ................................................7 Measurement Cartridge Types by Size....................................7 Detection Sub-assembly / Electronic Enclosure ................................
- Page 3 Heliflu TZN Anti scaling — Instruction manual Personnel Requirements ..........................................31 Hazards arising from failure to observe the instructions and warnings ....................31 Safety instructions ............................................31 Conditions of operation ..........................................31 Repair and maintenance.......................................... 32 Transport, handling, and storage ......................................32 Unpacking ................................................
- Page 4 Heliflu TZN Anti scaling — Instruction manual Chapter 1: Introduction to Anti Scaling TZN Meters The simple, rugged construction of Anti Scaling TZN turbine meters provides excellent accuracy and measurement repeatability for a wide range of industrial applications. All TZN flow meters are designed to provide high quality liquid volume measurement across a wide range of viscosities (0.3 to >1,000 cSt).
- Page 5 Heliflu TZN Anti scaling — Instruction manual Generation of Signal The operating principle of helical turbine flow meters is based on the electromagnetic field generated by the rotational velocity of magnets imbedded in blades of the helical rotor passing by a pick-up coil positioned in the flowmeter body.
- Page 6 Heliflu TZN Anti scaling — Instruction manual Chapter 2: Meter Components by Meter Size TZN flowmeters include the following components: Body · Measuring sub-assembly / cartridge · Inlet ring · Detection sub-assembly / Electronics enclosure · Flow conditioner (Optional) · ½...
- Page 7 Heliflu TZN Anti scaling — Instruction manual Meter Body The meter body is most commonly made of carbon steel or stainless steel (AISI 316/316L or equivalent); other materials are available upon request (Duplex, Hastelloy …). The meter body contains a removable cartridge. Depending upon meter size and operational preferences, the body can be fitted with one, two or three bosses, allowing generation of single or dual pulse signals to flow computer, as well as the addition of a localized readout via a totalizer if desired.
- Page 8 Heliflu TZN Anti scaling — Instruction manual Nominal sizes ≥ 16" The 3-piece cartridge is centered and fastened into the body by means of upstream and downstream stainless steel cross pieces containing the rotor. The outer rings are fixed into the meter body to hold the cartridge in place with screws.
- Page 9 Faure Herman can supply the flow conditioning assembly which integrates upstream piping, flow conditioning element (plate, straightening vanes, etc.) and downstream piping (to be utilized at time of meter calibration).
- Page 10 Prior to installing the TZN, visually inspect the turbine meter; pay particular attention to name plate (check for serial number, process conditions, direction of flow …), flange rating and general conditions. Should the product be damaged or documents missing, please contact the Faure Herman Worldwide Customer Support & Service via phone, email or website: Customer Support &...
- Page 11 Heliflu TZN Anti scaling — Instruction manual Handling recommendations: Meter sizes ³ 6"(DN 150) or weighing > 30 kg [66 lbs] The TZN must be carefully handled with lifting rings (when applicable) or with straps on both sides of the body.
- Page 12 Heliflu TZN Anti scaling — Instruction manual Chapter 4: Installation and Operation TZN turbine flowmeters can be installed horizontally or vertically (ascending flow) provided the flow direction indicated on the cartridge and meter body are followed. For custody transfer applications, turbine flowmeters require the integration of a minimum upstream pipe length at least equal to 10 times the pipe diameter and at least equal to 5 times the pipe diameter downstream.
- Page 13 Heliflu TZN Anti scaling — Instruction manual Meter installation Before installation, keep the equipment in its original packing, sheltered from bad weather and possible impacts. The meter should be installed in the measurement line with proper alignment of upstream and downstream flanges so that stress on the equipment body is avoided.
- Page 14 Heliflu TZN Anti scaling — Instruction manual Gaskets Check to ensure that the proper gaskets are installed according to flange type: ASME B16.20 and ASME B16.21 or NF EN 1514 and NF EN 12560 standards. NOTE: Spiral wound gaskets are forbidden for flanges rated below class 300 or PN 63. Never reuse gaskets.
- Page 15 Heliflu TZN Anti scaling — Instruction manual Condition of Liquids Measured Flowmeter life duration and measurement reliability can be seriously impacted by the presence of gas and/or solid particles in the flowing liquid. The presence of gas, in the form of bubbles or emulsions, can cause serious degradation of measurement performance.
- Page 16 Heliflu TZN Anti scaling — Instruction manual IMPORTANT: After a period of critical monitoring, the filtration degree can be relaxed to reduce strainer maintenance and pressure losses, e.g. MESH 6 to MESH 4 on a 12” meter (consult manufacturer). Should a filter and air elimination system be used simultaneously, we recommend placing the air eliminator as the last device upstream of flow conditioning.
- Page 17 Heliflu TZN Anti scaling — Instruction manual Hazardous area classification must be checked prior to connection (refer to ATEX or UL plate). Depending on preamplifier type (2 wire Standard, NAMUR or 3 wire Open Collector); connect the field shielded wire according to figures below. 2 wire preamp 3 wire preamp (Standard / NAMUR)
- Page 18 Heliflu TZN Anti scaling — Instruction manual 5 to 28 VDC Power Supply Protection fuse > 100 mA 3 wires FH71 blue white 3.5 < VDT < 20 V Ref Power Supply (0V) AWG 16 shielded wire L < 500 m (1,500 ft) (VDT: Voltage Detetcion Threshold) Figure 11.
- Page 19 Heliflu TZN Anti scaling — Instruction manual P148 Mezzanine Card: 12 to 24 VDC Power Supply SKT-C CH1 CH2 CH3 CH4 Pulse + Protection fuse > 100 mA Pulse - 3 wires FH71 1.2 k ± 5% 0.5 W Pulse + S600 Pulse input blue Pulse -...
- Page 20 Heliflu TZN Anti scaling — Instruction manual Chapter 5: Commissioning After meter installation on pipe and completion of electrical connections, proceed with filling of the pipe with liquid. During initial filling of system, make sure any gas present in the pipe is purged by utilizing available venting systems or by passing through the flowmeter at very low flow rate.
- Page 21 Heliflu TZN Anti scaling — Instruction manual Chapter 7: Troubleshooting Problem Potential Cause(s) Flowmeter overrates 1 – 2 – 5 - 7 – 8 – 9 – 10 – 11 Flowmeter underrates 1 – 2 – 3 - 4 – 5 – 6 – 8 – 9 – 10 – 11 Erratic indications 1 –...
- Page 22 Heliflu TZN Anti scaling — Instruction manual Chapter 8: Replacement – Repair Preamplifier replacement This operation is performed when the equipment is de-energized. Refer to magnetic sensors manual: Cut the sealing system (if any) · Unscrew the explosion-proof enclosure cover (4 screws) ·...
- Page 23 Heliflu TZN Anti scaling — Instruction manual Coil replacement Metal Retaining Ring This operation can only be performed after removal of the pre-amplifier (if present): Disconnect the coil / pre-amplifier connection wire · Withdraw the coil while removing the retaining ring using specific tool (ref 870046) ·...
- Page 24 Heliflu TZN Anti scaling — Instruction manual Holding the coil wires, insert the ring in bottom of enclosure and screw into the base of well, taking care to avoid crimping the wires or stripping the polymer threads. Then remove the tool. Figure 18.
- Page 25 Heliflu TZN Anti scaling — Instruction manual Note the direction of engraved arrow on the outer surface before inserting the cartridge into the body and re- fitting and tightening the inlet ring. The cartridge upstream face must be on inlet ring side. The cartridge should be mounted "horizontally", holding the three parts (upstream crosspiece "1", nozzle "2"...
- Page 26 Heliflu TZN Anti scaling — Instruction manual For meters equal or greater than 16", the cartridge is centered and fastened into the body by means of an upstream and downstream stainless steel cross pieces integrating the cartridge parts. Outer rings are fixed into the meter body to hold the cartridge in place with screws.
- Page 27 Heliflu TZN Anti scaling — Instruction manual Chapter 9: Equipment removal The equipment is designed to operate under pressure and must be depressurized and drained before removal (complete disassembly or removal of a component under pressure). If the bolts must be loosened to drain liquid into a recovery tank, make sure the line is completely depressurized prior to loosening bolts.
- Page 28 Heliflu TZN Anti scaling — Instruction manual Appendix 1: Alternative configurations Figure 22. TZN with local totalizer Figure 23. TZN with thermal extensions Figure 224. TZN with 3 pulse outputs...
- Page 29 Heliflu TZN Anti scaling — Instruction manual Appendix 2: K-factor – Flowrate/Frequency TZN Model Min Kfactor Linear Flow Range Frequency Range imp/m imp/Bbl mm - m Inches - BPH ~ Hz (imp/liter) (imp/USG) 16 – 012 0.5 – 0.75 (5 200) (19 700) 0.012–0.12 0.075 –...
- Page 30 Heliflu TZN Anti scaling — Instruction manual Appendix 3: Operating restrictions & Special recommendations The nominal operating process envelope is specified on the nameplate. This envelope is mainly defined in terms Minimum / Maximum – Flowrate · Maximum – Pressure ·...
- Page 31 Heliflu TZN Anti scaling — Instruction manual Safety Consideration Important Information Needed for Installation This manual contains important instructions and safety information. It is essential to read and understand the operating procedures prior to installation, connection, and commissioning of the equipment. Failure to observe these instructions and warnings may damage the flowmeter and/or endanger personnel.
- Page 32 Installation, maintenance and repair of the equipment shall be carried out by suitably trained personnel; all spare parts shall be approved by Faure Herman. No operation or repair which can affect the protective system can be done on this equipment without authorization by Faure Herman.
- Page 33 Return Contact Faure Herman prior to any return. If the flowmeter has been used with hazardous, corrosive, or toxic substances, the operator must make sure that it has been correctly rinsed, cleaned, and decontaminated before being returned to Faure Herman.
- Page 34 Heliflu TZN Anti scaling — Instruction manual Electrical components plate According to ATEX Directive, turbine meter consists of both mechanical and electrical parts. Each component certification which combines to provide the complete meter protection system and parameters. Complete unit plate (mechanical &...
- Page 35 Heliflu TZN Anti scaling — Instruction manual Marking example ATEX & IECEx Electrical Component and Tag Example Electrical components are covered by certificates: · LCIE 03 ATEX 6230X and IEC Ex LCI 12.0013X which allow use in flameproof (d) application. ·...
- Page 36 Heliflu TZN Anti scaling — Instruction manual UL & cUL Installation Magnetic sensor assemblies are UL and cUL certified for use in Class I, Div 1, Groups C and D hazardous locations, with several combinations of coils and preamps. Marking example...
- Page 37 Heliflu TZN Anti scaling — Instruction manual Risk analysis according to Directive 2014/68/EU Suitable resistance Requirements Temperatures and pressure limits should be considered during the design phase. Excess temperature and pressure The limitations are indicated on the equipment; the user is responsible to set up equipment properly.
- Page 38 This equipment must be installed and serviced by trained, specialized staff who understand the languages used in the manual. If you require a manual or any additional information, please contact the FAURE HERMAN Customer support team: FAURE HERMAN - 2, Lieu-Dit l’Archette –...
- Page 39 Heliflu TZN Anti scaling — Instruction manual FAURE HERMAN FAURE HERMAN - USA 2 Lieu-Dit l'Archette 8280 Willow Place Dr. North 72400 La Ferté Bernard Suite 150 France Houston, TX 77070 (U.S.A) Tel : +33 (0)2 43 60 28 60...
